NeoBuds Planar
True Wireless Planar Magnetic Noise Cancelling Earbuds
EN 1. Power ON/OFF
Open or close the case to power on/off.
2. First pairing
1. Once powered on, the earbuds will auto-enter Bluetooth pairing mode.
LEDs will be lit one by one from left to right in a circulating pattern.
2. Select "EDIFIER NeoBuds Planar" in your device settings to connect.
3. Pairing for new device
1. Place the earbuds in the case and keep it open.
2. Press and hold the button on the case for 3s. LEDs will be lit one by
one from left to right in a circulating pattern.
3. Select "EDIFIER NeoBuds Planar" in your device settings to connect.
Note: For subsequent use, the earbuds will automatically connect to the
device used last time.
4. Multipoint connection
1. Pair device A with the earbuds manually and keep the earbuds in
the case.
2. Re-enter Bluetooth pairing and select "EDIFIER NeoBuds Planar"
in device B settings to connect.
3. Select "EDIFIER NeoBuds Planar" again in device A settings to
complete the multipoint connection.
5. Reset/Left&Right Connection
1. Place the earbuds in the case and keep it open.
2. Press the button on the case 3 times, the LED will blink until the
reset is complete.
Note: This operation will clear pairing records, reconnect left&right
earbuds and restore factory settings.
6. Charging
1. Connect the included USB-C cable to a power source.
2. Or charge with a compatible third-party wireless charger (not included).
Input: 5V
200mA (Earbuds)
Note: Make sure the USB-C port is completely dry before charging.
7. Controls
Press area
Note:
1. "x 1" Press , "x 2" Double press, "x 3" Triple press, "—" Press and hold.
2. Default sound control: Noise Cancellation / Ambient Sound / Noise
Cancellation off.
3. Download EDIFIER ConneX App to customize more control settings.
Manual
Bluetooth
EDIFIER NeoBuds Planar
A
EDIFIER NeoBuds Planar
Bluetooth
EDIFIER NeoBuds Planar
3s
3s
or
5V
1A (Charging case)
Bluetooth
Bluetooth
EDIFIER NeoBuds Planar
A
B
x3
Press area
