Summary of Contents for TRENDnet TEG-S081FMI

  • Page 2 MAC address on an 8K-entry MAC address table. Figure 1-1. The TEG-S081FMi Switch The Switch provides 8 100Mbps Fiber ports and one GBIC slot for optional GBIC modules. The fiber ports are 100Base-SC type multi-mode fiber ports support up to 2kms distance.

  • Page 3: Intelligent Management Features

    Web-based management SNMP network management Console and Telnet management Port Base VLAN and IEEE 802.1q Tag VLAN, and VLAN group up to 256 , VLAN ID up to 4K IEEE 802.3 ad port trunk with LACP (Link Aggregation Control protocol) supported IEEE 802.1d Spanning Tree...

  • Page 4: Package Contents

    Package Contents Unpack the contents of the TEG-S081FMi Switch and verify them against the checklist below. Switch Power Cord Four Rubber Feet RS-232 cable User Guide TEG-S081FMi Switch Power Cord Rubber Feet RS-232 cable User Guide Figure 1-2. Package Contents Compare the contents of your TEG-S081FMi switch package with the standard checklist above.

  • Page 5: Console And Telnet Management

    Managing the TEG-S081FMi Switch in this method requires a direct connection between PC and the TEG-S081FMi Switch. While Telnet management is done over the network. Once the TEG-S081FMi Switch is on the network, you can use Telnet to Log in and change the configuration. Web-based Management The Switch provides an embedded HTML web site residing in flash memory.

  • Page 6: Hardware Description

    Hardware Description Front Panel The Front Panel of the Fiber Management Switch series consist of 8x 100Mbps Fast Ethernet Fiber and GBIC ports, and the LED indicators are also located on the frond panel of the switch. Figure 2-1. The Front Panel of the Fiber Management Switch Console Port : Console management can be done through the Console Port.

  • Page 7: Led Indicators

    GBIC port : It only support 3.3V model Gigabit Transceiver for Gigabit SX or LX. LED Indicators Figure 2-3. LED Indicators There are three LED-Indicators (LNK/ACT, FDX/COL ) for each Fiber port. The following table provides descriptions of the LED statuses and meaning.

  • Page 8: Rear Panel

    AC in the range 100-240V AC, 50-60Hz. Power on/off switch AC Power Plug Socket Figure 2-7 The Rear Panel of the 8 Port 100Mbps Fiber plus one GBIC Management Switch Desktop Installation Set the switch on a sufficiently large flat space with a power outlet nearby.

  • Page 9: Network Application

    Network Application This section provides you a few samples of network topology in which the Switch is used. In general, the TEG-S081FMi Switch is designed to be used as a desktop or segment switch. Segment Application For enterprise networks where large data broadcast are constantly processed, this switch is suitable for department user to connect to the corporate backbone.
  • Page 10 The Switch automatically learns node address, which are subsequently used to filter and forward all traffic based on the destination address. You can use any of the Fiber port of the Fiber Management Switch to connect with another Switch or Hub to interconnect each of your small switched workgroups to form a larger and long distance switched network.

  • Page 11: Network Configuration

    Management Switch. Console management involves the administration of the Switch via a direct connection to the RS-232 console port. This port is a female DB-9 connector. From the main menu of the console program, user has access to manage the functions of the Switch.

  • Page 12: Console - Menu

    Console Port Information provide by web to use windows HyperTerminal program to link the switch. 2. You can type user name and password to login. The default user name is “root”, the default password is “root ”.
  • Page 13 Status and Counters: Show the status of the switch. Switch Static Configuration: Configure the switch. Protocol Related Configuration: Configure the protocol function. Reboot Switch: Restart the system or reset switch to default configuration. Logout: Exit the menu line program. <Control Key>...

  • Page 14: Port Status

    Enabled: Display the port is enabled or disable depended on user setting. Enable will be display “Yes”, disable will be display “No”. Status: Display the port is link or no link, “Down” is no link, and “Up” is link. Mode: Display the port speed and duplex.

