Rapid Spanning Tree
Protocol (RSTP)

What is STP?

R F
ESILIENCE EATURES
The protocol is a part of the IEEE 802.1D bridge specification. To explain
STP more effectively, your Switch will be referred to as a bridge.
The Rapid Spanning Tree (RSTP) is an enhanced Spanning Tree feature.
RSTP implements the Spanning Tree Algorithm and Protocol, as defined in
the IEEE 802.1w standard. RSTP is enabled by default.
3Com recommends that you use the Rapid Spanning Tree Protocol
feature (enabled by default) to provide optimum performance for your
network and ease of use.
Some of the benefits of RSTP are:
Faster determination of the Active Spanning Tree topology throughout
a bridged network.
Support for bridges with more than 256 ports.
Support for Fast-Forwarding configuration of edge ports provided by
the 'Fast Start' feature. Fast Start allows a port that is connected to an
endstation to begin forwarding traffic after only four seconds. During
these four seconds RSTP (or STP) will detect any misconfiguration that
may cause a temporary loop and react accordingly.
If you have Fast Start disabled on a port, the Switch will wait for 30
seconds before RSTP (or STP) lets the port forward traffic.
Easy deployment throughout a legacy network, through backward
compatibility:
it will default to sending 802.1D style BPDU's on a port if it receives
packets of this format.
it is possible for some ports on a Switch to operate in RSTP
(802.1w) mode, and other ports, for example those connected to a
legacy Switch, to operate in STP (802.1D) mode.
you have an option to force your Switch to use the legacy 802.1D
version of Spanning Tree, if required.
STP is a bridge-based system that allows you to implement parallel paths
for network traffic and uses a loop-detection process to:
Find and disable the less efficient paths (that is, the paths that have a
lower bandwidth).
