- Page 1 Electric Standing Desk Instruction Manual Rev00(A) EGESD18B / EGESD18V / EGESD18N Technical Support: (US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST) (UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC) Other Info: support@ergear.com Website: https://ergear.com...
-
Page 2: Specifications
Tools Needed (Not lncluded) Drill Phillips Screwdriver Specifications Desktop Dimensions 57.1” (145cm) RATED Height Adjustment Range Power Input Max. Speed Operating Noise Max. Load 28.3”–46.5” (72–118cm) 100V–240V 20mm/s <55dB 176 lbs / 80kg Step 1 Supplied Parts and Hardware Short Crossbar Long Crossbar Left Desk Leg Right Desk Leg... - Page 3 x 12 Bolt Bolt Large Allen Wrench M6 × 35mm M6 × 11mm 3/16” (5mm) x 16 Small Allen Wrench 5/64” (2mm) Rubber Pad Transmission Rod Step 2 Supplied Parts and Hardware Left Desktop Panel Right Desktop Panel Desktop Panel Connector Screw M5 ×...
-
Page 4: Assembling The Frame
Assembling the Frame Step 1 Connect the crossbars together using the crossbar connector. Connect the desk legs. - Page 5 Attach the leg bases. Short Side Long Side Attach the side plates.
- Page 6 Loosen the coupling nut. Coupling nut Fig 1 Turn clockwise Left Leg Left Leg Fig 2 Turn anti-clockwise Left Leg Before attaching the transmission rod, measure the heights of the two desk legs to see if they are set at the same level. If not, insert the trans- mission rod into the hole in the left leg.
- Page 7 Right Leg NOTE: Make sure the set screw faces out. Ensure the transmission rod is properly inserted into the hole in the left leg. Smoothly connect the other end of the rod to the end of the motor drive shaft on the right leg. Right Leg Secure the transmission rod to the motor drive shaft by turning the set screw clockwise.
- Page 8 Tighten the coupling nut to fine-tune transmission rod fit.
- Page 9 Step 2 Assembling the Desktop Assemble the desktop. Secure the desktop panels with the connectors. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed) or a Phillips screwdriver.
- Page 10 Step 3 Attaching the Desktop Attach the desktop to the frame. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed) or a Phillips screwdriver.
- Page 11 Attach the controller and hooks to the desktop. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed) or a Phillips screwdriver.
- Page 12 Step 4 Connecting the Cables...
-
Page 13: Using The Controller
Using the Controller Save Current Height Setting Short-press the button, and the display will flash. Press the , or button to save the current height setting to that button. Select Height Setting 1 Press the button, and the desk will move to the height that was previously set for that button. - Page 14 Settings Press and hold the button until a flashing ‘S-’ is displayed. Change Display Press again, and ‘Un’ is displayed. Press to select it, Height Units press to switch between ‘IN’ (imperial) and ‘SI’ (metric), and press to save your choice. Long press the button, ‘S-‘...
- Page 15 Overvoltage Protection: Input voltage too high. If the correct AC adapter is being used, power off the desk, check the connection between power and the controller, and power on again. Undervoltage Protection: Input voltage too low. If the correct AC adapter is being used, power off the desk, check the connection between power and the controller, and power on again.
- Page 16 Thank you for choosing this product. We strive to provide you with the best quality products and service in the industry. Should you have any issues, please don't hesitate to contact us. Technical Support (US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST) (UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC) Other Info support@ergear.com Website https://ergear.com 860-00890-00 Rev00...
