  • Page 2 Introduction The TEG-S081Fi Switch is compact desktop size switches which are ideal solutions for Fiber network infrastructure. It provides wire-speed, Fast Ethernet switching function that allows high-performance, low-cost connection. The Switch features a store-and-forward switching and it can auto-learn and MAC address on an 8K-entry MAC address table.

  • Page 3: Intelligent Management Features

    Conforms to IEEE802.3u, IEEE802.3z and IEEE802.3x Ethernet Standards 8x 100Base-FX SC Type Fiber ports and one GBIC slot One Console port on the front side for switch Configuration Half-duplex mode for backpressure, and Full-duplex for flow control Store-and-forward switching architecture...

  • Page 4: Package Contents

    Package Contents Unpack the contents of the TEG-S081Fi Switch and verify them against the checklist below. Switch Power Cord Four Rubber Feet RS-232 cable User Guide TEG-S081Fi Switch Rubber Feet Figure 1-2. Package Contents Compare the contents of your TEG-S081Fi switch package with the standard checklist above.

  • Page 5: Console And Telnet Management

    Console and Telnet Management Console Management is done through the RS-232 Console Port. Managing the TEG-S081Fi Switch in this method requires a direct connection between PC and the TEG-S081Fi Switch. While Telnet management is done over the network. Once the TEG-S081Fi Switch is on the network, you can use Telnet to Log in and change the configuration.

  • Page 6: Hardware Description

    (PC ) via a RS-232 cable. Console Port Baud Rate: 9600,N,8,1 Figure 2-2. The Front Panel of the TEG-S081Fi Switch with SC connector 100Base-FX Fiber Port: There are 2 types of fiber connectors available for the TEG-S081Fi Switchas shown above.

  • Page 7: Led Indicators

    GBIC port : It only support 3.3V model Gigabit Transceiver for Gigabit SX or LX. LED Indicators Figure 2-3. LED Indicators There are three LED-Indicators (LNK/ACT, FDX/COL ) for each Fiber port. The following table provides descriptions of the LED statuses and meaning.

  • Page 8: Rear Panel

    Rear Panel The Console port and 3-pronged power plug are located at the Rear Panel of the TEG-S081Fi Switch as shown in Figure 2-8. The Switches will work with AC in the range 100-240V AC, 50-60Hz. Figure 2-7 The Rear Panel of the 8 Port 100Mbps Fiber plus one...

  • Page 9: Network Application

    Network Application This section provides you a few samples of network topology in which the Switch is used. In general, the TEG-S081Fi Switch is designed to be used as a desktop or segment switch. Segment Application For enterprise networks where large data broadcast are constantly processed, this switch is suitable for department user to connect to the corporate backbone.
  • Page 10 You can use any of the Fiber port of the Fiber Management Switch to connect with another Switch or Hub to interconnect each of your small switched workgroups to form a larger and long distance switched network. Figure 3-3 Use fiber port (TEG-S081Fi Switch) to extend the distance between workgroups...

  • Page 11: Network Configuration

    The terminal or PC to be connected must support the terminal emulation program. After the connection between Switch and PC is finished, turn on the PC and run a terminal emulation program or Hyper Terminal to match the following default characteristics of the console port:...

  • Page 12: Console - Menu

    Main Menu of console management appears. Console – Menu 1. The switch also provide a serial interface to manage and monitor the switch, user can follow the Console Port Information provide by web to use windows HyperTerminal program to link the switch.

  • Page 13: Status And Counters

    Reboot Switch: Restart the system or reset switch to default configuration. Logout: Exit the menu line program. <Control Key> The control key as follow provided in all menus: Tab: Move the vernier to next item. Backspace: Move the vernier to previous item.

  • Page 14: Port Counters

    Actions-> You can press the key of Tab or Backspace to choose action menu, and press Enter key to select item <Quit>: Exit the page of port status, and return to previous menu. 4-2-2. Port Counters The following information provides a view of the current status of the unit.

