Amana PHD48C02E Instruction Manual

Heating
Com fort. Q uality. Trust.
COOLING COOLING CAPACITY, BTUH
RATING SEER
47°/43°F
HEATING 35°/33°F
RATING 17°/15°F
HSPF
UNIT VOLTAGE (NAMEPLATE)
ELECTRICAL UNIT AMPS (TOTAL)
SPECIFICATION MIN CIRCUIT AMPACITY
MAX OVERCURRENT PROTECTION
COMPRESSOR TYPE
RATED LOAD AMPS
LOCKED ROTOR AMPS
CONDENSER HORSEPOWER
FAN MOTOR RPM
FULL LOAD AMPS
LOCKED ROTOR AMPS
CONDENSER BLADE DIAMETER / NUMBER
FAN CFM
CONDENSER FACE AREA (SQ.FT.)
COIL NUMBER OF ROWS
FINS PER INCH
EVAPORATOR HORSEPOWER - # OF SPEEDS
BLOWER FULL LOAD AMPS
MOTOR LOCKED ROTOR AMPS
MOTOR SPEED TAP - COOLING
RPM
EVAPORATOR DIAMETER X WIDTH
BLOWER RATED SCFM COOLING
MAX EXTERNAL STATIC PRESS
EVAPORATOR FACE AREA (SQ.FT.)
COIL NUMBER OF ROWS
FINS PER INCH
GENERAL FILTER SIZE (SQ.FT.)
INFORMATION DRAIN SIZE
EXPANSION DEVICE
REFRIGERANT CHARGE R-22 (oz.)
POWER SUPPLY ENTRANCE SIZE
LOW VOLTAGE ENTRANCE SIZE
SHIPPING WEIGHT LBS.
OPERATING WEIGHT LBS.
ACCESSORIES ROOFCURB - HEAT PUMP
ROOFCURB - COMBINATION
SXS TO OVER/UNDER KIT
SINGLE POINT WIRING KIT
HORIZONTAL DUCT COVER KIT
AMBIENT THERMOSTAT KIT
May 2001 (1)
Rev. 1
& Air Conditioning
®
SPECIFICATIONS
1810 Wilson Parkway • Fayetteville, TN 37334
[PHD48/PHB60]C02E
Heating & Cooling Unit
Specification Sheet
Affix this manual, Installation Instructions and
Users Information Manual adjacent to the unit.
PHD48C02E PHB60C02E
48,000 57,000
12.00 11.00
47,000 57,000
38,500 47,000
26,500 33,000
7.0 6.8
208/230-60-1 208/230-60-1
28.4 38
33.2 45.3
50 60
Scroll Scroll
19.2 28.9
137.0 148.0
1/3 1/3
1100 1100
2.4 2.4
5.8 5.8
22" / 4 22" / 4
3000 3000
12.2 12.2
2 2
18 18
ECM ECM
6.8 6.8
ECM ECM
VARIABLE VARIABLE
VARIABLE VARIABLE
10 X 8 10 X 8
1550 1750
.5"wc .5"wc
4.4 4.4
4 4
14 14
5.5 6.5
3/4 IN 3/4 IN
TXV / TXV TXV / TXV
150 150
1-1/4" 1-1/4"
3/4" 3/4"
378 383
365 370
PRC06A1 PRC06A1
PRC08A1 PRC08A1
PDTROU4A PDTROU4A
SPK08A SPK09A
CHK001A CHK001A
ATK01 ATK01
Amana
Package Heat Pump
NOTES:
1. All units are manufactured for use
on 208/230 VAC, 60 Hz, single
phase electrical supply.
2. IMPORTANT: While the data is
presented as a guide, it is required
to determine the proper size fuses
and wires to electrically connect
the unit in accordance with the
National Electrical Code and/or all
existing local codes.
3. Performance figures are based on
Department of Energy information
and requirements under continu-
ous operating conditions. Perfor-
mance will vary with weather con-
ditions and use.
20313905
