- Page 1 SF810 Endura Micro NLX Motherboard Product Manual Revision 1.1 July 2000...
-
Page 2: Revision History
The globe indicates a World Wide Web result in damage to data or the address. hardware. RadiSys is a registered trademark of RadiSys Corporation All other trademarks, registered trademarks, service marks and trade names are the property of their respective owners. July 2000 Copyright ©... -
Page 3: Electromagnetic Compatibility
SF810 Endura Motherboard Product Manual Safety & Approvals Notices Battery This product contains a lithium cell. When removing or replacing the lithium cell, do not use a conductive instrument as a short- circuit may cause the cell to explode. Always replace the cell with one of the same type. This product uses a CR2032 cell. - Page 4 Connect the equipment into an outlet on a different circuit to that of the receiver • Consult the dealer or an experienced radio/TV technician for help. Any change or modification to this product not expressly approved by RadiSys could void the approvals held by this product. Legal Directives This product complies with the relevant clauses of the following European Directives.
-
Page 5: Table Of Contents
SF810 Endura Motherboard Product Manual Contents Overview........................ 7 Motherboard Layout........................8 Block Diagram..........................9 Product Options ........................10 Configuration..........................11 1.4.1 Operation Mode Selection....................11 1.4.2 USB Channel 1 Routing ....................11 Motherboard Description ................... 12 Processor ..........................12 System Memory ........................12 Chipset .............................12 Video ............................13 2.4.1 System Memory Allocation...................14 Audio ............................14 Network ............................14 IDE Drives ..........................15... - Page 6 SF810 Endura Motherboard Product Manual 3.7.1 Motherboard Power Consumption ................26 3.7.2 General Purpose I/O Lines...................27 Motherboard BIOS ....................28 Configuration..........................28 Update and Recovery ......................29 4.2.1 Creating a BIOS Update Diskette ................29 4.2.2 Updating the System BIOS ..................29 4.2.3 Creating a BIOS Recovery Diskette................30 4.2.4 Recovering the System BIOS ..................30 4.2.5 Updating the BIOS Customization Area...............31 4.2.6 Updating the FBD......................31...
-
Page 7: Overview
SF810 Endura Motherboard Product Manual 1 Overview The SF810 “Springfield” is a Micro NLX form factor motherboard based around an Intel Celeron or Pentium III processor and an Intel 810 family chipset. It integrates video, audio, system monitoring and Ethernet on a 10.0 x 8.25-inch board and is targeted at the embedded PC technology market. Micro NLX, 10.0 x 8.25 inches Form Factor 370 pin PGA socket for Intel Celeron and Pentium III processors... -
Page 8: Motherboard Layout
SF810 Endura Motherboard Product Manual Motherboard Layout The figure below shows the layout of the SF810 motherboard with the major components identified. PC100 DIMM sockets NLX supplementary edge connector Graphics & memory controller (GMCH) ATAPI CD-ROM audio header Clock generator Mono microphone input 3V Lithium cell –... -
Page 9: Block Diagram
SF810 Endura Motherboard Product Manual Block Diagram The figure below shows a block diagram of the SF810 motherboard. Clocks Intel Celeron or Pentium III Processor PGA370 DIMM 1 SDRAM Bus PanelLink (100 MHz) DIMM 0 Connector Controller Graphics & Memory Controller (GMCH) Connector... -
Page 10: Product Options
SF810 Endura Motherboard Product Manual Product Options The table below lists the product options available. Functions SF810-V SF810-L SF810-FPL ISA support Flat panel interface 82559ER 82559ER SuperCap Each of the products is available with a choice of CPU speed. Consult the latest price list for the available options. -
Page 11: Configuration
