Multibrackets M Pro Series Installation Manual page 6

Dimensions
EAN: 7350105213373
Past list
A2 A3
A1
M5X15 M6X15
M8X25
X4 X4 X4
B1 B2 B3
3mm 5mm 6mm
X1 X1 X1
D1
2700mm
X3
D7
(1000mmx3+480mmx1)X3
X12
6
3490mm [137.4"]
1200mm [47.2"]
1356.4mm [53.4"]
A4
A5
6X 6.2X1.5 M8X45
X4 X4
B4 B5 B6
M8X10
M8 M8
X1
X74 X37 X37
D2
1200mm
X2
D8
X9 X6
www.multibrackets.com
A6 A7
3X 8.2X13
6X 8.2X1.5
X4 X4
C1 C2/C3 C4
M8X10 M8X45
X25 X12 X8
D3 D4
1000mm
X3
D9 D10
X36
Ø8.2mm [Ø0.3"]
X9
X1
D5
4''
X9 X3
D11 D12
X18 X6
187.8mm [7.4"]
±4°
1064mm [41.2"]
D6
4''
X3
D13
X6
