- Page 1 AIW-162BS-GI1 User manual...
- Page 2 Applicability Type AIW PN Description WNFB- 802.11ax/ac/a/b/g/n Industrial Grade 2T2R Wi- AIW-162BS-GI1 265AXI(BT) Fi+Bluetooth 5.0 Combo M.2 2230 Module...
- Page 3 Revision History Version Owner Date Description V0.9 Joejohn.Chen 2023-08-30 First issue V0.91 Joejohn.Chen 2023-11-28 Add description of pin definition Change model name from EWM-W183M201E V0.92 Joejohn.Chen 2024-01-29 to AIW-162BS-001 based on latest naming rule Change model name from AIW-162BS-001 to V0.93 Joejohn.Chen 2024-03-20 AIW-162BS-GI1...
-
Page 4: Product Introduction
1 Product Introduction Item Description IEEE 802.11ax/ac/a/b/g/n (2T2R) Standard Bluetooth V5.0, 4.2, V4.1, V4.0LE, V3.0+HS, V2.1+EDR Chipset solution Broadcom AP6275P 802.11b: 11Mbps 802.11a/g: 54Mbps 802.11n: MCS0~15 Data Rate 802.11ac: MCS0~9 802.11ax: HE0~11 Bluetooth: 1 Mbps, 2Mbps and Up to 3Mbps IEEE 802.11ax/ac/a/b/g/n Operating Frequency ISM Band, 2.412GHz~2.484GHz, 5.150GHz~5.850GHz... - Page 5 Item Description 802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM) 802.11ac: OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256- QAM) 802.11ax: OFDMA (BPSK, QPSK, 16-QAM, 64-QAM, 256- QAM, 1024-QAM) Modulation Header: GFSK Payload 2M: π/4-DQPSK Payload 3M: 8-DPSK TX mode: 660 mA (Max) Power Consumption RX mode: 201 mA (Max) Operating Voltage DC 3.3V...
- Page 6 2 Output Power & Sensitivity 2.1 Wi-Fi 802.11b Data Rate Tx ± 2dBm Rx Sensitivity ≦-88dBm 11Mbps 18.5dBm 802.11g Data Rate Tx ± 2dBm Rx Sensitivity ≦-77dBm 54Mbps 12dBm 802.11n / 2.4GHz Tx ± 2dBm Tx ± 2dBm Data Rate Rx Sensitivity (1TX) (2TX)
- Page 7 802.11ac Tx ± 2dBm Tx ± 2dBm Data Rate Rx Sensitivity (1TX) (2TX) VHT80 ≦-57dBm MCS9 9dBm 12dBm 802.11ax / 5 GHz Tx ± 2dBm Tx ± 2dBm Data Rate Rx Sensitivity (1TX) (2TX) HE20 ≦-69dBm 13.5dBm 16.5dBm ≦-68dBm HE40 11dBm 14dBm ≦-60dBm...
-
Page 8: Hardware Specification
3 Hardware Specification 3.1 Mechanical Dimension Dimension (L x W x H): 30 mm (Tolerance:±0.15mm) x 22 mm (Tolerance:±0.15mm) x 2.2 mm (Tolerance:±0.3mm) Figure 3-1: Hardware Dimension... - Page 9 3.2 MHF4 connector spec Figure 3-2: MHF4 connector spec...
-
Page 10: Block Diagram
3.3 Block Diagram Figure 3-3: Block Diagram... -
Page 11: Pin Assignment
3.4 Pin Assignment... - Page 12 The following section illustrate signal pin-outs for the module connector. ⚫ Top Side Pin Pin Name Type Description Ground connections USB_D+ No Connection USB_D- No Connection Ground connections SDIO_CLK/SYSCLK (1.8V) No Connection SDIO_CMD(1.8V) No Connection SDIO_DATA0(1.8V) No Connection SDIO_DATA1 (1.8V) No Connection SDIO_DATA2(1.8V) No Connection...
- Page 13 Pin Name Type Description Ground connections PETp0 PCI Express transmit data-Positive PETn0 PCI Express transmit data-Negative Ground connections REFCLKp0 PCI Express differential clock input-Positive REFCLKn0 PCI Express differential clock input-Negative Ground connections CLKREQ0#(3.3V) PCIe clock request PEWAKE0# PCIe PME Wake(1.8V) Ground connections RESERVED/PERp1 No Connection...
- Page 14 ⚫ Bottom Side Pin Name Type Description 3.3V VDD system power supply input 3.3V VDD system power supply input LED_1# No function PCM_CLK/I2S_SCK(1.8V) PCM clock PCM_SYNC/I2S_WS(1.8V) PCM sync signal PCM_OUT/I2S_SD_OUT(1.8V) PCM Data output PCM_IN/I2S_SD_IN(1.8V) PCM data input LED_2# No connection Ground connections BT_HOST-WKAE#(1.8V) UART_WAKE#...
- Page 16 Pin Pin Name Type Description COEX3 No Connection COEX_TXD No Connection COEX_RXD No Connection SUSCLK No Connecton PERST0#(3.3V) PCIe host indication to reset the device BT_REG_ON(3.3V) Used by PMU to power up or power down W_DISABLE2#(3.3V) the internal module regulators used by the Bluetooth section.
