Introduction

The purpose of this manual is to guide installers, operators and technicians through the

operaion of EVO™ 200 and EVO™ 400 automaic tank gauges (ATGs). EVO™ 200 and EVO™ 400

ATGs incorporate the monitoring and alarm capabiliies of preceding automaic tank gauges

with advanced technologies to supply tank and level data more accurately and eiciently. This

manual is also designed to introduce technicians to the opional LCD Graphical User Interface,

which is used as an input device to program system coniguraion and maintain all applicaions

from the front panel of the console. Overall safety issues, troubleshooing informaion, start-up

procedures, warranty, service and return policies, as deined in this manual, must be followed.

EVO™ 200 and EVO™ 400 ATGs consist of an open architecture console that can run muliple

Fuel Management Applicaions simultaneously. It typically contains a color LCD touch screen

user interface, but it can also be operated by a web-based remote interface. Magnetostricive

Liquid Level Probes inside of the tanks provide the console with inventory and leak detecion

informaion. A variety of opional sensors can be used to monitor containment spaces.

LED Indicators: Three LEDs below the front panel give an "at-a-glance" indicaion of the

system status. These LEDs are standard on all systems. The green Power LED indicates that the

system power is on. The yellow Warning LED gives indicaion that the console has detected a

malfuncion or condiion that has been deemed a Warning. The red Alarm LED indicates that the

system has detected an alarm condiion.

LCD Touch Screen: The color LCD touch screen is the most commonly used user interface for the

Fuel Management System. This bright and colorful display allows easy viewing in any lighing

condiion. Touching certain butons or segments of the screen will allow access to menus or

more detailed informaion. Do not use sharp or pointed objects to operate the touch screen or

damage may result. If improper operaion of the touch screen is noted, it may be necessary to

calibrate the touch screen. Please refer to the Rouine Maintenance chapter of this manual for

calibraion procedures.
