ENGLISH
Robot vacuum cleaner does not clean The high-efficiency filter is blocked. Clean it.
efficiently or doesn't pick up all the dirt
The main brush is blocked or tangled. Clean it.
The dust tank is full, empty it.
The robot vacuum cleaner could not Bad Wi-Fi signal. Check that the robot vacuum cleaner is
connect to the Wi-Fi network. located in an area with good Wi-Fi signal.
The Wi-Fi connection is unstable. Reset the router, check
if there are any App updates, and try again. This robot
vacuum cleaner only supports the 2.4 GHz band.
Make sure that your device mobile data are deactivated
to improve the linking process.
The robot vacuum cleaner did not Check if the robot vacuum cleaner is in Sleep mode and
carry out the scheduled cleaning task. change mode. This option can be found on the general
settings of the robot vacuum cleaner and allows you to
define time slots in which the robot will not perform the
scheduled cleaning tasks when in Sleep mode.
Make sure the robot vacuum cleaner is plugged to the
mains, that it will not be able to carry out scheduled
cleanings offline, and that the battery is not low.
The robot vacuum cleaner does not The robot vacuum cleaner will map and calculate a
return to the self-emptying base after new route after running in Spot cleaning mode or after
finishing Spot cleaning or changing the changing its starting position.
starting position.
If the self-emptying base is too far away from the robot
vacuum cleaner, the latter won't be able to return to the
base. Manually move the robot vacuum cleaner close to
the base.
The robot vacuum cleaner does not Make sure the robot vacuum cleaner is not in Sleep mode,
resume cleaning. as it will not resume cleaning in this mode.
When manually placed in the self-emptying base, the
robot will not resume cleaning.
The robot vacuum cleaner is always Make sure the robot vacuum cleaner is successfully
offline. connected to a 2.4 GHz network and always in areas with
good Wi-Fi signal.
53
CONGA 11090 SPIN REVOLUTION HOME&WASH
The connection between the Make sure the robot vacuum cleaner and the charging
smartphone and the robot vacuum base are in an area with good Wi-Fi signal, reset the
cleaner failed. router, and retry connection.
Auto clean base
Problem Possible cause and solution
The self-cleaning base does not clean There is not enough water in the clean-water
the mops. tank. Fill it in.
The waste-water tank is full. Empty and clean
it. Also clean the openings of the waste-water
filter.

6. TECHNICAL SPECIFICATIONS

Product: Conga 11090 Spin Revolution Home&Wash
Product reference: 08105
Voltage: 20 V DC 1.5 A
Rechargeable Li-ion battery
Rated capacity: 14.8 V 3200 mAh
Wi-Fi connection: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Maximum Transmission Power: 20 dBm
Product: Self-emptying base
Input: 220-240 V ~ 50/60 Hz
Output: 20 V 1.8 A
Power: 650 W
Technical specifications may change without prior notification to improve product quality
Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the
product and/or batteries must be disposed of separately from household
waste. When this product reaches the end of its shelf life, you should dispose
of the batteries/accumulators and take them to a collection point designated
ENGLISH