  • Page 15: System Information

    System Description: Display the name of device type. MAC Address: The unique hardware address assigned by manufacturer. Firmware Version: Display the switch’s firmware version. Hardware Version: Display the switch’s Hardware version. Kernel version: Display write to default EEPROM value version.

  • Page 16: Switch Static Configuration

    4-3. Switch Static Configuration You can press the key of Tab or Backspace to choose item, and press Enter key to select item 4-3-1. Administration Configuration...

  • Page 17: Device Information

    4-3-1-1. Device Information This page provide user to configure the device information. Actions-> <Edit>: Configure all items. Finished configure press BackSpace to go back action menu line. <Save>: Save all configure value. <Quit>: Exit the page of device information and return to previous menu. 4-3-1-2.
  • Page 18 Note: Always restart the computer after finishing the setup. 4-3-1-3. Change Username Use this page; user can change web management user name.

  • Page 19: Port / Trunk Configuration

    4-3-1-4. Change Password Use this page; user can change web management user password. The default password is root 4-3-2. Port / Trunk Configuration This page can change every port status and configure trunk group. Press TAB key to change configure of per item. 1.Enabled: User can disable or enable this port control, but port 9 always is enabled, can’t be disable.

  • Page 20: Port Mirroring Configuration

    3. Port: The ports you want to monitor. All monitor port traffic will be copied to sinffer port. You can select max 9 monitor ports in the switch. User can choose want to monitored RX frames only or TX frames only or...

  • Page 21: Vlan Configuration

    Actions-> <Quit>: Exit the page of port monitoring configuration and return to previous menu. <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. 4-3-4. VLAN Configuration 4-3-4-1. VLAN Configure 1. PVID (Port VID): Set the port VLAN ID that will be assigned to untagged traffic on a given port.

  • Page 22: Create A Vlan Group

    devices that you want to participate in the VLAN but that don’t support tagging. Only one untagged VLAN is allowed per port. 2. Ingress Filter 1: It matches that Ingress Filtering Rule 1 on web. Forward only packets with VID matching this port’s configured VID. Press Space key to choose forward or drop the frame that VID not matching this port’s configured VID.
  • Page 23 Actions-> <Quit>: Exit this page and return to previous menu. <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. 4-3-4-3. Edit / Delete a VLAN Group In this page, user can edit or delete a VLAN group. 1.

  • Page 24: Priority Configuration

    4-3-5. Priority Configuration 1. There are 0~7 priority level can map to high or low queue. 2. High/Low Queue Service Ration: User can select the ratio of high priority packets and low priority packets. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line.

  • Page 25: Mac Address Configuration

    4-3-6.MAC Address Configuration 4-3-6-1.Static MAC Address When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 26 3. In the Port num item, enter the port number. 4. If tag-based(802.1Q) VLAN are set up on the switch, static addresses are associated with individual VLANs. Type the VID to associate with the MAC address.

  • Page 27: Filtering Mac Address

    Edit static MAC address 1. Press <Edit> key to modify a static MAC address. 2. Choose the MAC address that you want to modify and then press enter. 3. Press <Edit> key to modify all the items. 4. Press ESC to go back action menu line, and then select <Save> to save all configure value.

  • Page 28: Misc Configuration

    Delete Filtering MAC address 1. Press <Delete> key to delete a Filtering MAC address. 2. Choose the MAC address that you want to delete and then press enter. 3. After delete Filtering MAC address, you have to press <Save> to complete the deleting operation.

  • Page 29: Mac Age Interval

    3. Press ESC to go back action menu line, and then select <Save> to save all configure value. 4-3-7-2.MAC Age Interval Type the number of seconds that an inactive MAC address remains in the switch’s address table. The valid range is 300~765 seconds. Default is 300 seconds.

  • Page 30: Broadcast Storm Filtering

    Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. <Quit>: Exit this page and return to previous menu. 4-3-7-3.Broadcast Storm Filtering This page is configuring broadcast storm control, press <Edit> to configure the broadcast storm filter mode.

