Pyle HYDRA PLMRMP3A User Manual

Pyle HYDRA PLMRMP3A User Manual

4-channel amplifier

Advertisement

Quick Links

Visit Our Website
SCAN ME
PyleUSA.com
PLMRMP3A - PLMRMP3B - PLMRMB4CW
PLMRMB4CB - PLMRKT4A - PLMRKT4B
4-Channel Amplifier
USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYDRA PLMRMP3A and is the answer not in the manual?

Questions and answers

Summary of Contents for Pyle HYDRA PLMRMP3A

  • Page 1 Visit Our Website SCAN ME PyleUSA.com PLMRMP3A - PLMRMP3B - PLMRMB4CW PLMRMB4CB - PLMRKT4A - PLMRKT4B 4-Channel Amplifier USER GUIDE...
  • Page 2 Pyle, founded in the 1960s, has evolved into a renowned manufacturer of high-quality advanced woofers. Our journey started with the iconic Pyle Driver, becoming a household name in original speakers. In the late 20th century, we expanded into replacement speakers, car audio, home audio, marine audio, and professional audio &...
  • Page 3 CONTENTS IC WARNING INSTALLATION PRECAUTIONS CONTROLS, INPUT AND OUTPUT CABLES ADJUSTMENT CONTROLS AND SETTINGS POWER AND SPEAKER WIRING REGISTER PRODUCT READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE. California Prop 65 Warning WARNING: This product may expose you to chemicals, which is known to the state of California to cause cancer, birth defects and other reproductive harm.
  • Page 4: Installation Precautions

    IC WARNING - English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 5 5. Power Connection Safety: Before making or breaking power connections in your system, disconnect the marine vessel battery. Con rm that your head unit or other equipment is turned o while connecting the input jacks and speaker terminals. Replacing Power Fuse: If you need to replace the power fuse, use only an identical fuse to the one supplied with the ampli er.
  • Page 6 Turn on the ampli er; the red Bluetooth indicator LED blinks. • In your phone settings, nd and open the "Bluetooth" function. • Search for the Bluetooth device named "pyle ampli er." After a successful connection, the red Bluetooth indicator LED will stay on. • Bluetooth Version: 3.0 •...
  • Page 7: Power And Speaker Wiring

    Power and Speaker Wiring Wire Color Description Battery (+), 12dc Black Barrery (-), Ground Blue Remote Turn On, 12vdc = ON White CH1 (+) White/Black CH1 (-) Gray CH2 (+) Gray/Black CH2 (-) Green CH3 (+) Green/Black CH3 (-) Purple Purple/Black CH4 (+) CH4 (-) Register Product...
  • Page 8 Questions or Comments? We are here to help! Phone: 1.718.535.1800 PyleUSA.com/ContactUs...

This manual is also suitable for:

Hydra plmrmp3bHydra plmrmb4cwHydra plmrmb4cbHydra plmrkt4aHydra plmrkt4b