SF810 Endura Motherboard Product Manual Configuration The majority of the configuration of the motherboard is done through the Setup utility built into the BIOS – discussed later in this document. There are, however, three jumpers that also control the operation of the motherboard and these are described below. Operating mode Normal Configure... -
Page 12: Motherboard Description
The minimum total memory size is 16MB and the maximum is 512MB. The BIOS automatically configures the motherboard for the correct size, speed and type. See the RadiSys web site at www.radisys.com a list of memory modules that have been tested with this product. -
Page 13: Video
SF810 Endura Motherboard Product Manual Video The video controller is integrated within the 810 chipset GMCH and provides the features listed below. • 2D graphics with full 2D acceleration • 3D graphics with extensive rendering capabilities • Hardware motion compensation for software MPEG2 decode •... -
Page 14: System Memory Allocation
SF810 Endura Motherboard Product Manual 2.4.1 System Memory Allocation The video controller does not have its own memory and makes use of system memory for all its needs. This must be taken into account when the amount of system memory is chosen. When the on-board video controller is not used, it should be disabled completely via BIOS Setup to prevent system memory being allocated to the controller. -
Page 15: Ide Drives
SF810 Endura Motherboard Product Manual IDE Drives Two independent bus-mastering IDE interfaces are provided via connectors on the riser, each supporting ATA modes up to UltraATA/66. The following drive types are supported. • ATA hard disks up to UltraATA/66 speeds •... -
Page 16: Infra-Red Support
SF810 Endura Motherboard Product Manual 2.9.3 Infra-red Support The SF810 motherboard supports an IrDA compliant infra-red interface via the riser. An IR transceiver must be added such as the Hewlett Packard HSDL-3201 or the HSDL-3610 device. The IR port shares the serial port 2 channel and thus the two ports cannot be used simultaneously. A transfer rate of up to 115kbps is supported. -
Page 17: Expansion Cards
SF810 Endura Motherboard Product Manual 2.13 Expansion Cards Expansion cards are supported via the NLX riser. PCI Slots A maximum of 5 bus-master PCI 2.2 compliant slots are supported although risers with a high PCI slot count must be carefully validated to ensure signal compliance with the PCI specification. In order to fully meet the PCI 2.2 specification, the 3VAux-power supply rail must be provided by the riser. -
Page 18: Temperature Monitoring
SF810 Endura Motherboard Product Manual A regulator on the motherboard generates the processor operating voltage with each processor selecting the correct voltage automatically. The table below indicates the correct operating voltage for the different processors. Processor Type Processor Speed Operating Voltage Intel Celeron 300 MHz 2.00V... -
Page 19: Power Management
SF810 Endura Motherboard Product Manual Since the logic is powered by the lithium cell, the tamper detection continues to operate even if the board is unpowered. 2.15 Power management The SF810 motherboard implements a number of power management features with software support for APM and ACPI. -
Page 20: Indicators
The code is built from a number of software and data modules that can be customized and assembled with a software tool that can be provided by RadiSys. Software to support BIOS updates and crisis recovery is also available - see the OEM products Download Library on www.radisys.com... -
Page 21: Specifications
SF810 Endura Motherboard Product Manual 3 Specifications Regulatory EMC Compliance The table below lists the EMC regulations the SF810 motherboard complies with when correctly installed. Regulation FCC Class B (Title 47 of Code of Federal Regulations, parts 2 & 15, subpart B) EN55022:1998 Class B EN55024:1998 Regulatory Safety Compliance... -
Page 22: Industry Compliance
SF810 Endura Motherboard Product Manual Industry Compliance The SF810 motherboard implements the following industry specifications. Specification Description Revision ACPI Advanced Configuration and Power Interface Specification 1.0b Advanced Power Management BIOS Specification AC’97 Audio CODEC ’97 Component Specification ATAPI ATA Packet Interface for CD-ROMs NLX Motherboard Form Factor Specification Peripheral Component Interconnect Local Bus Specification PCI Power Management Interface Specification... -
