- Page 1 Electric Standing Desk Instruction Manual EGESD12B / EGESD12V Rev00(A) Technical Support: Other Info: (US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST) support@ergear.com (UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC) Website: https://ergear.com...
- Page 3 IMPORTANT SAFETY INFORMATION • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 4: Specifications
Tools Needed (Not lncluded) Drill Phillips Screwdriver Hammer Specifications Height Adjustment Range RATED 28.3”–46.5” (72-118cm) Power Input Max. Speed Operating Noise Max. Load 100V-240V 20mm/s ≤55dB 176 lbs / 80kg Step 1 Supplied Parts and Hardware Crossbar Left Desk Leg Right Desk Leg Bolt Bolt... - Page 5 x 10 Large Allen Wrench Small Allen Wrench Rubber Pad 3/16” (5mm) 5/64” (2mm) Step 3 Supplied Parts and Hardware Desktop Controller Cable Management Tray Storage Hook Wood Dowel Pin Desktop Panel Connector x 20 Screw Screw M5 x 16mm M5 x 12mm Step 4 Supplied Parts...
- Page 6 Step 5 Actual part Supplied Parts may vary from image shown. and Hardware AC Adapter Cable Clip Step 6 Supplied Parts and Hardware Drawing Pin...
- Page 7 Assembling and Connecting Step 1 the Desk Legs Large Allen Wrench HEAVY! You may need assistance with this step. Large Allen Wrench...
- Page 8 Attaching the Side Plates and the Step 2 Transmission Rod Large Allen Wrench Coupling nut Loosen the coupling nut.
- Page 9 Fig 1 Turn anti-clockwise Left Leg Left Leg Fig 2 Before attaching the transmission rod, measure the heights of the two desk legs to see if they are set at the same level. If not, insert the transmission rod into the hole in the left leg. Turn clockwise Turn the rod to adjust the left leg so it's level Left Leg...
- Page 10 Small Small Allen Wrench Allen Wrench Secure the transmission rod to the motor drive shaft by turning the set screw clockwise. Tighten the coupling nut to fine-tune transmission rod fit.
- Page 11 Step 3 Assembling and Attaching the Desktop Assemble the desktop. Attach the desktop to the frame. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed) or a Phillips screwdriver.
- Page 12 Attach the controller, storage hooks and cable management tray to the desktop.
- Page 13 Attaching the Felt Board and Felt Storage Step 4 Bag to the Desktop Attach the felt board and felt storage bag on the left or right as you need. Hammer (not included) Left Right Large Right Large Left Allen Wrench Allen Wrench...
-
Page 14: Connecting The Cables
Step 5 Connecting the Cables c l u d e N o t l n... - Page 15 Step 6 Using the Felt Board N o t ln c lu d e d...
-
Page 16: Using The Controller
Using the Controller Save Current Height Setting Short-press the button, and the display will flash. Press the , or button to save the current height setting to that button. Select Height Setting 1 Press the button, and the desk will move to the height that was previously set for that button. - Page 17 Settings Press and hold the button until a flashing ‘S-’ is displayed. Change Display Press again, and ‘Un’ is displayed. Press to select it, Height Units press to switch between ‘IN’ (imperial) and ‘SI’ (metric), and press to save your choice. Long press the button, ‘S-‘...
- Page 18 Overvoltage Protection: Input voltage too high. If the correct AC adapter is being used, power off the desk, check the connection between power and the controller, and power on again. Undervoltage Protection: Input voltage too low. If the correct AC adapter is being used, power off the desk, check the connection between power and the controller, and power on again.
- Page 20 Thank you for choosing this product. We strive to provide you with the best quality products and service in the industry. Should you have any issues, please don't hesitate to contact us. Technical Support: (US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST) (UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC) Other Info: support@ergear.com Website: https://ergear.com 860-00966-00 Rev00...
