- Page 1 PT-PTC-D-BT PoE to USB-C Adapter Quick Installation Guide www.procetpoe.com...
- Page 2 Declaration This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Overview The installation Guide for PT-PTC-D-BT and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
-
Page 4: Table Of Contents
able of Contents 1. Introduction 1.1 Introduction...............01 1.2 Appearance..............01 1.3 Specification..............03 2. Installation Preparation 2.1 Package Contents............03 2.2 Installation Toolkits............04 2.3 Caution.................05 Table of Contents... -
Page 5: Introduction
1.1 Introduction PT-PTC-D-BT is an indoor PoE to USB-C adapter. The power and data obtained from the IEEE802.3 bt PoE power supply or PoE switch are used to power and network the USB-C PD through the adapter. PT-PTC-D-BT adopts a white plastic shell design and can be carried around for easy desktop use. -
Page 6: Side View
Upper V Upper Vie Side View Side View Introduction... -
Page 7: Specification
IP Rated IP40 Dimensions & NW 100mm X 60mm X 22mm（129g） 2. Installation Preparation 2.1 Package Contents Open the box of the PT-PTC-D-BT and carefully unpack it, the box should contain the following items: PT-PTC-D-BT Operating Manual USB-C Cable Introduction... -
Page 8: Installation Toolkits
Please use Cat5e or Cat6 cables to connect this product. USB-C Device PoE Swicth RJ45 Lengths ≤100m Data & Power Input USB-C Port PT-PTC-D-BT Data & Power Output Device Connection Caution： For 1000Base-T Ethernet, it is recommended to use Cat5e and above UTP/STP cables; Installation Preparation... -
Page 9: Caution
2.3 Caution 1. This device is only for indoor use. 2. To achieve the best experience with this device, please use Cat 5e or above PoE cables. 3. Connect the PoE network cable to the PoE input port of this product. The length of the network cable should not exceed 100 meters. - Page 10 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd www.procetpoe.com...
