3. Installation

3.1. System overview

1
External CAN interface (X1)
Position Description
1 External excavator guidance system
2 C2C (CAN to CAN bridge)
3 Cabin module
4 USB cable (connection to MicroConf)
5 Tiltrotator
6 Rotation sensor
7 Tilt Sensor (optional extra)
2
7 6
6
3 Installation
3
Internal CAN interface (X2)
5
4