  • Page 15: Port Counters

    Actions-> You can press the key of Tab or Backspace to choose action menu, and press Enter key to select item <Quit>: Exit the page of port status, and return to previous menu. 4-2-2. Port Counters The following information provides a view of the current status of the unit.

  • Page 16: System Information

    Actions-> You can press the key of Tab or Backspace to choose action menu, and press Enter key to select item <Quit>: Exit the page of port status, and return to previous menu. <Reset All>: Set all count to 0.

  • Page 17: Switch Static Configuration

    4-3. Switch Static Configuration You can press the key of Tab or Backspace to choose item, and press Enter key to select item...

  • Page 18: Administration Configuration

    This page provide user to configure the device information. Actions-> <Edit>: Configure all items. Finished configure press BackSpace to go back action menu line. <Save>: Save all configure value. <Quit>: Exit the page of device information and return to previous menu.
  • Page 19 4-3-1-2. IP Configuration User can configure the IP setting and fill in the new value. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. <Quit>: Exit the page of IP configuration and return to previous menu.

  • Page 20: Change Username

    Note: Always restart the computer after finishing the setup. 4-3-1-3. Change Username Use this page; user can change web management user name.

  • Page 21: Change Password

    1.Enabled: User can disable or enable this port control, but port 9 always is enabled, can’t be disable. 2.Auto Negotiate: port 1 to 8 (100Mbps Fiber) is disabled, port 9 ( GBIC port) is enabled. 3.Speed/Duplex Config: For port 1 to 8 ( 100 Mbps Fiber port)only can set Full or Half duplex , Port 9 ( GBIC port ) support 1000Mbps Full Duplex.

  • Page 22: Port Mirroring Configuration

    2. Analysis Port: It’s mean mirror port can be used to see all monitor port traffic. 3. Port: The ports you want to monitor. All monitor port traffic will be copied to sinffer port. You can select max 9 monitor ports in the switch. User can choose want to monitored RX frames only or TX frames only or both RX and TX frame from the port at Action item.
  • Page 23 Actions-> <Quit>: Exit the page of port monitoring configuration and return to previous menu. <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value.

  • Page 24: Vlan Configuration

    4-3-4. VLAN Configuration 4-3-4-1. VLAN Configure 1. PVID (Port VID): Set the port VLAN ID that will be assigned to untagged traffic on a given port. This feature is useful for accommodating devices that you want to participate in the VLAN but that don’t support tagging. Only one untagged VLAN is allowed per port.

  • Page 25: Create A Vlan Group

    2. VLAN ID: Type a VID (between 1~4094). The default is 1. 3. Protocol VLAN: Press Space key to choose protocols type. 4. Mode: Press Space key to choose VLAN member. There are three types to selected as 802.1Q, 802.1Q with GVRP and Port-Base UnTagged: the member port is un-tagged port.

  • Page 26: Edit / Delete A Vlan Group

    In this page, user can edit or delete a VLAN group. 1. Press <Edit> or <Delete> item. 2. Choose the VLAN group that you want to edit or delete and then press enter. 3. User can modify the protocol VLAN item and the member port is tagged or un-tagged and remove some member ports from this VLAN group.

  • Page 27: Priority Configuration

    4-3-5. Priority Configuration 1. There are 0~7 priority level can map to high or low queue. 2. High/Low Queue Service Ration: User can select the ratio of high priority packets and low priority packets. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action...

  • Page 28: Mac Address Configuration

    These options represent the number of high priority packets sent before one low priority packet is sent. For example, 2 High : 1 Low means that the switch sends 2 high priority packets before sending 1 low priority packet.
  • Page 29 In this page user can add / modify / delete a static MAC address. Add static MAC address 1. Press <Add> --> <Edit> key to add a static MAC or edit address. 2. Enter the MAC address to and from which the port should permanently forward traffic, regardless of the device’s network activity.

  • Page 30: Filtering Mac Address

    VLANs. Type the VID to associate with the MAC address. 5. Press ESC to go back action menu line, and then select <Save> to save all configure value. Edit static MAC address 1. Press <Edit> key to modify a static MAC address.