  • Page 31: Max Bridge Transmit Delay Bound

    Default is 1 seconds. Enable Delay Bound: Limit the low priority packets queuing time in switch. If enable, the low priority packet stays in switch exceed Max Delay Time, it will be sent. Press Space key to enable or disable this function.

  • Page 32: Protocol Related Configuration

    4-4.Protocol Related Configuration 4-4-1.STP 4-4-1-1.STP Enable This page is enable or disable Spanning Tree function. Press Space key to select enable or disable.

  • Page 33: System Configuration

    4-4-1-2.System Configuration 1. You can view spanning tree information about the Root Bridge on the left. 2. On the right, user can setting new value for STP parameter. You must enable STP function, then can select configuration menu. 4-4-1-3.Perport Configuration...
  • Page 34 1. PortState: You can view spanning tree status about the switch for per port. 2. PathCost: Specifies the path cost of the port that switch uses to determine which port are the forwarding ports. If you change the value, you need to restart the switch for valid value.

  • Page 35: System Options

    Press <Edit> to enter all items, and then press <Save> to save configure value. 1. System Name: Type a name to be used for the switch. 2. System Contact: Type the name of contact person or organization. 3. System Location: Type the location of the switch.

  • Page 36: Trap Managers

    4-4-2-3.Trap Managers A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station...
  • Page 37 Actions-> <Add>: Create a trap manager. <Edit>: Modify all items. Finished configure press ESC to go back action menu line. <Delete>: Delete a trap manager. After delete item press <Save> to complete the deleting operation. <Save>: Save all configure value. <Quit>: Exit this page and return to previous menu.
  • Page 38 Actions-> <Edit>: Configure all items. Press Space key to choose Enable or Disabled mode. Finished configure press ESC to go back action menu line. <Save>: Save all configure value. <Quit>: Exit this page and return to previous menu. 4-4-4.LACP...

  • Page 39: Aggregator Setting

    4-4-4-1.Aggregator Setting 1. Group: Display the trunk group ID. 2. LACP: Press Space key to enable or disable LACP (Link Aggregation Control Protocol) support. If enable, the group is LACP static trunking group. If disable, the group is local static trunking group. 3.

  • Page 40: State Activity

    4-4-4-2.State Activity Active: The port automatically sends LACP protocol packets. Passive: The port does not automatically sends LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. Actions-> <Edit>: Configure all items. Finished configure press ESC to go back action menu line.

  • Page 41: Reboot Switch

    Actions-> <Quit>: Exit this page and return to previous menu. 4-5.Reboot Switch Default: Reset switch to default configuration. Restart: Reboot the switch in software reset.
  • Page 42 Note: It may make the system setting parameter error that execut Default command and power off without wait consol appear "$$$ Press X key to start Xmodem receiver:” message if. Regarding this issue, user must wait console appear that message then can shut down power. Note: RS-232 Local console firmware upgrade (X modem ) 1.Press X key to start upgrading for Xmodem.
  • Page 43 6.After successfully upgraded the new firmware, please modify baud rate to 9600bps.

  • Page 44: Web-Based Management

    Web-Based Management Web Management Function 1. Web Management Function provides a Web browser to manage and monitor the switch, the default values as follows: If you need change IP address in first time, you can use console mode to modify it.

  • Page 45: Port Status

    5-2. Port status 1. port status State: Display port status off or on depended on user setting. “unlink” will be treated as “off ”. Link Status: Down is “No Link”, UP is “Link” Auto Negotiation: auto negotiation mode Speed status: Display link speed, Port 1- 8 is 100Mbps, Port 9 is 1000Mbps.

