Hoymiles HRSD-1C User Manual

Rapid shutdown
Hide thumbs Also See for HRSD-1C:
Table of Contents

Advertisement

Quick Links

Download this manual
Open Energy for All
Rapid Shutdown
USER MANUAL
HRSD-1C
HT10
HT10-Kit
Region: Global V202404
hoymiles.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRSD-1C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoymiles HRSD-1C

Summary of Contents for Hoymiles HRSD-1C

  • Page 1 Open Energy for All Rapid Shutdown USER MANUAL HRSD-1C HT10 HT10-Kit Region: Global V202404 hoymiles.com...

  • Page 2: Legal Notice

    However, the content of this manual is continually reviewed and amended, due to product enhancements or feedback from real-world usage. Hoymiles retains the right to modify this manual without prior notice at any time. Please refer to Hoymiles official website at www.hoymiles.com...

  • Page 3: Using This Manual

    • Updated illustrations in 5.1, 5.2, and of "5. Installation" • Added "6. Troubleshooting" • Updated "7. Technical Specifications“ • Added "3. Hoymiles Rapid Shutdown System" V202404 • Updated "7.2 HT10" © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 4: Table Of Contents

    4.2 Routing Instruction 5. Installation 5.1 HRSD-1C 5.2 HT10 5.3 HT10-Kit 5.4 Recommended Conduit Drilling Guide 6. Troubleshooting 6.1 Terminology 6.2 Troubleshooting Guide 7. Technical Specifications 7.1 HRSD-1C 7.2 HT10 7.3 HT10-Kit © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 5: Safety Information

    • To install the HRSD, connect the input cables to the PV module first, and then connect the HRSD output cables in series. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 6 • Recommended Max. number of strings connected to the HRSD: 30 modules • Hoymiles recommends that the Transmitter power supply be on the same AC branch circuit as the inverter to meet rapid shutdown requirements. • During the PV system operation, check that the Power LED 1 is lit and the Signal LED 2 is blinking.

  • Page 7: Products

    Rapid Shutdown User Manual 2. Products 2.1 HRSD-1C Appearance IP68 / NEMA6P Output Output Input Input Mounting Brackets © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 8 Able to avoid crosstalk with special communication modulation technique As part of Hoymiles Rapid Shutdown Solution for the PV system, HRSD-1C is connected with one module. It meets NEC 2017, NEC 2020, UL 1741 and SunSpec Rapid Shutdown requirements, guaranteeing PV system safety.

  • Page 9: Ht10

    Power Input (+12 V) Power Input (GND) INITIATOR - INITIATOR + LED 2 LED 1 LED 2 CORE 2 Port CORE 1 Port 150 A Core 1 150 A Core 2 © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 10 • Achieves rapid shutdown through Transmitter power-off or external initiation As part of Hoymiles Rapid Shutdown solution, Hoymiles Transmitter HT10 works with HRSD for module- level rapid shutdown. When powered on, the HT10 uses PLC technology to continuously send a “permission to operate” signal to HRSD, enabling the PV system to start producing power.

  • Page 11: Ht10-Kit

    DC OK LED 1 LED 2 CORE 2 Port CORE 1 Port PE L2 L1 150 A Core 1 150 A Core 2 [A] Transmitter HT10 [B] 180-550 VAC DIN Rail PSU © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 12 Equipped with single- / three-phase power supply As part of Hoymiles Rapid Shutdown solution, the HT10-Kit is designed to work with HRSD for rapid shutdown at the module level. The kit comprises one HT10 (available in single or dual Core), one single- or three-phase power supply, and an outdoor enclosure.

  • Page 13: Hoymiles Rapid Shutdown System

    Inverter IMPORTANCE • Hoymiles recommends that the Transmitter power supply be on the same AC branch circuit as the inverter to meet rapid shutdown requirements. When energized, the Transmitter constantly sends a “permission to operate” signal to the HRSD-1C, which receives the signal and turns ON and allows full PV module voltage.