  • Page 31: Misc Configuration

    2. Choose the MAC address that you want to modify and then press enter. 3. Press <Edit> key to modify all the items. 4. Press ESC to go back action menu line, and then select <Save> to save all configure value.

  • Page 32: Mac Age Interval

    1. Press <Edit> to enable or disable the port security. 2. Press Space key to choose enable / disable item. 3. Press ESC to go back action menu line, and then select <Save> to save all configure value. 4-3-7-2.MAC Age Interval Type the number of seconds that an inactive MAC address remains in the switch’s address table.

  • Page 33: Broadcast Storm Filtering

    <Quit>: Exit this page and return to previous menu. 4-3-7-3.Broadcast Storm Filtering This page is configuring broadcast storm control, press <Edit> to configure the broadcast storm filter mode. Press Space key to choose the threshold value. The valid threshold value are 5%, 10%,15%,20%,25% and NO.

  • Page 34: Max Bridge Transmit Delay Bound

    Max bridge transmit delay bound (0,1-4 sec): Limit the packets queuing time in switch. If enable, the packets queued exceed will be drop. Press Space key to set the time. These valid values are 1sec, 2sec, 4sec and off. Default is 1 seconds.

  • Page 35: Protocol Related Configuration

    NOTE: Make sure of “Max bridge transit delay bound control” is enabled before enable Delay Bound, because Enable Delay Bound must be work under “Max bridge transit delay bound control is enabled” situation. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line.
  • Page 36 4-4-1-1.STP Enable This page is enable or disable Spanning Tree function. Press Space key to select enable or disable.

  • Page 37: System Configuration

    4-4-1-2.System Configuration 1. You can view spanning tree information about the Root Bridge on the left. 2. On the right, user can setting new value for STP parameter. You must enable STP function, then can select configuration menu.

  • Page 38: Perport Configuration

    If you change the value, you need to restart the switch for valid value. 3. Priority: This is mean port priority, you can make it more or less likely to become the root port. If you change the value, you need to restart the switch for valid value.

  • Page 40: System Options

    4-4-2-1.System Options Press <Edit> to enter all items, and then press <Save> to save configure value. 1. System Name: Type a name to be used for the switch. 2. System Contact: Type the name of contact person or organization. 3. System Location: Type the location of the switch.

  • Page 41: Trap Managers

    A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a community string.
  • Page 42 Actions-> <Add>: Create a trap manager. <Edit>: Modify all items. Finished configure press ESC to go back action menu line. <Delete>: Delete a trap manager. After delete item press <Save> to complete the deleting operation. <Save>: Save all configure value.
  • Page 43 Actions-> <Edit>: Configure all items. Press Space key to choose Enable or Disabled mode. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. <Quit>: Exit this page and return to previous menu.

  • Page 44: Aggregator Setting

    Control Protocol) support. If enable, the group is LACP static trunking group. If disable, the group is local static trunking group. 3. LACP Work Port Num: The max number of ports can be aggregated at the same time. If LACP static trunking group, the exceed ports is standby and able to aggregate if work ports fail.
  • Page 45 Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. <Quit>: Exit this page and return to previous menu.

  • Page 46: State Activity

    Active: The port automatically sends LACP protocol packets. Passive: The port does not automatically sends LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line.

  • Page 47: Reboot Switch

    Actions-> <Quit>: Exit this page and return to previous menu. 4-5.Reboot Switch Default: Reset switch to default configuration. Restart: Reboot the switch in software reset.
  • Page 48 Note: It may make the system setting parameter error that execut Default command and power off without wait consol appear "$$$ Press X key to start Xmodem receiver:” message if. Regarding this issue, user must wait console appear that message then can shut down power.
  • Page 49 3.Select “send file" under "transfer" menu from menu bar. 4.Press "browse" button to select the path. 5.Select "1K Xmodem" of protocol and press "Send" button. 6.After successfully upgraded the new firmware, please modify baud rate to 9600bps.

