3Com SuperStack 3C17300 Implementation Manual page 61

Figure 15 Example CLI screen text
*** WARNING: Unit 1 Failure detected
*** Select individual unit 'system summary? Command for details
Menu options: --------------3Com Superstack 3 Switch 4200---------------
bridge
gettingStarted
logout
physicalInterface
protocol
security
system
trafficManagement
Type ? For help
-------------------------------(1)-----------------------------------
Select menu option: system summary
Figure 16 Example of an individual unit system summary screen
Select menu option (system): Summary
3Com Superstack 3
System Name
Location
Contact
Time Since Reset
Operational Version
Hardware Version
Boot version
Mac Address
Product Number
Serial Number
Device Status
Select menu option
Via the web.
On the Web interface, an indication of a general hardware failure will
be provided through the top-level System Summary information
screen. You should refer to the detailed Device Summary Web page,
see Figure 17.
Hardware Status Monitoring
- Administer bridge-wide parameters
- Basic device configuration
- Logout of the Command Line Interface
- Administer physical interfaces
- Administer protocols
- Administer security
- Administer sytem-level functions
- Administer traffic management
:
:
:
: 0 Hrs 0 Mins 6 Seconds
:
:
:
: 08:00:4e:01:02:00
: 3C17300/3C17302
: 7TSV0010200
: Fan Failed
(system) :
