  • Page 1 Cabin Series Operating Instructions V1.0 IRay Technology Co., Ltd.

  • Page 2: Specifications

    *Actual uptime depends on the frequency of Wi-Fi use and the built-in VCR. Improvements may be made to the design and software of this product to enhance its features without prior notice to customers. This manual can be downloaded from the official InfiRay Outdoor website: www.infirayoutdoor.com.
  • Page 3 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 1. Contents of the package • Cabin Series Thermal Imager • Hand strap • Neck strap • Carrying bag • IBC-2 Power Adapter • Accumulator IBP-2 • Data output cable type C-USB-Video for video output •...

  • Page 4: Operating The Buttons

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 4. Units and controls 1. Lens cover 2. Laser indicator 3. LED light 4. Type C port 5. Power button 6. Up/Magnify button 7. Menu button 8. Down/Photos button 9.
  • Page 5 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Turn PIP on/off Home screen Magnification from 2× to 8× Local Offer/Main Up/Mag Navigation to the top Offer nify button Laser cursor Move cursor up/down calibration/faulty Quickly move the one pixel pixel calibration cursor up/down...
  • Page 6 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 6. Batteries and safety The Cabin product comes with a quick-change 18650 lithium-ion battery that allowed the device to be used for up to 7.5 hours. The battery should be fully charged before first use. Power Drawer adapter...
  • Page 7 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Remark: Two batteries can be charged simultaneously: there is a second slot for this.

  • Page 8: Security Measures

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Installing the battery unit • Lift the puller (14) on the battery pack (13), align the orange line (D) on the battery pack (13) with the orange line (C) on the Battery unit battery slot (21) and push the battery pack (13) into the battery slot (21).

  • Page 9: External Power Supply

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 • Keep the battery pack out of the reach of children. 7. External power supply The Cabin product supports external power supply such as a portable power supply (5 V). •...

  • Page 10: Installation And Use

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 8. Installation and use Switching on and operation WARNING! The lens of the Cabin product must not be pointed at any intense energy sources such as laser devices or the sun. This could damage electronic components in the device. Damage caused by failure to follow operating instructions is not covered by warranty.

  • Page 11: Digital Zoom

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 9. Calibration If the image is degraded or uneven, it can be improved by calibration. Calibration can balance the background temperature of the detector and eliminate image defects. There are three calibration modes: automatic shutter calibration (A), manual shutter calibration (M) and background calibration (B).
  • Page 12 • Switch on the device. • On the desktop, double-click "This computer". Double-click to open the device named "Infiray" . T h e s e p r o v i d e s t h a t t h e r e a s s e s s s i g n i f i c a n t " I n t e r n a t i o n a l l y "...