  • Page 51: Web-Based Management

    Web Management Function 1. Web Management Function provides a Web browser to manage and monitor the switch, the default values as follows: If you need change IP address in first time, you can use console mode to modify it. IP Address: 192.168.16.1...

  • Page 52: Port Status

    5-2. Port status 1. port status State: Display port status off or on depended on user setting. “unlink” will be treated as “off ”. Link Status: Down is “No Link”, UP is “Link” Auto Negotiation: auto negotiation mode Speed status: Display link speed, Port 1- 8 is 100Mbps, Port 9 is 1000Mbps.

  • Page 54: Port Statistics

    5-3. Port Statistics 1. The following information provides a view of the current status of the unit. 5-4. Administrator Those management functions include: IP address, Switch settings, Console port information, Port controls Link aggregation, Filter database, VLAN configuration ,Spanning Tree, Port Mirror, SNMP, Security Manager, TFTP Update Firmware...
  • Page 55 5-4-1. IP Address 1. User can configure the IP Settings and fill in the new value, than clicks apply button. 2. User must be reset switch and use new IP address to browser this web management. Default IP:192.168.16.1 Subnetmask:255.255.255.0 Gateway:192.168.16.254...

  • Page 56: Switch Setting

    5-4-2. Switch Setting 5-4-2-1.Basic 1. Description: Display the name of device type. 2. MAC Address: The unique hardware address assigned by manufacturer (default) 3. Firmware Version: Display the switch’s firmware version. 4. Hardware Version: Display the switch’s Hardware version. 5. Kernel version: Display write to default EEPROM value...
  • Page 57 300~765 seconds. Default is 300 seconds. Max bridge transit delay bound control: Limit the packets queuing time in switch. If enable, the packets queued exceed will be drop. This valid value are 1sec, 2 sec, 4 sec and off. Default is 1 seconds.
  • Page 58 These options represent the number of high priority packets sent before one low priority packet is sent. For example, 2 High :1 Low means that the switch sends 2 high priority packets before sending 1 low priority packet.
  • Page 59 Enable Delay Bound: Limit the low priority packets queuing time in switch. Default Max Delay Time is 255ms. If the low priority packet stays in switch exceed Max Delay Time, it will be sent. The valid range is 1~255 ms.
  • Page 60 802.1Q(Tag VLAN) with GVRP VLAN mode Port Based Also, three kind of typologies shown as below indicate how the IGMP Query work within a network: 1. This topology has to be set for when the router’s IP address is smaller than other Switch in subnet.
  • Page 61 2. This topology has to be set for when the router’s IP address is not smaller than other Switch in subnet. Note: This Router supports IGMP protocol, but IGMP has to be in enable mode, and the Router has to be the Queryer.

  • Page 62: Console Port Information

    Note: Suggest VOD server set with Switch has smallest IP address. 4. All of Switch must be in Disable mode, When VOD server is set up for IGMP Queryer. GVRP (GARP [Generic Attribute Registration Protocol] VLAN Registration Protocol) GVRP allows automatic VLAN configuration between the switch and nodes.

  • Page 63: Port Controls

    1. This page can Change every port status State: User can disable or enable port 1-8, port 9 always enable. Auto Negotiation: Port 1-8 is fixed to disable mode, and port 9 is enabled. Speed setting: The speed mode is fixed. 100Mbps (1-8 port) , 1000Mbps...

  • Page 64: Aggregator Setting

    5-4-5. Trunk The Port Trunk provides a standardized means for exchanging information Between Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner.
  • Page 65 3. Work ports:The max number of ports can be aggregated at the same time. If LACP static trunking group, the exceed ports is standby and able to agreate if work ports fail. If local static trunking group, the number must be the same as group ports.

  • Page 66: Aggregator Information

    LACP protocol packets from the opposite device. 1. A link having either two active LACP ports or one active port can perform dynamic LACP trunking. A link has two passive LACP ports will not perform dynamic LACP trunking because both ports are waiting for and LACP protocol packet from the opposite device.

