Adesso Leonard 4008-22 Assembly Instruction

Assembly Instructions (English)
ASSEMBLY INSTRUCTION FOR
Leonard Shelf Floor Lamp
Model# 4008-22
1. Screw tube (B) onto base (A)
2. Screw tube (B), (C) and (D) together until tight.
3. Hex screw (G) comes pre-assembled to the curved tube (E).
Before placing the curved tube(E) onto the tube (D) , please
unscrew this hex screw (G).
4. Place the curved tube(E) onto tube (D), then tighten it using
hex screw (G) with allen wrench (F).
Note: The Arc lamp should face forward with the arm
reaching over the base (see diagram below).
5. Screw tube (H) onto base (A), then place glass top (I) onto
tube (H) together.
6. Screw second tube (H) onto base (A), then screw tube (J)
onto tube (H). Then place glass top (K) onto tube (J) and
screw down to tighten.
7. Socket ring (M) comes pre-assembled to the socket. Before
placing the shade onto the socket, please unscrew this socket
ring.
8. Place shade (L) onto socket and tighten it with socket ring
(M).
GENERAL PRODUCT INFORMATION:
This product is suitable
for dry locations only.
---------------------------------------------------------------
IMPORTANT SAFETY INSTRUCTIONS:
This portable lamp has a polarized plug as a feature to reduce the
risk of electric shock (one blade is larger than the other). This plug
will fit in a polarized outlet only one way. If the plug does not fit
fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician.Do not use with an extension cord unless the
DO NOT ALTER THE PLUG .
plug can be fully inserted.
----------------------------------------------
BULB TYPE: type A Max 100W bulb (bulb not included).
PARTS DIAGRAM:
(1)* HEX screw (G)
353 West 39
4008-22
(1)* Allen Wrench (F)
th nd
Street 2 Floor New York, NY 10018
Tel: (212) 736 4440 Fax: (212) 736 4806
www.adessohome.com
1.0
