HPE Aruba Networking 9300-32D
and 9300S-32C8D Switches and
Accessories
Start Here: Installation, Safety, and Regulatory Information
Published: August 2024
Edition: 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aruba Networking 9300-32D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HPE Aruba Networking 9300-32D

  • Page 1 HPE Aruba Networking 9300-32D and 9300S-32C8D Switches and Accessories Start Here: Installation, Safety, and Regulatory Information Published: August 2024 Edition: 3...
  • Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code. Along with the request, please send a check or money order in the amount of US $10.00 to:...
  • Page 3: Applicable Products

    See the rest of this guide for important pre-setup information. There are no user-serviceable parts in the HPE Aruba Networking power supplies. For switch or accessory service needs, contact an authorized HPE Aruba Networking representative. Applicable products...
  • Page 4: Installation Precautions And Guidelines

    HPE Aruba Networking 9300S 32p QSFP28 100G 8p QSFP-DD 400G Switch Overview product information The HPE Aruba Networking 9300-32D and 9300S-32C8D Switch Series are a family of premium edge networking stackable switches, ideal for enterprise network access, aggregation, and core. They provide the foundation for high-performance networks supporting IoT, mobile, and cloud applications.
  • Page 5: Power Cords

    Different countries/regions may require different power cords. For a list of the power cords that apply to your HPE Aruba Networking switch, see the section that lists power cords in the latest edition of the Installation and Getting Started Guide for you switch product.
  • Page 6: Environmental And Physical Specifications

    Environmental and Physical specifications Table 1: Environmental Specifications for all HPE Aruba Networking 9300-32D Switches HPE Aruba Networking 9300-32D Switches Operating temperature* Front-to-Back airflow: 45°C 32°F to 113°F (0°C to 45°C) at sea level Derate 1°C for every 1,000 ft to 10,000 ft (300 m to 3.0 km) Back-to-Front airflow: 40°C...
  • Page 7 Item Dimensions (W x D x H) Weight R9A29A 17.26" x 23.23" x 1.71 " (43.8 x 59.0 x 4.3 cm) 26.9 lb (12.2 kg) R9A30A 17.26" x 23.23" x 1.71 " (43.8 x 59.0 x 4.3 cm) 26.9 lb (12.2 kg) R8Z96A 17.26"...
  • Page 8: Battery Statements

    The battery, which may be too small to bear the CE marking, conforms with applicable requirements. These switches use a lithium battery. Do not attempt to replace the battery. Return the switch to HPE Aruba Networking for battery replacement. The only indicator of battery failure is the failure of the switch internal clock to keep the correct time across a reboot or power cycle.
  • Page 9 QSFP-DD 2p 10G SFP+ Back-to- Front 6 Fans 2 AC PSU (R9A30A) 9300S-32C8D Switch model Maximum current Nominal Voltage Frequency range HPE Aruba Networking 9300S 32p 12A/8A 100-127 / 220-240 VAC* 50Hz-60Hz QSFP28 100G 8p QSFP-DD 400G Front-to-Back 6xFan 2xAC PSU...
  • Page 10 Safety and Regulatory EN 62368-1:2014 +A11:2017 EN 62368-1:2018+A11:2020 Safety-Worldwide IEC 62368-1:2014 (Second Edition) IEC 62368-1:2018 (Third Edition) North American UL 62368-1, 3rd Ed. CAN/CSA C22.2 No. 62368-1:19, 3rd Ed BS/EN 55032:2015/CISPR 32, Class A FCC CFR 47 Part 15: 2018, Class A ICES-003, Class A VCCI-32, Class A CNS 15936, Class A...
  • Page 11 Brazil statement Este equipamento deve ser conectado obrigatoriamente em tomada de rede de energia elétrica que possua aterramento (três pinos), conforme a Norma NBR ABNT 5410, visando a segurança dos usuários contra choques elétricos.) CAUTION: Shock hazard. To completely remove power from the switch, disconnect all power cords.
  • Page 12 Preview of installing an HPE Aruba Networking 9300-32D and 9300S-32C8D switch This section previews the steps for installing the HPE Aruba Networking 9300-32D switches. To find detailed switch installation steps, information on configuration tools, and other instructions and information, see the latest Installation and Getting Started Guide for your switch.
  • Page 13: Documentation Feedback

    8. Connect the network cables. 9. Configure the switch for network operation. Documentation feedback Send any errors, suggestions, or comments to Documentation Feedback (hpe-aruba-techpub@hpe.com). Start Here: Installation, Safety, and Regulatory Information...
