- Page 1 S5800SERIESSWITCHESENABLEWEBMANAGEMENTCONFIGURATIONGUIDE S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE Models:S3200-8MG4S;S3200-8MG4S-U www.fs.com...
-
Page 2: Table Of Contents
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE Contents 1. Introduction..............................1 2. Topology..............................1 3. Configuration Steps............................ 1 3.1 Connection Equipment ....................................1 3.2 Download Related Software ..................................1 3.3 Configure Computer Ip ....................................1 3.4 Configure Software Parameters ................................... 2 3.5 Login Switch ........................................3 3.6 Configure the Port of the Network Card Connection Device for the Server ...................3... -
Page 3: Introduction
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE 1. Introduction This document details the steps to upgrade the switch system firmware for version 1.0.1.11 2. Topology 3. Configuration Steps 3.1 Connection Equipment According to the way of networking topo to connect PC and S3200-8MG4S switch to network.One end of the RJ-45 cable is connected to the PC's network port, and the other end is connected to the Manage interface of S3200-8MG4S. -
Page 4: Configure Software Parameters
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE 3.4 Configure Software Parameters After the switch is powered on, right-click "My Computer" on the PC, click Manage, and check the com port corresponding to the console line in the device manager. (If an unrecognized USB device is displayed, please download and install the corresponding driver), then open SecureCRT, select the serial port login method, and select the serial number from the device manager. -
Page 5: Login Switch
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE 3.5 Login Switch When starting the switch, and display "Hit Esc key to stop autoboot: 1", press "ESC" button to enter the command line. As the picture shows. 3.6 Configure the Port of the Network Card Connection Device for the Server After completing the previous step, we need to configure the port of the server network card connection device. -
Page 6: Configure Tftpd32 Software
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE 3.7 Configure Tftpd32 Software Open Tftpd32 software and set Server interfaces as the local IP address of the computer. Current directory file Select the location where the firmware file is stored.As the picture shows. -
Page 7: Enter Web Interface
S3200 SERIES SWITCHES FIRMWARE UPGRADE GUIDE 3.10 Enter Web Interface After the restart,Upgrade completed.Enter the Administrator IP address:192. 168. 1.88 in the URL bar of Google Browser,then enter the default username and password admin/admin.As the picture shows. www.fs.com...
