Home Accents Holiday 23RT40619114 Use And Care Manual

Safety Information
CAUTION:
Grasp the plug to insert or remove from the power source. Do not unplug by pulling on cord.
CAUTION:
The lighting string on this product is rated at 2.4 Watts (0.02 Amps) for Baby Deer and rated at 4.8 Watts (0.04 Amps) for Doe. Do
not overload. Do not connect to another lighting string, decorative outfit or other electrical products. Before you use or re-use this product inspect
it carefully. Discard or return to place of purchase with purchase receipt if the product has cuts, damage, frayed wire insulation on cords, cracks
in the socket enclosures, loose connections, exposed copper wire or other obvious damage.
Pre-Assembly
Carefully remove all the parts from the box and place them on the ground. Many parts are connected by the lighting
string that runs throughout the item. Take special care not to pull, cut or damage the lighting string. Read the entire
manual prior to assembly and identify all the parts included in the package against the parts list. It is recommended
to assemble parts of the product while lying flat on the ground or a flat surface, versus standing the item up to
assemble the parts. If any parts are missing or damaged do not attempt assembly but contact our customer service
center or return to place of purchase with purchase receipt,1-855-HDHoliday (1-855-434-6543)
Assembly of this product may require more than one person.
PACKAGE CONTENTS
O
P
D
C
Q
F
R
Assembly
1
Assembling the Legs to the Body of Baby Deer
Insert the connecting rods on the Baby Deer's Front and Hind Legs
(E, F) into the connecting holes on the underside of the Body (C) and
fasten together at the connecting loops with the Plastic Ties (Q). The
Legs come with metal bars attached to stabilize the Baby Deer. Insert
the hooked end of the metal bars into the metal hole on the opposite
Leg.
F
3
Assembling the Ears & Tail to Body of Baby Deer
Insert the connecting rods on both Ears of Baby Deer (A) into the
matching connecting holes at the top of Head / Neck of Baby Deer
(B). Insert the connecting rod on the Tail of Baby Deer (D) into the
connecting hole at the rear of Body of Baby Deer (C). Insert the
wires on the backside of the Bow of Baby Deer (N) through the
material on the body then twist the wires together to secure.
Use and Care Guide
2-Piece Polar Wishes
LED Deer
M
N
A
B
K
E
C
E
G
H
J
I
L
2
Assembling the Head/Neck to Body of Baby Deer
Insert the connecting rods on the bottom of the Baby Deer's
Head / Neck (B) into the connecting holes on the front of the
Body of Baby Deer (C) and fasten together at the connecting
loops with Plastic Ties (Q).
Q
Please contact 1-855-HD-HOLIDAY (1-855-434-6543) for further assistance.
Item # 1005416747
Model # 23RT40619114
TOOLS REQUIRED
Part Description
A Ear of Baby Deer
B Head / Neck of Baby Deer
C Body of Baby Deer
D Tail of Baby Deer
E Front Leg of Baby Deer
F Hind Leg of Baby Deer
G Ear of Doe
H Head / Neck of Doe
I Body of Doe
J Tail of Doe
K Front Leg of Doe
L Hind Leg of Doe
M Bow of Doe
N Bow of Baby Deer
O Spare Bulb
P Spare Fuse
Q Plastic Tie
R Ground Stake
Q
B
C
A
D
B
C
N
Plier
Quantity
2
1
1
1
2
2
2
1
1
1
2
2
1
1
4
4
20
8
