Installation Manual

DUAL FUEL RANGES

CDR & SDR MODELS

www.zlinekitchen.com

Table of Contents

Need help?

Do you have a question about the CDR and is the answer not in the manual?

Questions and answers

Summary of Contents for Zline CDR

Page 1 Installation Manual DUAL FUEL RANGES CDR & SDR MODELS www.zlinekitchen.com...
Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
Page 4 This page left intentionally blank.
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 Gas Safety ........1 Electric and Gas Safety .
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS GAS SAFETY WARNING: If the information in these instructions is not followed exactly, a fire WARNING or explosion may result causing property damage, personal injury or death. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 7 IMPORTANT SAFETY INSTRUCTIONS AVERTISSEMENT : Le non-respect à la lettre de ces instructions peut causer AVERTISSEMENT un incendie ou une explosion, qui pourrait entraîner des dommages matériels, desblessures ou la mort • Ne pas entreposer ou utiliser d’essence ou tout autre liquide ou gaz inflammable à...
Page 8 IMPORTANT SAFETY INSTRUCTIONS WARNING: WARNING Never Operate the Top Surface Cooking Section of this Appliance Unattended. • Failure to follow this warning statement could result in fire, explosion, or burn hazard that could cause property damage, personal injury, or death. •...
Page 9 IMPORTANT SAFETY INSTRUCTIONS WARNING: Never use this appliance as a space heater to heat or warm the room. Doing so may result in carbon monoxide poisoning WARNING and overheating. Never use the top of the range or the interior of the oven as a storage areas, as items could melt or ignite, increasing the risk of fire, damage, and/or serious injury.
Page 10 IMPORTANT SAFETY INSTRUCTIONS • Before beginning installation, please read and follow these important instructions for the safety of your home and the people living in it. • The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation, improper use of the appliance, or failure to heed the warnings listed.
Page 11: Electric And Gas Safety
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY ALERTS DANGER: When you see this symbol in the instructions, it indicates a hazardous situation which, if not avoided, could result in death or serious injury. DANGER WARNING: When you see this symbol in the instructions, it indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Page 12: Installation Safety
IMPORTANT SAFETY INSTRUCTIONS Installation and service on this product must be performed by a qualified installer, servicer, or gas supplier. Ask the manufacturer to recommend a WARNING qualified technician and authorized repair service in your area. • Know how to shut off gas supply at the meter and disconnect the electrical power to the appliance at the circuit breaker or fuse box in case of an emergency.
Page 13: State Of California Proposition 65 Warnings
IMPORTANT SAFETY INSTRUCTIONS • If the appliance is used intensively for a long time, the effectiveness of the ventilation will have to be increased, for example by opening a window or increasing the power of the range hood operating above. •...
Page 14: Cooktop Safety
IMPORTANT SAFETY INSTRUCTIONS COOKTOP SAFETY DANGER • Do not store items of interest to children in the cabinets above the appliance or on the back splash of appliance. • Children should not be left alone or unattended in the area where the appliance is in use. Do not allow children to climb, play, sit, or stand on or around any part of the appliance.
Page 15 IMPORTANT SAFETY INSTRUCTIONS • Pot/pan handles should be turned inward and not extend over surface burners. To reduce the risk of burns, ignition of flammable materials, and spillage due to unintentional contact with the pot/pan, the handle of the utensil should be positioned so that it is turned inward, and does not extend over adjacent surface burners.
Page 16: Ventilation Safety
