- Page 1 Quick Installation Guide TPE-224WS...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ...................... 1. Before You Start ................2. Hardware Installation ................ 3. Web Management Utility ..............Troubleshooting ..................Version 05.03.2007... -
Page 3: English
1. Before You Start Package Contents TPE-224WS Quick Installation Guide Utility & User Guide CD-ROM 2 Mounting Brackets with Screw Power Cord System Requirements Web Browser: Internet Explorer (5.0 or above), Netscape (6.0 or above) Computer with Network adapter installed IEEE 802.3af Powered Device Mini-GBIC module (e.g. -
Page 4: Hardware Installation
2. Hardware Installation Note: 1. After hardware installation is complete, use the Web Browser to configure the TPE-224WS. To access the Web Browser configuration, open your web browser, and enter the default IP Address http://192.168.0.1 and default password "admin". Make sure your computer and the TPE-224WS are configured to the same network segment. -
Page 5: Web Management Utility
3. Web Management Utility Note: If you would like to easily discover all the Web Management Switches on the network, assign IP Address, change the password, and upgrade to new firmware, please install the Web Management Utility. Follow the steps below. For Windows User 1. - Page 6 4. Click Discovery, and then double- click the Switch that appears in the Discovery List. 5. Click the Switch in the Monitor List and then click Configuration setting. 6. Configure the IP Address, Subnet mask, Gateway, and Password. Click Set. English...
- Page 7 For more information regarding the Web-based Smart Utility configuration and advanced settings, please refer to the User's Guide included on the Utility CD-ROM or TRENDnet's website at www.trendnet.com Register Your Product To ensure the highest level of customer service and support, please take a moment to www.TRENDnet.com/register...
-
Page 8: Troubleshooting
Third, plug the device into a different port on the PoE switch. Fourth, try using another RJ-45 network cable. If you still encounter problems or have any questions regarding the TPE-224WS, please refer to the User's Guide included on the Utility CD-ROM or contact Trendnet's Technical Support Department. - Page 9 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 10 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 20675 Manhattan Place Torrance, CA 90501 Copyright ©2007. All Rights Reserved. TRENDnet.
