PROCET PT-PGC-AF User Manual

PT-PGC-AF
Gigabit PoE to USB-C Adapter
User Manual
www.procetpoe.com
Overview
PT-PGC-AF is an indoor PoE to USB-C adapter. It allows power and data obtained from an
IEEE802.3af PoE injector or PoE switch to be provided to USB-C PD and network connectivity
through the adapter.
PT-PGC-AF features a white plastic housing design, making it portable for on-the-go use or for
fixed installations. The device operates within a safe voltage input of up to 57V and provides a
power output of 5V/2A and network data at 10/100/1000Mbps. The effective distance for PoE
transmission via Cat5e/Cat6 Ethernet cable is 100 meters.
PT-PGC-AF is compatible with most tablets, Android smartphones, and the latest Apple
smartphones with USB-C interface. When no PoE power source is fed, it can be regarded as a
Gigabit Ethernet converter. That is Ethernet signal can be transmitted through two connected
devices.
Appearance
Front View
��.�±�mm
��.�±�mm
PoE Input
USB-C
�.�mm
�.�mm
�.�mm
1 Product Diagram
��.�±�mm
�.�±�mm
USB-C Output
�.��mm
��.�mm
Ｄｅｃｌａｒａｔｉｏｎ
Copyright ©2024 Creative Lianjie Network
Technology Co.Ltd
This document belongs to PROCET company. It is not
allowed to reproduce and modify without the original
author's permission. It is PROCET's policy to improve its
products as new technology components, software , and
firmware at any time. PROCET, therefore, reserves the right
to change specifications without prior notice.
Please follow WEEE (Waste Electrical and Electronic
Equipment) disposal instructions for old electronic
products.Please do not dispose of the old product in your
general household waste bin.
The symbol indicates that the product should not be
discarded as unsorted waste but must be sent to separate
collection facilities for recovery and recycling.
Upper View
Power Indicator
��.�±�mm
≤���mm
Side View
All rights reserved.
Fixing Holes
��.�mm
��mm
� Dimensions
��.�mm
USB-C
Output