  • Page 13: Status Bar

    ⑧. Automatic standby (if enabled) ⑨. LED status (by default, not lit at start-up) ⑩. Clock (set in the main menu or sync the time in the InfiRay Outdoor app) ⑪. Battery unit indication (when the inside of the icon is green , it means the power is more than 20%;...
  • Page 14 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 brightness, picture sharpness and picture contrast, via the local menu.
  • Page 15 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 • From the home screen, press the Menu button (7) to access the local menu interface. • Press the Up/Magnify (6) or Down/Photo (8) button to toggle the following options. - Image mode: After selecting this option, adjust the picture mode by pressing the Menu button.
  • Page 16 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 14. Main offer • From the home screen, press and hold the Menu button (7) to open the main menu. • Press the Up/Magnify (6) or Down/Photo (8) button to toggle the menu options. •...
  • Page 17 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Enable/disable Wi-Fi • Press and hold the Menu button (7) to open the main menu. • Short press the Up/Magnify (6) or Down/Photo button Wi-Fi (8) Select Wi-Fi. • Press the Menu button (7) briefly to enable or disable Wi-Fi. •...
  • Page 18 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Calibration mode selection Cabin provides three calibration modes: automatic shutter calibration (A), manual shutter calibration (M) and background calibration (B). • Press and hold the Menu button (7) to enter the main interface Offers.
  • Page 19 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Enable/disable gravity sensor • Press and hold the Menu button (7) to access the main menu interface. • Short press the Up/Magnify (6) or Down/Photo button (8) Select Gravity Sensor. •...
  • Page 20 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 If the actual location is different from the location marked by the laser pointer, you can use this function to calibrate the laser pointer. • Press and hold the Menu button (7) to enter the main interface Offers.
  • Page 21 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 When using the Cabin product, defective pixels such as visible bright spots or dark spots with stable brightness may appear. To resolve this issue, use the Pixel Defect Calibration feature to remove the defective pixels. •...
  • Page 22 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Digital compass calibration • Press and hold the Menu button (7) to access the main menu interface. • Short press the Up/Magnify (6) or Down/Photo button (7) select Compass Calibration. •...
  • Page 23 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Setting the standby state and duration • Press and hold the Menu button (7) to enter the main menu interface. • Short press the Up/Magnify (6) or Down/Photo button (8) Select Standby settings.
  • Page 24 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Setting the system date • Press the Menu button (7) briefly to open the secondary Settings menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Date. •...
  • Page 25 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Setting the system time • Press the Menu button (7) briefly to open the secondary Settings menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Time. T h e 24-hour display is used with the hour and minute displayed.
  • Page 26 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Language selection • Press the Menu button (7) briefly to open the secondary Settings menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Language. Short press the Menu button (7) to open its secondary menu.
  • Page 27 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Enable/disable automatic state hiding • Press the Menu button briefly to open the secondary Settings menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Auto Hide Status. Short press the Menu button (7) to open its secondary menu.
  • Page 28 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 To restore the factory default settings • Press the Menu button (7) briefly to open the secondary Settings menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Factory Reset. Short press the Menu button (7) to open its secondary menu.
  • Page 29 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Enquire about equipment information • Press the Menu button (7) briefly to open the General Settings secondary menu. • Short press the Up/Magnify button (6) or Down/Photos (8), select Version Information. •...

  • Page 30: Picture In Picture (Pip)

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 15. Picture in Picture (PIP) Picture-in-Picture (PIP) provides a floating window independent of the entire screen. This window displays a portion of the image that is enlarged to 2x in a specific area centered on an intentional cross of the main image.

  • Page 31: Led Indicator

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 - Wild boar: 0,9 m high - Hare: 0.2 m tall • Adjust the device so that it is in the center of the image by pressing the Up/Magnify (6) or Down/Photo (8) button.
  • Page 32 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 the hottest object. • To stop viewing the hotspot, press and hold the Up/Magnify button (6) and the Menu button (7). 20. Automatic hiding This feature is used to hide the GUI with only the intentional cross displayed, so there is no blocking in the image.
  • Page 33 Click "Now" to download the latest version immediately or click "Later". • The InfiRay Outdoor app saves the last connected device. So once you open the app InfiRay Outdoor, automatically detects the update in the background, even when the Cabin product is not connected to a phone or tablet.
  • Page 34 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 you can d o w n l o a d it first. Once the Cabin product is connected to your mobile device, the version will be automatically updated. • After installing the update, the device reboots and starts working.

  • Page 35: Product Maintenance

    11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 23. Technical inspection Before using the equipment, perform a technical check to check the following items: • Outside of the device (no cracks on the cover) • Lens and eyepiece (free of cracks, oil, stains or other deposits) •...
  • Page 36 11th Guiyang Street, YEDA, Yantai 264006, People's Republic of China +86-400-998-3088 Adjust the focus by turning the knob The lens is out of focus. focusing the lens. The icons are clear, but Wipe the optical surface with a soft the images are blurry. There is dust or ice on the cotton cloth or allow the device to dry inside of the lens or on the...
