EASY ASSEMBLY AND OPERATION INSTRUCTIONS
21SV22139 Vintage Clown
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
IF ANY PART IS MISSING OR BROKEN, DO NOT ATTEMPT TO ASSEMBLE THE PRODUCT AND CONTACT SVI CUSTOMER SERVICE FROM 8:30AM TO
5:30PM PST AT 1-855-428-3921, EMAIL CUSTOMERSERVICE@SVIUS.COM, OR CALL THE HOME DEPOT CUSTOMER SERVICE AT 1-877-527-0313.
IMPORTANT TIPS:
• Ensure that the item's adapter is plugged in at the Function Control Box and in
the wall.
• Ensure that the switch on the function control box is on the desired setting.
• If not functioning properly (ex: Mouth doesn't move, eyes don't light up, body
doesn't move), ensure that cables are connected to their corresponding cable as
shown in the instruction sheet.
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
PARTS LIST
A. Base x 1
B. Support Pole x 4
C. Shoe x 2
D. Costume x 1
E. Lower Torso Frame x 1
F. Hip Hoop x 1
G. Upper Torso Frame x 1
H. Chest Hoop x 1
I. Left Arm x 1
J. Right Arm x 1
K. Cotton Candy x 1
L. Head x 1
M. Collar x 1
N. Adapter * x 1
* Power Adapter Spec
Input: 100 - 240VAC 50/60Hz
Output: 5.9V 1.5A
Click
Means It's
Locking Pin
Locked
B
BACK
RIGHT
A
FRONT
NOTE: Throughout the instructions, Right
and Left are relative to the character.
F
B
B
B
A
LEFT
1 1
.
• Ensure that the volume is not all the way down.
• Be sure nothing is blocking the sensor.
• If the item still does not work, contact SVI customer service from 8:30am to
5:30pm PST at 1-855-428-3921, email customerservice@svius.com, or call The
Home Depot customer service at 1-877-527-0313.
A B
G
L
K
C
B
B
B
1 2
.
C D
H I
M
C
B
2 1
.
YOW 1006102962
TM
E
L
J
N
D
B
B
2 2
.