IMPORTANT SAFETY INSTRUCTIONS VENTILATION SAFETY WARNING • The appliance should have proper ventilation in order to keep the unit operating properly and maintain the temperature of immediate surroundings. Do not obstruct flow of combustion and ventilation air. • Observe all governing codes and ordinances, and check your local building codes as they may vary from the general rules outlined in this manual.
Page 17: Before Installation
28–31, as well as additional gas supply requirements on page 15. • Reference the diagram on page 13 for the appropriate locations for gas and electrical hookups. Electrical cord length for all CDR and SDR series ranges and sizes is 3 feet — 36" (914 mm).
Page 18: Dimensions And Clearances
BEFORE INSTALLATION DIMENSIONS AND CLEARANCES Cooking Range Side View Front View 30"–36" (762–914 mm) 13" to bottom of (330 mm) 18" ventilation hood 27 5/16" (457 mm) (694 mm) opening width 37 1/2"–39" (953–991 mm) to cooking surface gas and electric 4 1/2"...
Page 19: Gas Supply And Electrical Connection
BEFORE INSTALLATION GAS SUPPLY AND ELECTRICAL CONNECTION GAS SAFETY Explosion hazard conditions will exist unless you perform ALL of the following; failure to do so can result in death, explosion, or fire. DANGER • Use a new CSA International approved gas supply line. •...
Page 20: Natural Gas
BEFORE INSTALLATION GAS SUPPLY NATURAL GAS: • This appliance is designed for use with natural gas or, after proper conversion, for use with liquid propane gas. • This appliance is factory set for use with natural gas. The model/serial rating plate has information on the types of gas that can be used.
Page 21: Gas Connections
BEFORE INSTALLATION GAS CONNECTIONS • IMPORTANT: Do not apply pressure directly to the appliance manifold pipe when tightening supply connections. The manifold pipe should be held securely at the pressure regulator to prevent twisting. Hold the pressure regulator with a wrench during tightening, or the manifold pipe may be twisted and split and cause a dangerous leak.
Page 22: Electrical Supply
BEFORE INSTALLATION ELECTRICAL SUPPLY ELECTRIC SHOCK HAZARD DANGER • Failure to follow these instructions can result in death, fire, or electrical shock. • Any additions, changes, or conversions required to properly operate this appliance must be made by a qualified service technician in accordance with the manufacturer’s instructions and all codes and requirements of the local governing authority.
Page 23: Additional Parts
BEFORE INSTALLATION TOOLS NEEDED (INCLUDED) • Allen wrench / hex key (for handle installation) TOOLS AND ADDITIONAL PARTS NEEDED (NOT INCLUDED) • Tape measure • Phillips-head screwdriver • Flat blade screwdriver • 1/8" (3 mm) flat blade screwdriver • Hex screwdriver •...
Page 24: Product Specifications
BEFORE INSTALLATION PRODUCT SPECIFICATIONS CDR30/SDR30 SERIES RANGES 27 5/16" (694 mm) 30" (763 mm) 24 3/8" (619 mm) 7 1/2" (190 mm) 33 1/4" (844 mm) 20 1/8" (511 mm) 4 5/16" (110 mm) 2 3/4" (70 mm) to 4 1/4" (108 mm) CDR36/SDR36 SERIES RANGES 27 5/16"...
Page 25 BEFORE INSTALLATION RECOMMENDED CABINET CUT-OUT DIMENSIONS • CDR30/SDR30 Series Ranges: 30 1/4" W x 24 3/4" D x 36" H 768 mm W x 629 mm D x 914 mm H • CDR36/SDR36 Series Ranges: 36 1/4" W x 24 3/4" D x 36" H 921 mm W x 629 mm D x 914 mm H •...
Page 26: Pre-Installation Specifications And Instructions
BEFORE INSTALLATION PRE-INSTALLATION SPECIFICATIONS AND INSTRUCTIONS • Before beginning installation, please carefully read and follow the important safety precautions on pages 1–1 1. • Safety instructions pertaining to each step have been outlined in the installation steps; however it is important to read all the safety instructions. •...
Page 27: Installation
INSTALLATION TIPPING SAFETY DANGER ANTI-TIP DEVICE. • TIPPING RANGES CAN CAUSE SERIOUS PERSONAL INJURY OR DEATH. e foot is under anti-tip bracket. • TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE SECURED WITH A PROPERLY INSTALLED ANTI-TIP DEVICE. es, the anti-tip device has not been installed correctly.
