Summary of Contents for Hoymiles HRSD-1C
- Page 1 Open Energy for All Rapid Shutdown USER MANUAL HRSD-1C HT10 HT10-Kit Region: Global V202205 hoymiles.com...
-
Page 2: Table Of Contents
1.3 HT10-Kit 2. System Overview 3. Installation Notes 4. Installation 4.1 HRSD-1C Installation 4.2 HT10 Installation 4.3 HT10-Kit Installation 4.4 Conduit Drilling Guide 5. Technical Specifiications 5.1 HRSD-1C 5.2 HT10 5.3 HT10-Kit © 2022 Hoymiles Power Electronics Inc. All rights reserved. - Page 3 • Do not attempt to install in inclement weather. • Be aware that the body of the running HRSD-1C is the heat sink and can reach high temperatures. To reduce the risk of burns, do not touch the body of the HRSD-1C.
-
Page 4: Products
• Much lower than arc noise. No risk of triggering AFCI As part of Hoymiles rapid shutdown solution for PV system, HRSD-1C can be connected with one module. It meets NEC2017, NEC 2020, UL 1741 and Sunspec Rapid Shutdown requirements, guaranteeing PV system safety. -
Page 5: Ht10
• Realize rapid shutdown by simply powering off the transmitter or using an external initiator The Transmitter HT10 is part of Hoymiles Rapid Shutdown solution. When paired with Hoymiles rapid shutdown HRSD and powered on, HT10 sends a “permission to operate” signal to HRSD, to make PV modules connected in series and then connect to string inverter, thus producing power. -
Page 6: Ht10-Kit
• Weatherproof outdoor enclosure • Includes power supply Hoymiles Transmitter HT10-Kit is part of a rapid shutdown solution when paired with Hoymiles rapid shutdown HRSD. While powered on, HT10-Kit sends a “permission to operate” signal to HRSD to keep the PV modules connected in series to the string inverter and producing power. -
Page 7: System Overview
The Transmitter is installed in line with a solar PV inverter. The HRSD-1C starst in the OFF position and measures 1V at the output. When power is supplied to the Transmitter, the HRSD-1C turns ON and allows full PV module voltage. The HRSD-1C constantly receives a “permission to operate”... -
Page 8: Installation Notes
• If parallel string connections are needed, first connect the HRSD-1C to the PV modules, then connect all outputs of HRSD-1C in series, and finally pass one side (+ or -) of the string through the transmitter to turn the system ON. -
Page 9: Installation
Mounting Brackets Method 1 (Recommended) Allow a minimum of 1.5 cm of space between the roof and the HRSD-1C enclosure to ensure ventilation and heat dissipation Method 2 Allow a minimum of 1.5 cm of space between the roof and the HRSD-1C enclosure to ensure ventilation and heat dissipation... - Page 10 Rapid Shutdown User Manual B ). Connect modules to inputs of HRSD-1C. Each HRSD-1C must have a PV module connected to its inputs. Output - Output + Input + Input - C ). Connect the outputs of HRSD-1C in series.
-
Page 11: Ht10 Installation
CORE 2 Transmitter Din Rail PSU Core 1 INITIATOR- -12 V INITIATOR+ +12 V LED 2 LED 1 CORE 1 CORE 2 LED 2 Transmitter Din Rail PSU Core 1 Core 2 © 2022 Hoymiles Power Electronics Inc. All rights reserved. - Page 12 - Connect wires to AC side of power supply. *Only positive homerun or negative homerun through core *Only positive homerun or negative homerun through core *Only positive homerun or negative homerun through core © 2022 Hoymiles Power Electronics Inc. All rights reserved.
- Page 13 Rapid Shutdown User Manual C ). - Connect the serially connected outputs of HRSD-1C to the inverter with a DC cable. - Turn on AC power to Transmitter HT10 power supply to activate the “permission to operate” signal. GRID Note: Install HRSD-1C before powering on Transmitter HT10-Kit.
-
Page 14: Ht10-Kit Installation
LED 2 Transmitter Din Rail PSU Core 1 INITIATOR- -12 V INITIATOR+ +12 V LED 2 LED 1 CORE 1 LED 2 CORE 2 Transmitter Din Rail PSU Core 1 Core 2 © 2022 Hoymiles Power Electronics Inc. All rights reserved. - Page 15 *Only positive homerun or negative homerun through core * AC Wires for PSU *Only positive homerun or negative homerun through core *Only positive homerun or negative homerun through core © 2022 Hoymiles Power Electronics Inc. All rights reserved.
- Page 16 - Use grounding-type bushings and jumper wires. D ). - Connect the serially connected outputs of HRSD-1C to the inverter with a DC cable. - Turn on AC power to Transmitter HT10-Kit power supply to activate the “permission to operate” signal.
-
Page 17: Conduit Drilling Guide
Rapid Shutdown User Manual Conduit Drilling Guide Enclosure Drilling Guide for .75” Conduit Enclosure Drilling Guide for 1” Conduit © 2022 Hoymiles Power Electronics Inc. All rights reserved. -
Page 18: Technical Specifiications
IP68/NEMA6P Compliance Safety UL1741, CSA C22.2 No. 330-17, IEC/EN 62109-1 FCC Part15 Class B, ICES-003, IEC/EN 61000-6-1/-2/-3/-4 *1: Fits PV module in landscape and portrait installation. 1200 1200 Unit : mm © 2022 Hoymiles Power Electronics Inc. All rights reserved. -
Page 19: Ht10
-40°C to +85°C (-40°F to +185°F) Outdoor Rating IP30/NEMA1 Compliance Safety UL1741, CSA C22.2 No. 330-17 FCC Part15 Class B, ICES-003 *1: Φ 6 mm DC cable diameter Unit : mm 36.5 Transmitter Core-150A Core-75A © 2022 Hoymiles Power Electronics Inc. All rights reserved. -
Page 20: Ht10-Kit
*1 According to the cable diameter Φ 6 mm, if cable diameter is more than Φ 6 mm, Strings Per Core will be reduced. Care should also be taken not to exceed the allowable current. 198.5 36.5 Power Supply Unit : mm Transmitter Core-150A Core-75A (optional) © 2022 Hoymiles Power Electronics Inc. All rights reserved.
