TRENDnet TL2-E284 Quick Installation Manual
Hide thumbs
Also See for TL2-E284:
- Specifications (3 pages) ,
- User manual (293 pages) ,
- Quick installation manual (15 pages)
Related Manuals for TRENDnet TL2-E284
Summary of Contents for TRENDnet TL2-E284
- Page 1 Quick Installation Guide TL2-E284 1.01...
-
Page 2: Table Of Contents
Table of Contents English 1. Before You Start 2. Hardware Installation 3. LEDs 4. Configure the Switch Troubleshooting Version 11.05.2010... -
Page 3: English
1. Before You Start Package Contents Ÿ TL2-E284 Ÿ Multi-Language Quick Installation Guide Ÿ CD-ROM (User's Guide) Ÿ RS-232 cable (3 m / 9.8 ft.) Ÿ Power Cord (1.8 m / 5.9 ft.) Ÿ Rack Mount Kit Installation Requirements Ÿ Web Browser: Internet Explorer (6.0 or higher) Ÿ... -
Page 4: Hardware Installation
2. Hardware Installation Note: Note: The Mini-GBIC slots are shared with port 25 and 26 Gigabit Ethernet ports. When the Mini-GBIC slots are in use, port 25 and 26 Gigabit Ethernet ports are disabled. 1. Connect the Power Cord to the TL2-E284 and then to a power outlet. -
Page 5: Leds
3. LEDs PWR (Power) SYS (System) 1000M LINK/ACT 10/100M LINK/ACT 10/100M LINK/ACT 10M LINK/ACT... - Page 6 Sequence Definition Device Status LED Color Green Solid Device powered On PWR (Power) Device powered Off Green Solid Device is ready SYS (System) Device is not ready Ethernet LED (RJ-45) Color Sequence Definition Solid 100/200Mbps (Half/Full Duplex) Connected (per port) 100/200Mbps (Half/Full Duplex) Data 100M Link/ACT Green...
-
Page 7: Configure The Switch
4. Configure the Switch Note: 1. Before the Switch can be configured, a Static IP address must be assigned to your computer's network adapter in the subnet of 192.168.10.x. Since the Switch's default IP address is 192.168.10.200, make sure no other network devices are assigned an IP address of 192.168.10.200. - Page 8 2. Using the Console Port Note: A terminal program such as HyperTerminal is required to configure the switch via the Console Port. The instructions shown below demonstrates how to configure the Switch on a Windows PC using HyperTerminal. 1. Connect the RS-232 cable from a serial port on your PC to the console port on the switch.
- Page 9 5. Enter the following, click Apply and then click OK. Bits per second: 115200 Data bits: Parity: None Stop bits: Flow control: None 6. Press the Enter Key. 7. Enter the User Name for login. Then press the Enter. Then Enter the Password and then press Enter.
-
Page 10: Register Your Product
Configuration is now complete For detailed information regarding the TL2-E284 configuration and advanced settings, please refer to User's Guide included on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register... -
Page 11: Troubleshooting
Troubleshooting 1. How do I configure TCP/IP settings on my computer? Windows 7 1. Go into the Control Panel, click Network and Internet, click Network and Sharing Center, click Change Adapter Settings and then right-click the Local Area Connection icon and then click Properties. 2. - Page 12 3. Click Turn Windows features on or off. 4. Check the box next to Telnet Client and then click OK. 5. Please wait while Windows enables Telnet. If you still encounter problems or have any questions regarding the TL2-E284 please contact TRENDnet's Technical Support Department.
- Page 15 Copyright ©2010, All Rights Reserved. TRENDnet.
