SERVICE PARTS
25981K-4
PULL-DOWN KITCHEN FAUCET UPRIGHT HANDLE
90482
1474452
1463722
1466825
1463730
**Finish code must be specified when ordering.
1463725-H2-A
ATOM
1463723**
1435853**
833438
1435854
1463700**
1357256
1466826
INSTALLATION INSTRUCTIONS
25981K-4
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. For new installations, install the faucet to sink before installing.
3. The highest working pressure for spray is 0.5MPa (5bar). If it exceeds 0.5MPa(5bar), a pressure reducer
is needed. The highest water and environment temperature is 60ºC. Please keep spray away from heater,
or it may become damaged and cause injury to the user.
ROUGHING-IN DIMENSION (in mm)
Ø34-Ø40
4
1463725-H2-A
PULL-DOWN KITCHEN FAUCET UPRIGHT HANDLE
81
398
13°
75
212
135
75 Max
697
ATOM
212
Ø52
760
G3/8"
1
Advertisement
Related Manuals for Kohler ATOM 25981K-4
Summary of Contents for Kohler ATOM 25981K-4
- Page 1 PULL-DOWN KITCHEN FAUCET UPRIGHT HANDLE BEFORE YOU BEGIN All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
- Page 2 Remove the spray (12). Run hot and cold water through the spout for about one minute to remove any debris. Shut off Do not use abrasive cleaners or solvents on Kohler faucets and fittings. the faucet. Reinstall the spray. "LEAD FREE" is marked on the back of the faucet signifying its compliance with the United States AB1953...