  • Page 14: Initiation Methods

    The figures above are intended for working principle illustration only. They do not serve as wiring references. 3.2 Initiation Methods Hoymiles Rapid Shutdown System can be initiated in two ways—1) turning off the AC breaker and 2) pressing the external emergency stop button.
  • Page 15 Serially connect the NC contacts (1 and 2) of the emergency stop button to the live wire (L) of the upstream AC cable. NOTICE The AC circuit should be 220V 6A or 380V 4A. • • The emergency stop button should be installed at an accessible location. © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 16: Cable Length And Routing

    HRSD-1C input cable: 0.3 m (0.98 ft.) PV Module output cable ≥ 1.3 m (4.27 ft.) * The proportions of the HRSDs have been modified to improve the depiction of the structure. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 17 HRSD-1C input cable: 0.3 m (0.98 ft.) PV Module output cable ≥ 1.3 m (4.27 ft.) * The proportions of the HRSDs have been modified to improve the depiction of the structure. © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 18: Routing Instruction

    PV 1 + PV 2 + Cable Transmitter No. 9 Tray PV 8 - PV 9 - PV 8 + PV 9 + Number of Transmitter ≤ 9 PV arrays and HRSDs © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 19: Installation

    NOTICE • Cables of the HRSD inputs and the PV module outputs cannot be extended. • HRSD-1C output voltage is 0.9 V to 1.1 V when the Transmitter “permission to operate” signal is not present. IMPORTANCE • Max. cable length from inverter (+) to inverter (-): 800 m (2625 ft.) •...
  • Page 20 Connect the PV modules to the HRSD-1C. IP68 / NEMA6P IP68 / NEMA6P HRSD inputs Click ! PV module outputs Step 3 Connect the HRSD-1C outputs in series. IP68 / NEMA6P IP68 / NEMA6P © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 21: Ht10

    • Improper installation may lead to HT10 damage, which is not covered under warranty. • Hoymiles recommends that Transmitter power supply be on the same AC branch circuit as the inverter to meet rapid shutdown requirements. • Place rapid shutdown system sticker no more than 1m (3 ft.) from the Transmitter or AC disconnect.
  • Page 22 PV 1 - PV 2+ PV 2 + PV 2 - PV 2 - PV 1 + PV 1 + PV 2 - PV 3 - PV 1 - PV 4 + © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 23 Step 5 Connect the serially connected outputs of the HRSDs to the inverter with a DC cable. GRID Step 6 Power on the Transmitter to activate the “permission to operate” signal. © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 24: Ht10-Kit

    • Improper installation may lead to HT10-Kit damage, which is not covered under warranty. • Hoymiles recommends that the Transmitter power supply be on the same AC branch circuit as the inverter to meet rapid shutdown requirements. • Place rapid shutdown system sticker no more than 1m (3 ft.) from the Transmitter or AC disconnect.
  • Page 25 *Either positive or negative homerun runs through the Core. -V +V DC OK *Either positive or negative homerun runs through the Core. *AC Wires for PSU PE L2 L1 © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 26 Connect the serially connected outputs of the HRSDs to the inverter with a DC cable. GRID -V +V DC OK PE L2 L1 Step 7 Power on the Transmitter to activate the “permission to operate” signal. © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 27: Recommended Conduit Drilling Guide

    Rapid Shutdown User Manual 5.4 Recommended Conduit Drilling Guide © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 28: Troubleshooting

    The cable length (the PV+ to PV- loop of each PV string) does not exceed 800 m (2625 ft.). • The homeruns passing through the Core are of the same polarity, either all positive or all negative. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 29 HRSD with a multimeter. If the output voltage is still 0 V, there is an internal malfunction in the HRSD. Contact Hoymiles technical support team to replace the HRSD. © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 30: Technical Specifications

    *1: The former matches PV module output cables of 1.3 m (4.27 ft.) at minimum, and the latter matches those of 0.2 m (0.66 ft.) at minimum. 2: Fits PV module in portrait installation. Contact Hoymiles if horizontal installation is needed.

  • Page 31: Ht10

    Voltage: 12 VDC (+/-2%) Power Standby: 0.2 W Duty Cycle: 16% Max. Power: 3W Unit : mm / inch 36.5 / 1.44 Transmitter Core-150 A Core-75 A © 2024 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 32: Ht10-Kit

    Unit : mm / inch 32 / 1.26 36.5 / 1.44 18 / 0.71 -V +V DC OK PE L2 L1 Transmitter Power Supply Power Supply Core-150 A Core-75 A (85-277 V) (180-550 V) © 2024 Hoymiles Power Electronics Inc. All rights reserved.