Page 23: Mechanical
The SF810 is an NLX 1.8 compliant motherboard measuring 10.0 x 8.25 inches. It is manufactured using a 4-layer PCB with components on the topside only. The screen-printing includes the following. • Product Name, RadiSys part number and RadiSys branding. • Location for serial number label •... -
Page 24: I/O Shield And Cover
SF810 Endura Motherboard Product Manual 3.6.2 I/O Shield and Cover An I/O shield for the SF810 when used in a standard NLX chassis with a 9.0-inch aperture is available and is illustrated below. The shield is in two parts – the shield itself, which is manufactured to provide flexible fingers that contact the chassis and a cover that fits inside the shield envelope and provides the stiffness. -
Page 25: Fansink
SF810 Endura Motherboard Product Manual 3.6.3 Fansink The motherboard can be optionally shipped with a processor fansink, which must have a minimum air space of 0.2 inches around it to function correctly. This is shown in the drawing below. 0.2 inch Minimum Air Gap Max. -
Page 26: Electrical
SF810 Endura Motherboard Product Manual Electrical 3.7.1 Motherboard Power Consumption The motherboard power consumption is highly dependent on the processors, memory and devices attached and also on the software that is running and the power state that the board is in. The figures given in the table below are designed to give the user a guide to the power requirements that should be expected under selected conditions. -
Page 27: General Purpose I/O Lines
SF810 Endura Motherboard Product Manual 3.7.2 General Purpose I/O Lines Symbol Parameter Conditions Unit Input High Voltage Input Low Voltage -0.5 Input Leakage Current µA 3.3V µA Input Hysteresis Output High Voltage = -3mA Output Low Voltage = 6mA Page 27 of 45... -
Page 28: Motherboard Bios
SF810 Endura Motherboard Product Manual 4 Motherboard BIOS Configuration The motherboard BIOS includes a setup utility that can be used to both view and modify the board’s configuration. The settings are stored in CMOS RAM with the default settings held in the flash ROM. -
Page 29: Update And Recovery
BIOS ROM (as a result of an interrupted update, for example) to be repaired. Updates are available online from the RadiSys site in the form of a compressed image (ZIP) of a number of files. Using the software contained in the ZIP file, you must first create a flash diskette that is then used for the update or recovery process. -
Page 30: Creating A Bios Recovery Diskette
Follow the steps below. You need a PC with Microsoft MS-DOS, Windows 95, Windows 98 or Windows NT and a blank diskette. 1. Obtain the file update ZIP file from the Download Library on the RadiSys web site, www.radisys.com. 2. Unzip the contents to a directory on your hard drive. -
Page 31: Updating The Bios Customization Area
UPDATE. If you do this using the standard update files contained in the downloaded ZIP, the customizations will be set to RadiSys standard defaults. To update with customer-specific data you must first customize the update disk as described in the BIOS Customization section of this document. -
Page 32: Bios Error Indications
SF810 Endura Motherboard Product Manual BIOS Error Indications Once the motherboard powers-up the BIOS code runs Power-On-Self-Test software to check that the motherboard is operating correctly. During this process, the code writes an 8-bit value to an error port at various code checkpoints. If a fatal error is determined, then the error code indicates the last successful checkpoint reached. - Page 33 SF810 Endura Motherboard Product Manual BIOS POST Checkpoint Codes Enable A20 Initialize hard disk controller Autosize DRAM Initialize local bus hard disk controller Initialize PMM Jump to UserPatch2 Clear 512KB base RAM Build MPTABLE for multiprocessor boards Test 512KB base address lines Install CDROM for boot Test low byte of 512KB base memory Clear huge ES segment register...
