REVLON ONE-STEP RVDR5371ED1 Manual page 3

KEEP THESE IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions before using this appliance. This appliance is intended for household use only.
These instructions are also available on our website. Please visit www.helenoftroy.com/emea-en/
WARNING: Do not use this appliance near
bathtubs, showers, basins or other vessels
containing water.
WARNING: When the appliance is used in a bathroom,
unplug it after use since the proximity of water presents a
hazard even when the appliance is switched off.
For additional protection, the installation of a residual current
device (RCD) having a rated residual operating current
not exceeding 30 mA is advisable in the electrical circuit
supplying the bathroom. Ask your installer for advice.
This appliance can be used by children aged from 8
years and above, and by persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
Children should be supervised to ensure that they do not
play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING: Do not leave the appliance unattended. Do not
allow bare skin or the eyes to come into contact with any
heated surface on the appliance when in use. Do not place
the appliance on any heat-sensitive surfaces when hot
or plugged into the mains. Always unplug the appliance
when not in use.
WARNING: Do not block the air inlet or outlet during use.
When using the appliance, care must be taken to prevent
hair entering the air inlet opening. The air outlet opening of
this appliance will become hot during use, avoid touching
the outlet or any accessories attached to the outlet.
NOTE: Use on towel-dried hair only.
WARNING: Should this product malfunction, do not
attempt to repair it. This appliance has no user-serviceable
parts or components.
2
Blow-Dry Multi Air Styler 5-in-1
The revolutionary One-Step ™ Blow-Dry Multi
Styler is designed to deliver multiple styles for
all hair. It's gentle on your hair as it dries, curls
and styles without extreme heat, creating shiny,
healthy-looking styles with less damage.
Original Revlon Large Oval Brush:
Ceramic Titanium Coating
For shiny and long-lasting styles.
360° Vented Airflow Curler:
Triple Ceramic Coating
Triple ceramic coating helps reduce damage from
over-styling with even heat distribution, making
styling fast and easy.
Overheating Cut-Off
This appliance is equipped with a thermostat that
will cycle OFF (0) should the heat of the dryer exceed
the optimum drying level, due to partially blocked
air inlet or outlet openings. In the event that the
appliance stops or releases only cool air during
use, turn the appliance OFF (0) and allow it to cool
down. Once the appliance cools, the thermostat will
automatically reset and usage may resume.
Styling
• Always towel-dry hair to remove excess
water and smooth it with a comb or brush
to untangle. Styling hair will be faster if it is
slightly damp, not wet.
• Plug the appliance into an electrical outlet and
turn the temperature dial to LOW (I). Gradually
increase to a comfortable temperature.
• First use the Root Drying Concentrator
attachment to prepare the hair, begin blow-
drying and combing your fingers through
your hair, lifting sections and aiming the
concentrator at the roots. Continue until the
roots are dry.
• Remove the roots drying concentrator head
and attach the 70mm oval brush attachment to
smooth your hair and give volume.
• For best results, separate hair into manageable
sections.
Depending on the style you want to achieve use
the different attachments:
For Classy Curls ends: Attach the 32mm
360° Vented Airflow Curler head. Holding the
appliance vertically, clamp a 2.5 cm section at
the ends and roll toward your crown. Continue
holding the appliance vertically until hair feels
dry. Lightly press the clamp to release hair and
pull the appliance downward to unroll the curl.
Repeat until hair has been dried into bouncy
spiral curls.
For Sleek style: Attach the paddle brush head.
Starting with the bottom section of hair, place
brush dryer over the hair and close to the roots
and glide the paddle brush until the ends. It will
give you a smooth, sleek look.
For shaping your style and get flips: Attach
the round brush head. Shape your style by
further boosting root volume, create soft curls,
flips for layered cuts.
ENGLISH
• Turn the appliance off when styling is complete.
Styling tip: While hair is still clamped, twist the
temperature dial to COOL and hold for 10–15
seconds.
How To Change The Attachments
Press the release button down and slightly
twist the handle to the right as you pull the
attachment away from the handle of the
appliance (illustration 1). To attach one of the
other attachments, align the attachment with
the handle and insert it with a slight twist to
the left until you hear a CLICK to secure and lock
attachment in place (illustration 2).
Features:
See page 1.
A. Root drying concentrator
Reduces dry time and preps for hair
curling and styling.
Unique Comb Design to easily reach
the roots.
B. Paddle Brush
Large Paddle Design dries & smooths
hair quickly.
Detangling Bristles glide easily through
the hair.
C. Round Brush
D. Revlon Original Large Oval Brush
Oval Design - 70 mm large.
Ceramic Titanium Coating.
Tangle-free Nylon Bristles with
activated charcoal pins.
E. Curler
F. Attachment release button
G. Lightweight ergonomic sleek handle
H. 4 Settings (Off, , I, II, III )
I. Air inlets
J. 2.5m tangle-free swivel cord
The appearance of this appliance may differ from
the illustration.
Cleaning
Always unplug the appliance from the mains after
use and allow it to cool before cleaning. Wipe the
outer surface of the dryer with a slightly moist
cloth, then wipe dry. Dust and lint can be removed
from the air intake openings with a small brush or
vacuum cleaner with a brush attachment.
Storage
Always unplug when not in use.
Allow the appliance to cool before storing.
Always store in a dry location. Do not pull or
twist the cord. Do not wrap the cord around the
appliance, as this may cause the cord to wear
prematurely and break. Regularly check the power
cord for wear and damage (particularly where it
enters the appliance and the plug).
3