  • Page 47: Port Statistics

    1. The following information provides a view of the current status of the unit. 5-4. Administrator Those management functions include: IP address, Switch settings, Console port information, Port controls Link aggregation, Filter database, VLAN configuration ,Spanning Tree, Port Mirror, SNMP, Security Manager, TFTP Update Firmware Configuration Backup, Reset system and Reboot.
  • Page 48 5-4-1. IP Address 1. User can configure the IP Settings and fill in the new value, than clicks apply button. 2. User must be reset switch and use new IP address to browser this web management. Default IP:192.168.16.1 Subnetmask:255.255.255.0 Gateway:192.168.16.254...

  • Page 49: Switch Setting

    5-4-2-1.Basic 1. Description: Display the name of device type. 2. MAC Address: The unique hardware address assigned by manufacturer (default) 3. Firmware Version: Display the switch’s firmware version. 4. Hardware Version: Display the switch’s Hardware version. 5. Kernel version: Display write to default EEPROM value...
  • Page 50 300~765 seconds. Default is 300 seconds. Max bridge transit delay bound control: Limit the packets queuing time in switch. If enable, the packets queued exceed will be drop. This valid value are 1sec, 2 sec, 4 sec and off. Default is 1 seconds.
  • Page 51 Enable Delay Bound: Limit the low priority packets queuing time in switch. Default Max Delay Time is 255ms. If the low priority packet stays in switch exceed Max Delay Time, it will be sent. The valid range is 1~255 ms.
  • Page 52 Queryer will be the first priority, they are three mode as follow: 1. Auto Mode: Choose the indicated Switch, which has the smallest IP address will be set for the IGMP Queryer. 2. Enable Mode: Enable one of Switch to be the IGMP Queryer.
  • Page 53 Note: This Router supports IGMP protocol, but IGMP has to be in enable mode, and the Router has to be the Queryer. 3. This topology must be set for when the Switch’s IP address is not the smallest in the subnet. If in Auto mode, the network will cause multi-cast storm from the client IGMP report, the topology shown as below is necessary to be set for.

  • Page 54: Console Port Information

    Note: Suggest VOD server set with Switch has smallest IP address. 4. All of Switch must be in Disable mode, When VOD server is set up for IGMP Queryer. GVRP (GARP [Generic Attribute Registration Protocol] VLAN Registration Protocol) GVRP allows automatic VLAN configuration between the switch and nodes.

  • Page 55: Port Controls

    5-4-4. Port Controls 1. This page can Change every port status State: User can disable or enable port 1-8, port 9 always enable. Auto Negotiation: Port 1-8 is fixed to disable mode, and port 9 is enabled. Speed setting: The speed mode is fixed. 100Mbps (1-8 port) , 1000Mbps (GBIC port) Duplex setting: port 1-8 support Full or Half Duplex, port 9 only support Full Duplex.
  • Page 56 LACP operation requires full-duplex mode, more detail information refer to IEEE 802.3ad. 5-4-5-1. Aggregator setting System Priority: A value used to identify the active LACP. The switch with the lowest value has the highest priority and is selected as the active LACP.
  • Page 57 1.Group ID: you can create a link aggregation across two or more ports, choose the "group id" and click "Get". 2.LACP: If enable, the group is LACP static trunking group. If disable, the group is local static trunking group. All ports support LACP dynamic trunking group. If connecting to the device that also supports LACP, the LACP dynamic trunking group will be created automatically.

  • Page 58: Aggregator Information

    5-4-5-2. Aggregator Information When you are setting LACP aggregator, you can see relation information in here. 5-4-5-3. State Activity Active (select): The port automatically sends LACP protocol packets. Passive (no select): The port does not automatically sends LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device.

  • Page 59: Filter Database

    5-4-6. Filter Database 5-4-6-1. IGMP Snooping The TEG-S081Fi Switchsupport IP multicast , you can enable IGMP protocol on web management’s switch setting advanced page, then display the IGMP snooping information in this page, you can view difference multicast group ,VID and member port in here, IP multicast addresses range from 224.0.0.0 through 239.255.255.255.

  • Page 60: Static Mac Address

    Message A message sent from the querier (IGMP router or switch) asking for a Query response from each host belonging to the multicast group. A message sent by a host to the querier to indicate that the host wants to be Report or is a member of a given group indicated in the report message.