Page 28 INSTALLATION • Ensure the anti-tip device is re-engaged when the range is moved by following the same steps outlined above and on page 41. • Carefully pull on the range from the rear. If the brackets are installed correctly, the range will not tip more than 4"...
Page 29: Installing Parts
INSTALLATION INSTALLING PARTS BURNER SPREADS AND CAPS • After unpacking the range, set the cast iron grates aside and remove the burner spreads and caps from the parts storage location under the grates. • Place each spread on the appropriate burner by making sure the hole fits over the white metal electrode spark tip.
Page 30 SIM setting for melting chocolate and butter, cooking rice and delicate sauces, simmering soups and stews, and keeping cooked food hot. Never leave the appliance unattended when in use. over, make sure you clean the affected burners before Boil over causes smoking and greasy spills that may using them again.
Page 31 INSTALLATION CDR48/SDR48 SERIES RANGE KNOBS (10 TOTAL) The oven knobs go on the 2 middle single valves, with the small oven knob on the left. Individual burner knobs go on each side. One dual function knob goes immediately left of the small oven burner, and the other goes on the far right side of the range.
Page 32: Installing The Handle
INSTALLATION INSTALLING THE HANDLE • To install the handle on the oven door, place each handle bracket onto the pre-installed mounting studs located at both sides of the oven door, as outlined below in the left image below. • Once the handle is secured, locate the screw holes on the underside of each handle bracket base.
Page 33: Gas Connection
INSTALLATION GAS CONNECTION • While ranges come factory ready to operate on natural gas (NG), the appliance can be converted for use on liquid propane gas (LPG). When using this range on liquid propane gas, the conversion must be made by a qualified installer before attempting to operate the range top on that gas.
Page 34: Explosion Hazards
INSTALLATION GAS CONNECTION (CONTINUED) EXPLOSION HAZARDS WARNING • Please read ALL safety precautions on pages 1–1 1 before beginning installation. • Only use a CSA-approved gas supply line. • You must install an approved manual shut-off valve. • Securely tighten all gas connections. •...
Page 35: Installation
INSTALLATION Only connect the gas line through the 1/2" fitting on the side of the pressure regulator, as outlined in the diagram on the following page. DO NOT attempt WARNING to connect gas by removing the regulator access cap — the regulator access cap is only used for liquid propane conversions and must stay on at all times.
Page 36 1/2 psig (3.5 kPa). CDR36/SDR36 models • The below figure demonstrates the proper gas hook-up flow for all CDR and SDR series ranges and sizes. The pressure regulator is located at the bottom right corner when facing CDR48/SDR48 models the unit (bottom left corner when facing it from behind).
Page 37: Liquid Propane Gas Conversion Procedure (Optional)
INSTALLATION LIQUID PROPANE GAS CONVERSION PROCEDURE (OPTIONAL) CAUTION: The gas supply shall be shut off prior to disconnecting the electrical power, before proceeding with the conversion. CAUTION CAUTION: Before proceeding with the conversion, shut off the gas supply to the appliance prior to disconnecting the electrical power.
Page 38 INSTALLATION LIQUID PROPANE CONVERSION (CONTINUED) WARNING WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.
Page 39 1/2 PSI (14" W.C.P / 3.5 kPa). If the line pressure is in excess of that amount, a step- up regulator will be required. For all CDR/SDR range models and sizes, do not perform the pressure test on the dual function burners, as this will not allow for proper results. Only perform CAUTION the test on one of the burners on the far left side of the range top.
Page 40 kit for converting to LP gas is supplied with your appliance. property damage. The conversion must be performed by a qualiﬁed service technician in accordance with the kit instruc- INSTALLATION WARNINGS: tions and all local codes and requirements. Failure Reverse the r et to follow instructions could result in serious injury or pages 4 to 10.
