MSB Technology The Select DAC User Manual page 10

The MSB Remote
1 Power On/Off Powerbase on and off. When the
Indicator LED While in use:
2
3
4 Phase Invert Toggles phase invert (Ø - on display)
5 Video Mode Toggles video mode ("Video" - on display)
6 Display Mode Toggles between the three display modes.
7 Volume/Scroll The center scroll wheel controls DAC
8 Mute/Select DAC mute and select when in the menu.
9 Backward Skip backward
10 Play/Pause Play and pause
11
12 DAC Menu Enter DAC menu
13
14
15 Charging Port Micro-USB to charge the remote battery
powerbase is linked to an amplifier or MSB
product via the 12 volt trigger system, this
button will turn off the entire system.
White - Command Sent
Red and White - Command Sent
and Low Battery
Red Flashing - Needs Charging
While charging:
Red - Charging
White - Fully Charged
Input Toggles directly through DAC inputs
volume and scrolls when in the menu.
(Renderer and MSB Transport only)
(Renderer and MSB Transport only)
Forward Skip forward
(Renderer and MSB Transport only)
While in menu:
Up - Volume wheel up
Down - Volume wheel down
Enter - Mute (Center button)
Return - DAC menu button
Stop Stop media
(Renderer and MSB Transport only)
Repeat Track or playlist repeat
(Renderer and MSB Transport only)
10
