1. Appearance
2. Installation
Note:
·
Allow a minimum of 1.5 cm of space between the roof and the HRSD-1C enclosure to ensure ventilation and heat dissipation.
Region: Global
AP040555
Output +
Method 1 (Recommended)
REV.1.1
HRSD-1C Quick Installation Guide
Input +
Input -
Mounting Brackets
© 2022 Hoymiles Power Electronics Inc. All rights reserved.
Output -
Method 2