  • Page 67: Filter Database

    The TEG-S081FMi Switchsupport IP multicast , you can enable IGMP protocol on web management’s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group ,VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.

  • Page 68: Static Mac Address

    Query response from each host belonging to the multicast group. A message sent by a host to the querier to indicate that the host wants to be Report or is a member of a given group indicated in the report message.

  • Page 69: Port Security

    User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port. Enter the settings, then click Submit to apply the changes on this page.
  • Page 70 Ethernet frames. Tag contains a VLAN Identifier (VID) that indicates the VLAN numbers. Support Protocol-based VLAN In order for an end station to send packets to different VLANs, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a...

  • Page 71: Port Vid

    From the main Tag-based (IEEE 802.1Q) VLAN page, click Port VID Settings. Port VID (PVID) Sets the Port VLAN ID that will be assigned to untagged traffic on a given port. For example, if port 9's Default PVID is 100, all untagged packets on port 9...

  • Page 72: Spanning Tree

    The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. You can enable Spanning-Tree Protocol on web management’s switch setting advanced item, select enable Spanning-Tree protocol.
  • Page 73 Prameter Description You can change priority value, A value used to identify the root bridge. The Priority bridge with the lowest value has the highest priority and is selected as the root. Enter a number 1 through 65535.
  • Page 74 3. The following parameter can be configured on each port , click set Apply button to modify . Paramet Description You can make it more or less likely to become the root port, the rage is Port 0-255,default setting is 128 Priority the lowest number has the highest priority.

  • Page 75: Port Mirror

    Mirror Ports: The ports you want to mirror. All mirror port traffic will be copied to mirror port. You can select max 9 monitor ports in the switch. If you want to disable the function, you must select monitor port to none.
  • Page 76 Read write: Enables requests accompanied by this string to display MIB-object information and to set MIB objects. 3. Trap Manager A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are...

  • Page 77: Security Manager

    Create a trap manager by entering the IP address of the station and a community string. 5-4-11.Security Manager 1. Use this page, user can change web management user name and password. User name: root (default) Password: root (default)

  • Page 78: Tftp Update Firmware

    * Download new image.bin file then in web management press <update firmware>. 5-4-13. Configuration Backup 5-4-13-1. TFTP Restore Configuration Use this page to set TFTP server address. You can restore EEPROM value from here, but you must put back image in TFTP server, switch will download back flash image.

  • Page 79: Tftp Backup Configuration

    5-4-13-2. TFTP Backup Configuration Use this page to set TFTP server IP address. You can save current EEPROM value from here, then go to the TFTP restore configuration page to restore the EEPROM value. 5-4-14. Reset System Reset Switch to default configuration...
  • Page 80 5-4-15. Reboot Reboot the Switch in software reset.

  • Page 81: Technical Specifications

    Technical Specifications This section provides the specifications of 8 port Fiber plus GBIC Management Switch series, and the following table lists these specifications. Specifications Standards IEEE 802.3u 100Base- FX Fast Ethernet Compliance IEEE 802.3z Gigabit Fiber Protocol CSMA/CD Max Forwarding...

  • Page 82: Troubleshooting

    External Power 100-240V AC, 50-60Hz Troubleshooting This section is intended to help you solve the most common problems on the TEG-S081FMi Switch. Incorrect connections Faulty or loose cables Look for loose or obviously faulty connections. If they appear to be OK, make sure the connections are snug.

  • Page 83: Diagnosing Led Indicators

    IF the power indicator does not turn on when the power cord is plugged in, you may have a problem with power outlet, or power cord. However, if the Switch powers off after running for a while, check for loose power connections, power losses or surges at power outlet.

  • Page 84: Limited Warranty

    Limited Warranty TRENDware warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. TEG-S081FMi– 5 Years Warranty If a product does not operate as warranted above during the applicable...
  • Page 85 OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE. Governing Law: This Limited Warranty shall be governed by the laws of the state of California. AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 Year Warranty...
