- Page 1 How to Remove and Replace New Housing from Open frame Parts - Model: GOPW2380HB3 to Chassis mount housing. i-Tech Company LLC EMAIL: info@itechlcd.com • WEB: www.iTechLCD.com Modified: 02-22-22...
- Page 2 Parts...
- Page 3 Steps of removing parts(1/3): Coastline • Remove the orange area first • 1. light sensor (can be unscrewed by hands) • 2. RS232 (remove via Hexagon screwdriver 5m/m) • 3. AD board (remove via Hexagon screwdriver 5m/m)
- Page 4 Steps of removing parts(2/3): AC power wires • There are only two cables need to loosen: L cable and N cable from power modules.
- Page 5 Steps of removing parts(3/3): Loosen the all screws • Loosen the all screws from the mechanism. • Please note that there are two types of screws, one is black and one is sliver. The two cannot be exchanged. be exchanged.
- Page 6 Steps of fixing parts (1/3) : • Put back all the parts/PCBs and tighten all screws on the new mechanism.
- Page 7 Steps of fixing parts (2/3) : • 1. Connect L to L wire first (color: black) • 2. Connect N to N wire (color: white) • If there’s any hesitation please take pictures and contact iTech for help.
- Page 8 Steps of fixing parts(3/3): Coastline • Put back the orange area...
- Page 9 • END...
