- Page 1 BLUETOOTH AMPLIFIER PLMRM4BTA USER MANUAL Bluetooth A2DP Function • USB Interface • AUX IN function...
-
Page 2: Table Of Contents
CONTENTS Installation ........... ………………………………………………3 Wiring Connection .......………………………………………….…5 Operation ..........……………………………………………..6 USB play operation ......………………………………………………6 BT operation ........…………………………………….………...6 Remote control……………………………………………………………………….…8 Specification ........………………………………………………9 Trouble shooting ......... ………………………………………………10... -
Page 3: Installation
INSTALLATION Notes: Choose the mounting location where the unit will not interfere with the normal driving function of the driver. Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. - Page 4 INSTALLATION...
-
Page 5: Wiring Connection
WIRING CONNECTION ISO CONNECTION... -
Page 6: Operation
OPERATION TURN ON/OFF THE UNIT Note: Press button on the remote control to BAND: 7 turn on/off the unit. AUXILIARY INPUT BDISP: SEL: confirm The unit can be connected a portable audio player through the AUX IN interface. FOLDER+/- FUNCTION When MP3/WMA playing. - Page 7 OPERATION mobile phone on how to operate Bluetooth.) 2) “CAR KIT” should appear in the list on your mobile phone, please select “CAR KIT” and then input password “0000” if necessary if needed. Bluetooth audio (A2DP function) Press MODE key on the remote control till to the BT mode.
-
Page 8: Remote Control Handset
REMOTE CONTROL HANDSET FUNCTION KEY & CONTROL Power ON/OFF Button. 2. VOL+ Volume up button. 3. BAND no function. 4. SEL In MP3/WMA searching mode press it for confirm function. In MP3/WMA mode: Press it shortly for skip previous file. Press and hold it for fast reverse. -
Page 9: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 100 (W) x 100 (D) x 70 (H) Tone Controls : ±10 dB Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) Maximum Output Power : 4 x 40 watts Current Drain : 10 Ampere (max.) -
Page 10: Trouble Shooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition switch is power supply No power. not on. connected to the car accessory circuits, but the engine is not moving, switch the ignition key...
