Weidmüller IE-PI-RJ45-FH Mounting Information

IE-PI-RJ45-FH 1962730000 / IE-PI-RJ45-FH-A 1132010000
IE-PI-RJ45-FH-B 1132020000 / IE-PI-RJ45-FH-P 1132030000
Montagehinweis / Mounting information / Références de montage
Indicaciones de montaje / Informazioni per il montaggio
1
V1M
Anschlussbelegung /
2
PIN assignments
PIN Nr. / No.
T568A
1132010000 1132020000 1132030000
1 WH-GN
2 GN
3 WH-OG
4 BU
5 WH-BU
6 OG
7 WH-BN
8 BN
Weidmüller Interface
GmbH & Co. KG
Postfach 3030
32720 Detmold
V4
V1
1962730000
T568B Profinet
WH-OG YE
OG OG
WH-GN WH
BU -
WH-BU -
GN BU
WH-BN -
BN -
Telefon +49 5231 14-0
Telefax +49 5231 14-2083
info@weidmueller.com
www.weidmueller.com
V5M
min. 20 mm
min. 0.8 in.
3
3
8
6
7
4
5
2
1
Montageanleitung siehe
Mounting Instructions see
Instructions de montage
Instrucciones de montaje
Istruzioni per il montaggio
V14M
ca. 5 mm
about 0.2 in.
www.weidmueller.com
