SERVICE PARTS
596T-4E
1374687
1218824**
1446854
1296289
1307337
1046153
1232505
1319955
**Color code must be specified when ordering.
1434194-AN2-A
SIMPLICE
Pull-down Kitchen Faucet
1086396
1297533
1228706
1288038
1288208**
1303572
1384194
1384195
1106466
1447895
1288332
1128531
1267359
58946
Installation INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTE:
1. Flush the water supply pipes thoroughly to remove debris.
2. An inline water filter must be used with this product.
3. For new installations, install the faucet to sink before installing.
4. The highest working pressure for sprayhead is 0.5MPa(5bar). If it exceeds 0.5MPa(5bar), a pressure reducer is
needed. The highest water and environment temperature is 60ºC. Please keep sprayhead from heater, or it may
become damaged and cause injury to the user.
5. All installations should comply with the relevant requirements of AS/NZS 3500 and AS/NZS 6400.
ROUGH-IN DIMENSIONS
1243689**
56823
4
1434194-AN2-A
596T-4E
Pull-down Kitchen Faucet
14º
81
234
Ø51
Ø34~Ø41
745
G1/2˝
SIMPLICE
1
