TRENDnet TFC-1000S40D3 Specifications

FEATURES
• Compliant with IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-LX Standards
• Provides Dip Switch for Fiber (Auto/Manual), LLR (Enable/Disable)
• Support LLCF (Link Loss Carry Forward, Link Pass Through)
• Supports LLR (Link Loss Return) for FX Port
• Supports Full-Duplex and Auto-Negotiation Mode for Fiber Port
• Single-Strand Fiber Optic, Hot Pluggable & Wall-Mountable
• Optional 19" system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters
• 5 year limited warranty
Intelligent 1000Base-TX to 1000Base-FX Dual Wavelength
Single Mode SC Fiber Converter TX1310
TFC-1000S40D3
The TFC-1000S40D3 Bi-Directional Intelligent Fiber Converter works
with the TFC-1600 chassis system or as a standalone unit. This
converter is a Dual Wavelength Single Mode SC-Type fiber converter
that supports port-based SNMP reporting and spans distances up to
40km (24.9 miles). This module must be used with the TFC-1000S40D5
module. Ports include 1 x 1000Base-TX (RJ-45) port and 1 x 1000Base-
FX (SC Simplex Type) port.
fiber
TFC-1000S40D3
rev: 07. 1 9.2010