-
Page 34: Isa Option Roms
SF810 Endura Motherboard Product Manual BIOS POST Checkpoint Codes Enable keyboard Initialize PEM Test for unexpected interrupts PEM log Initialize PDS PEM Display Display prompt "Press F2 to enter PEM sys error initialization SETUP" CPU cache off Dual CMOS Test RAM between 512KB and 640KB Docking initialization Base Address Late docking initialization... -
Page 35: Customer Support
RadiSys Online Support at www.radisys.com and includes device drivers, BIOS updates, support software and documentation. See the OEM products Download Library. RadiSys hotline numbers for the US and Canada are Support: (800) 438-4769 Service: (800) 256-5917 Online specifications and reference material:... -
Page 36: Appendix A Technical Reference
SF810 Endura Motherboard Product Manual Appendix A Appendix A Appendix A Appendix A Technical Reference Technical Reference Technical Reference Technical Reference A.1. I/O Map Address (hex)* Description 0000 – 000F DMA controller 1 0020 – 0021 Interrupt controller 1 0040 – 0043 Timer counter 0060 –... -
Page 37: Pci Interrupt Allocation
SF810 Endura Motherboard Product Manual Address (hex)* Description 1600 – 165F SIO system management controller and GPIO FFA0 – FFA7 Primary IDE bus master registers FFA8 – FFAF Secondary IDE bus master registers Dynamically assigned USB controller (32 locations on 32-byte boundary) Dynamically assigned SMBus controller (16 locations on 16-byte boundary) Dynamically assigned... -
Page 38: Isa Interrupt Allocation
SF810 Endura Motherboard Product Manual Device IDSEL Device Function Number Number Number power & system management, GPIO) IDE controller USB controller SMBus controller AC97 audio controller AC97 MODEM controller PCI Slot 1 (on riser) AD31 PCI Slot 2 (on riser) AD29 PCI Slot 3 (on riser) AD27... -
Page 39: Isa Dma Channel Allocation
SF810 Endura Motherboard Product Manual A.5. ISA DMA Channel Allocation DMA Channel Description Channel 0 Unassigned 8-bit channel Channel 1 Unassigned 8-bit channel Channel 2 Floppy controller or unassigned 8-bit channel Channel 3 ECP parallel port or unassigned 8-bit channel Channel 4 Cascade channel Channel 5... -
Page 40: Bios Organization
SF810 Endura Motherboard Product Manual A.7. BIOS Organization The BIOS ROM is a 4Mbit device containing eight symmetrical 64KB blocks. The diagram below shows how the ROM is used to store code and control information. The addresses shown refer to the ROM image at the top of the 4GB-address space. -
Page 41: Appendix B Connector Descriptions
SF810 Endura Motherboard Product Manual Appendix B Appendix B Appendix B Appendix B Connector Descriptions Connector Descriptions Connector Descriptions Connector Descriptions B.1. Connector Part Numbers The various motherboard connectors are listed in the table below along with the part number of one of the approved vendors. - Page 42 SF810 Endura Motherboard Product Manual Signal Signal Signal Signal GNT2# A100 SD14 B100 SD15 GNT1# AD31 A101 MASTER# B101 GND +3.3V REQ0# A102 IDEA_DD8 B102 GND REQ2# A103 IDEA_RST# B103 IDEA_DD7 REQ3# AD29 A104 IDEA_DD9 B104 IDEA_DD6 AD30 AD28 A105 +5V B105 IDEA_DD5 AD26 A106 IDEA_DD4...
- Page 43 SF810 Endura Motherboard Product Manual Signal Signal Signal Signal DRQ2 A139 +5V B139 DRATE0 A140 Not Used B140 DS1# ZWS# A141 DENSEL B141 DS0# A142 MTR0# B142 DIR# A143 INDEX# B143 Not Used IOCHRDY A144 MTR1# B144 GND SA18 A145 GND B145 WDATA# SMEMW# SMEMR#...
-
Page 44: Nlx Supplemental Connector
SF810 Endura Motherboard Product Manual B.3. NLX Supplemental Connector Signal Signal CDIN_LEFT CDIN_RIGHT CDIN_GND MIC_IN +5VA LINEO_LEFT LINEO_RIGHT FPSPKR_EN Not Used Not Used Not Used AC97_RST# Not Used AC97_SDIN0 AC97_SDIN1 Not Used AC97_SDOUT Not Used AC97_SYNC AC97_BITCLK MODEM_MIC MODEM_SPKR B.4. DFP Monitor B.6. -
Page 45: Parallel Port
SF810 Endura Motherboard Product Manual B.8. Parallel Port B.11. PS/2 Keyboard Signal Signal Signal Signal STB# AFD# DATA ERR# Not Used CLOCK INIT# Not Used SLIN# B.12. PS/2 Mouse Signal Signal DATA Not Used CLOCK ACK# Not Used BUSY B.13. ATAPI CD-ROM SLCT Signal B.9.
