RCP 401 D • Setup Guide
Step 3: Mount the Remote Control Plate
The RCP 401 D can be installed directly into the wall using a
1-gang wall mounting bracket (mud ring) (see figure 4) or a
UL Listed electrical junction box (see figure 5).
The RCP 401 D ships with one black and one white
wallplate. Either wallplate can be used to complement the
surroundings.
Mounting with a wall mounting bracket
Mount the RCP 401 D with a wall mounting bracket as
follows:
1.
Mark the position of the hole (3.61" [9.17 cm] H x 2.13"
[5.42 cm] W) on the wall in the desired location. Use a
level to ensure hole is marked at the correct angle.
2.
Use a drywall saw to cut a hole (
3.
Insert the mounting bracket into the hole. Use a
screwdriver to turn and tighten the locking arms until
they clamp the mud ring to the mounting surface (
Do not overtighten.
4.
Attach cables as described in
Features
on page 2.
5.
Use the two provided Phillips head screws to secure the
button panel to the mounting bracket (
6.
Use the two screws provided to secure the Decorator-
style wallplate to the button panel (
Mounting with a UL-Listed electrical
junction box
The wall box is not provided and must be purchased
separately. Ensure the wall box is the correct size for the
RCP 401 D.
1.
Install the junction box by following the instructions
provided by the manufacturer.
2.
Locate a suitable wall stud and mark the hole on the
wall. Use a level to ensure hole is marked at the correct
angle.
3.
Use a drywall saw to cut the hole. Follow the instructions
of the wall box manufacturer for the correct dimensions
of the hole to be cut.
4.
Use at least two screws or nails to secure the wall box to
the wall stud.
5.
Attach cables as described in
Features.
6.
Use the two provided Phillips head screws to secure the
button panel to the mounting bracket (
7.
Use the two screws provided to secure the Decorator-
style wallplate to the button panel (
4
).
1
).
2
RCP 401 D Rear Panel
).
3
).
4
RCP 401 D Rear Panel
).
1
).
2
Wall
Locking
Arm
2
Wall Mounting
Bracket
Figure 4. Mounting with a Wall Mounting Bracket
Elec trica l
Junc tion
Box
Figure 5. Mounting with an Electrical Junction Box
1
3
R K
M A
R K
M A
R K
T
M A O U
L A Y
A P
S W
n n
t r o t r o
E x E x
RCP 401 D
Wallplate
Wall
1
R K
M A
R K
M A
R K T
O U
M A
L A Y
A P
S W
n n
t r o t r o
E x E x
RCP 401 D
Wallplate
4
2
