2.2 Transportation
2.2.1 Packaging (boxes and metallic easel)
XLINING offers two different types of packaging depending on
the size and thickness of the porcelain tile:
Stackable wooden drawers:
• Plate dimensions: for plates of various thicknesses.
• Description: used for the safe transport and storage of
the finest porcelain slabs. The drawers are designed to be
stackable up to a maximum of 9 high, facilitating efficient
storage.
• Storage data:
Plate surface area: 3.36 m² Plate weight: 54.5 kg
Weight per square meter: 16.22 kg/m²
Plates per box: 20
Weight of complete drawer: 1,090 kg
Dimensions of drawer: 145 x 292 x 35 cm
Metal trestles:
• Plate dimensions: for plates of 160x320 meters and 12 mm
thick.
• Description: used for larger and thicker plates, the metal
trestles provide a sturdy and safe support during transport.
• Storage data:
Plate surface: 5.12 m²
Plate weight: 149 kg
Weight per square meter: 29.10 kg/m²
Sheets per ridge: 22
Weight of complete stand: 3.458 kg
Dimensions of stand: 75 x 330 x 201 cm
Storage and transportation considerations:
• Plate distribution: smaller plates should never be placed
between larger plates. This avoids possible damage during
transport and storage.
• Adequate support: the trestles must be able to support the
entire surface of the plates. Make sure that the plates are
fully supported.
• Use of straps: the straps used to secure the sheets should
not be excessively tightened.
• Excessive pressure can break parts, compromising the
integrity of the product.
• When installing the straps, cardboard or plastic corner
pieces should be placed on the sharp edges to prevent
breakage of the straps, which could cause the sheets to fall.
5
This information ensures that XLINING porcelain slabs are
transported and stored safely, minimizing the risk of damage
and facilitating efficient handling of the product.
2.2.2. Arrangement of large-format porcelain
tile slabs on the truck
Transportation of large format porcelain tile slabs requires
careful planning to ensure the integrity of the material during
transport. The following are the best practices for arranging the
slabs on the truck:
Truck preparation
• Vehicle inspection:
Verify that the truck is in good condition and clean.
Make sure that the floor of the truck is flat and free of
elements that could cause damage.
• Weight distribution:
Distribute the weight evenly to avoid imbalances that
may cause problems during transport.
Plate loading
• Stackable wooden drawers::
Horizontal position: place the wooden crates in a
vertical position, ensuring that they are well aligned
and supported.
Spacing: leave a small space between the drawers to
avoid friction during movement.
Fastening: use straps and straps to securely fasten
the crates to the truck, preventing movement during
transit.
• Metal trestles:
Position and fastening: the metal trestles must be
positioned so that the plates are well supported. Make
sure that the trestles arefirmly fixed to the floor of the
truck.
Additional protection: place protective materials such
as foam or blankets between the trestles and the truck
walls to prevent lateral movement and damage.
Fastening: use straps and straps to securely fasten
the crates to the truck, preventing movement during
transit.
Specific considerations
• Different sized plates:
Spacing: Never place small plates between large
plates. This could cause damage due to uneven
pressure.
Loading sequence: load the larger plates first and,
if necessary, place the smaller plates last, always
ensuring that they are adequately supported.
