- Page 1 Messenger Lite User Manual 9M02-4103-A001-EN...
-
Page 2: Revision History
Cattron Holdings, Inc., or any of its affiliates or agents shall not be liable for incidental or consequential damages of any kind. All Cattron products are sold pursuant to the Terms and Conditions of Sale, a copy of which will be furnished upon request. When used as a tradename herein, Cattron means Cattron Holdings, Inc. -
Page 3: Table Of Contents
Messenger Lite User Manual Contents Capabilities ....................................5 Capabilities ............................... 5 Monitored Parameters ............................5 RemoteIQ Cloud .............................. 5 Installation and Setup ................................. 6 Installation Steps .............................. 6 Unpacking the Equipment ..........................6 Mounting the Equipment ..........................6 Mounting the Antenna ............................7 Connect Main Power and CAN J1939 ...................... - Page 4 This User Manual describes installation and setup of the Messenger Lite product. The Messenger Lite is a cost-effective monitoring device for engine-driven equipment. It supports monitoring and reporting of data values from the J1939 SAE engine bus as well as GPS location. It uses a 4G LTE-M cellular data connection to report engine data to the RemoteIQ Cloud service to enable equipment owners and operators to have a complete picture of the status of their equipment fleet at all times.
-
Page 5: Capabilities
Messenger Lite User Manual Capabilities Capabilities The Messenger Lite is an easy to install device for remote monitoring of engine driven equipment. Some of the capabilities are listed below. • Monitoring of standard engine and equipment operational parameters • Alerts for any J1939 DTC (diagnostic trouble code) •... -
Page 6: Installation And Setup
Built in cable harness providing wiring connections for the J1939 CAN bus and DC power Mounting the Equipment The Messenger Lite is housed in a IP65 weather resistant enclosure; the dimensions of the enclosure are shown Figure 1. Figure 1 (Dimensions are in Inches) -
Page 7: Mounting The Antenna
User Manual If the mounting location is exposed to the elements, the Messenger Lite should be mounted in a vertical position to try and minimize the chance of water entering through the antenna connection. The antenna wires should have a service loop just below the antenna connectors. -
Page 8: Led States
One flash = CAN bus detected • Two flashes = CAN bus not detected • LED off indicates that the system is no longer functioning (contact Cattron at support for assistance) Log in to RemoteIQ Log in to your RemoteIQ account at my.remoteiq.com to confirm device connectivity to the cloud, configure device name and description, and set up alarms and notifications as needed. -
Page 9: Technical Support
Messenger Lite User Manual Technical Support For remote and communication control systems support, parts and repair, or technical support, visit us online at: www.cattron.com/contact 9M02-4103-A001-EN Version A... - Page 10 Due to continuous product improvement, the information provided in this document is subject to change without notice. Cattron Support For remote and communication control systems support, parts and repair, or technical support, visit us online at: www.cattron.com/contact Cattron North America Inc., 655 N River Rd NW, Suite A, Warren, OH 44483 9M02-7000-A101-EN Version A...