  • Page 61: Port Security

    5. If tag-based (IEEE 802.1Q) VLANs are set up on the switch, static addresses are associated with individual VLANs. Type the VID (tag-based VLANs) to associate with the MAC address. 6. Click add 5-4-6-3. Port Security A port in security mode will be “locked” without permission of address learning.
  • Page 62 Layer 2 switch. However, all the network devices are still plug into the same switch physically. The TEG-S081Fi Switchsupport port-based and protocol-base VLAN in web management page. NOTE: The default VLAN can’t be deleted.
  • Page 63 2. Click Add 3. Type a name for the new VLAN. 4. Type a VID (between 2-4094). The default is 1. 5. From the Available ports box, select ports to add to the switch and click Add. 6. Click Apply 5-4-7-2.

  • Page 64: Spanning Tree

    Ingress Filtering Ingress filtering lets frames belonging to a specific VLAN to be forwarded if the port belongs to that VLAN. TEG-S081Fi Switchhave two ingress filtering rule as follows: Ingress Filtering Rule 1: Forward only packets with VID matching this port's configured VID.
  • Page 65 1. You can view spanning tree information about the Root Bridge. Such as follow screen. 2. You can view spanning tree status about the switch. Such as below screen. Prameter You can change priority value, A value used to identify the root bridge. The...

  • Page 66: Port Mirror

    0-255,default setting is 128 Priority the lowest number has the highest priority. If you change the value, you must reboot the switch. Specifies the path cost of the port that switch uses to determine which Path port are the forwarding ports Cost the lowest number is default value base on IEEE802.1D...
  • Page 67 Mirror Ports: The ports you want to mirror. All mirror port traffic will be copied to mirror port. You can select max 9 monitor ports in the switch. If you want to disable the function, you must select monitor port to none.
  • Page 68 3. Trap Manager A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station...

  • Page 69: Tftp Update Firmware

    1. Use this page, user can change web management user name and password. User name: root (default) Password: root (default) 5-4-12. TFTP Update Firmware 1. The following menu options provide some system control functions to allow a user to update firmware and remote boot switch system: * Executing TFTP software...

  • Page 70: Tftp Restore Configuration

    5-4-13. Configuration Backup 5-4-13-1. TFTP Restore Configuration Use this page to set TFTP server address. You can restore EEPROM value from here, but you must put back image in TFTP server, switch will download back flash image. 5-4-13-2. TFTP Backup Configuration Use this page to set TFTP server IP address.

  • Page 71: Reset System

    5-4-14. Reset System Reset Switch to default configuration 5-4-15. Reboot Reboot the Switch in software reset.

  • Page 72: Technical Specifications

    Technical Specifications This section provides the specifications of 8 port Fiber plus GBIC Management Switch series, and the following table lists these specifications. Specifications Standards IEEE 802.3u 100Base- FX Fast Ethernet Compliance IEEE 802.3z Gigabit Fiber Protocol CSMA/CD Max Forwarding...

  • Page 73: Troubleshooting

    Troubleshooting This section is intended to help you solve the most common problems on the TEG-S081Fi Switch. Incorrect connections Faulty or loose cables Look for loose or obviously faulty connections. If they appear to be OK, make sure the connections are snug. IF that does not correct the problem, try a different cable.

  • Page 74: Diagnosing Led Indicators

    IF the power indicator does not turn on when the power cord is plugged in, you may have a problem with power outlet, or power cord. However, if the Switch powers off after running for a while, check for loose power connections, power losses or surges at power outlet. IF you still cannot resolve the problem, contact your local dealer for assistance.

  • Page 75: Limited Warranty

    TEG-S081Fi– 5 Years Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDware shall, at its option and expense, repair the...
  • Page 76 WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OTHERWISE, INCLUDING WARRANTIES MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDWARE NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDWARE’S PRODUCTS.