Page 41 Installation INSTALLATION Installation Unscr ew the regulator cap with a wrench (see Figure Installation pane) Unscr ew the regulator cap with a wrench (see Figure LIQUID PROPANE CONVERSION (CONTINUED) etainer pin by pulling it out (see Figure 10). Optional) Unscr ew the regulator cap with a wrench (see Figure pane) CDR30/SDR30 and ore Step 6 if converting to Propane)
Page 42 INSTALLATION Installation STEP 5 (Continued) LIQUID PROPANE CONVERSION (CONTINUED) Gas Conversion CHANGING BURNER ORIFICES Changing Burner Nozzles WARNING: • After removing the burner grates, burner caps, and burner spreads, use a 7mm nut Save the natural gas oriﬁces removed from the INSTALLATION TIP: To prevent any omissions, remove ALL existing Natural Gas nozzles before appliance for possible future conversions to natural...
Page 43 INSTALLATION LIQUID PROPANE CONVERSION (CONTINUED) Installation ORIFICE NUMBERS STEP 5 (Continued) Gas Conversion INSTALLATION TIP: To prevent any mistakes during the conversion, remove ALL existing Changing Burner Nozzles Installation natural gas orifices first before replacing them with the LPG orifices. Installation INSTALLATION TIP: To prevent any omissions, remove ALL existing Natural Gas nozzles before...
Page 44 Installation Installation Installation STEP 5 (Continued) INSTALLATION STEP 5 (Continued) STEP 5 (Continued) Gas Conversion Gas Conversion Gas Conversion Changing Burner Nozzles Changing Burner Nozzles INSTALLATION TIP: To prevent any omissions, Changing Burner Nozzles remove ALL existing Natural Gas nozzles before LIQUID PROPANE CONVERSION (CONTINUED) replacing them with the LP nozzles.
Page 45 30” 1.79 1.16 0.94 1.36 INSTALLATION Broil 1.42 0.94 Oven 2.13 Installation Installation Figure 15A Installation STEP 5 (Continued) STEP 5 (Continued) LIQUID PROPANE CONVERSION (CONTINUED) STEP 5 (Continued) Gas Conversion Gas Conversion 0.94 Gas Conversion Changing Burner Nozzles IMPORTANT: Install the proper orifice in the exact locations as noted in the illustrations and Changing Burner Nozzles INSTALLATION TIP: To prevent any omissions, Burner...
Page 46: Installing The Anti-Tip Device
INSTALLATION INSTALLING THE ANTI-TIP DEVICE A child or adult can tip the range and be seriously injured or killed. Do not operate the range without the anti-tip device in place. Failure to follow these DANGER instructions can result in death or serious burns to children and adults. Scan to follow along with a video.
Page 47: Finish Installation
INSTALLATION FINISH INSTALLATION 1. After your gas connection and anti-tip brackets are properly installed, plug the range’s NEMA 14-50 electrical cord into a properly grounded 4-prong outlet. The electrical socket must be easily accessible with the appliance installed. In all cases, the power supply lead must be positioned so that it does not reach a WARNING temperature of 122 °F (50 °C) above the room temperature at any point.
Page 48: Warranty
Products must be unobstructed and accessible to the service provider at the time of service. ZLINE’s liability is limited to the original purchase price of the product. Additional injuries, losses, damages, or other inconveniences caused by product malfunction or defects in materials are not covered under the terms of this warranty.
Page 49 If a product qualifies within the service window provided under these warranty terms, and ZLINE is unable to repair the product or a defective part of the product after a reasonable number of attempts, ZLINE reserves the right to offer to replace the defective part or the...
Page 50 Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help.
Page 51: Serial Number Location
ﬁlled out per product speciﬁcs. This is a template. Once the artwork is approved for this sticker, please apply the template to all stickers and send the artwork to the ZLINE Team for review. Thank you!
