MSB Technology The Select DAC User Manual page 9

Select Powerbase
The powerbase contains isolation technology. The powerbase
detects the input voltage and switches to 120 volt or 240 volt
operation. It is also available in a fixed 100 volt configuration. The
Select powerbase has over-voltage protection.
Two fuses are provided:
- 5A 250V SLO BLO - 5 mm x 20 mm miniature fuse (This is the main fuse).
- 100mA 250V SLO BLO - 5 mm x 20 mm miniature fuse
(This is for the standby supply only).
Select Powerbase User Interface
There is one button on the front of the powerbase— as well as
two control features just under the front of the powerbase, on the
bottom.
LED
indications
Display
brightness
Power control
White - Power On
Red - Power off
White/Red - Unit is in "Normal" mode, but the 12v
trigger has turned it off.
Flashing Red - The unit is over voltaged or has
over heated and has gone into protection. (Once
the problem has been resolved, be sure to cycle
the unit's power.)
This is a spinning wheel to control the brightness
for the power indicator light.
Normal - This sets the powerbase as the 12 volt
trigger master.
Linked - This sets the powerbase as the 12 volt
trigger slave. The 'Normal' powerbase will control
this unit.
