- Page 1 PT-PCGI-BT Gigabit PoE to USB-C Adapter Quick Installation Guide www.procetpoe.com...
- Page 2 Declaration This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Overview The installation Guide for PT-PCGI-BT and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
-
Page 4: Table Of Contents
able of Contents 1. Introduction 1.1 Introduction...............01 1.2 Appearance..............01 1.3 Specification..............03 2. Installation Preparation 2.1 Package Contents............03 2.2 Installation Toolkits............04 2.3 Inspection................04 2.4 Caution................05 3. Installation 3.1 Mounting Installation...........05 3.2 Inspection................06 Table of Contents... -
Page 5: Introduction
1. Introduction 1.1 Introduction PT-PCGI-BT is a gigabit PoE to USB-C power and data all-in-one adapter. It allows for the power and data obtained from an IEEE802.3bt PoE injector or PoE switch to convert to USB-C PD. Support your USB-C device has stable wired network connectivity. - Page 6 Upper View Fixing holes Company Logo Area 1-2 Upper View Side View 1-3 Side View Introduction...
-
Page 7: Specification
Dimensions & NW 98.7mm X 73.72mm X 19mm（167g） 2. Installation Preparation 2.1 Package Contents Open the box of the PT-PGCI-BT and carefully unpack it, the box should contain the following items: USB-C cable with PT-PCGI-BT O perating Manual Locking screw Introduction... -
Page 8: Installation Toolkits
Please use Cat5e or Cat6 cables to connect this product. USB-C Device PoE Switch Lengths≤100m Data & Power input Data & Power PT-PCGI-BT output in USB-C port 2-1 Device Connection Caution： We recommend to use Cat5e or above UTP/STP cables for 1000Base-T Ethernet. -
Page 9: Caution
2.4 Caution 1. This device is for indoor use only. 2. For optimal performance of this device, please use Cat 5e or Cat6 cables. 3. The total Ethernet cable length can not exceed 100 meters. 4. Disconnect the USB-C cable from your USB-C device if it does not need power charged. -
Page 10: Inspection
Screw hol Screws Fixing holes Metal plate or Wall 3-1 Wall-mounted Installation 3.2 Inspection Inspect the installed equipment before putting it into operation： · Make sure the PD connected can work normal. · Make sure the Ethernet cable connection is correct. Installation... - Page 11 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd www.procetpoe.com...
