EDIFIER NeoDots Manual

True Wireless Earbuds with Active Noise Cancellation
EN 1. Power ON/OFF
Open or close the case to power on/off.
2. First pairing
1. Once powered on, the earbuds will automatically enter Bluetooth
pairing mode.
2. Select "EDIFIER NeoDots" in your device settings to connect.
3. Pairing for new device
1. In ON state, press and hold the button on the case for about 3s.
2. Select "EDIFIER NeoDots" in your device settings to connect.
Note: For subsequent use, the earbuds will automatically connect to
the device used last time.
4. Multipoint connection
1
1. Pair device A with the earbuds manually and keep the earbuds in
the case;
2. Re-enter Bluetooth pairing mode and select "EDIFIER NeoDots" in
device B settings to connect.
3. Select "EDIFIER NeoDots" again in device A settings to connect.
Note: For subsequent use, the earbuds will automatically reconnect
to the two devices used last time.
5. Reset
1. Place the earbuds in the case and keep it open.
2. Press the button on the case 3 times, orange LED blinks until the
reset is complete.
6. Charging
Input: 5V
Note: Make sure the USB port is completely dry before charging.
7. Controls
Call
Press Area
x1
x1
x2
Note:
1. Default sound control: High noise cancellation / Ambient sound /
Noise cancellation off.
2. Download EDIFIER ConneX App for more customizable control
settings.
NeoDots
Bluetooth
EDIFIER NeoDots
A
200mA(Earbuds)
Press Area
x1
x1
x2
Manual
3s
2
3s
x3
5V 1A(Charging case)
Music
Press Area
Bluetooth
EDIFIER NeoDots
Bluetooth
EDIFIER NeoDots
3
B
x1 x1
x2 x2
x3 x3
2s 2s
Bluetooth
EDIFIER NeoDots
A
Press Area
