Rivers Edge RE401 Operator's Manual

12' 2-man quad pod
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WE ARE HUNTERS
PRODUCT MEETS
INDUSTRY STANDARDS
RECOGNIZED BY
PARTICIPATING MEMBER
Get parts online at
www.HuntRiversEdge.com
Operator's Manual
12' 2-Man
Quad Pod
MODEL RE401
Maximum Height
12' to shooting rail
Maximum Field Rating
500 lbs; no more than
300 lbs per person.
P/N: 45832
© 2024 Ardisam, Inc.
C/N: 45857
All Rights Reserved
REV2: 05/03/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RE401 and is the answer not in the manual?

Questions and answers

Related Manuals for Rivers Edge RE401

Summary of Contents for Rivers Edge RE401

  • Page 1 Operator's Manual 12’ 2-Man WE ARE HUNTERS Quad Pod MODEL RE401 Maximum Height 12’ to shooting rail Maximum Field Rating 500 lbs; no more than 300 lbs per person. PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY P/N: 45832 Get parts online at ©...

  • Page 2: Table Of Contents

    Any misunderstanding or questions regarding the products of their use should be directed to Ardisam, Inc. prior to any use. All Rivers Edge® Treestands are sold with a full body harness (“Fall Arrest System”) that meets standards set by the Treestand Manufacturer’s Association (“TMA”).

  • Page 3: Warnings

    Operator’s Manual 12’ 2-Man Quad Pod READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE401 WARNING MAXIMUM USE HEIGHT - 12’ TO SHOOTING RAIL A signal device such as a mobile phone, radio, whistle, MAXIMUM OCCUPANCY - TWO (2) PERSONS signal flare or personal locator device (PLD) must be on your person and readily available at all times.
  • Page 4 Only use approved Rivers Edge® parts. Failure to do so not visible to the naked eye. Do not attempt to use any may result in serious injury or death! product if damage is detected or suspected.

  • Page 5: Inspection And Maintenance Schedule

    Operator’s Manual 12’ 2-Man Quad Pod WARNING INSPECTION AND MAINTENANCE Be sure only one person ascends or descends ladder at a BEFORE EACH USE PERFORM THE FOLLOWING: time. Be certain first person is fully off of the ladder and positioned safely on tower platform or ground before •...

  • Page 6: Hardware List

    Operator's Manual 12’ 2-Man Quad Pod TOOLS REQUIRED (NOT INCLUDED) 7/16 IN WRENCHES HARDWARE LIST Item Part No. Image Description KNOB NUT 43276 5/16 IN KNOB BOLT 43277 5/16 X 2-1/4 IN Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 7 Operator’s Manual 12’ 2-Man Quad Pod HARDWARE LIST (CONTINUED) Item Part No. Image Description BOLT 48153B 1/4 X 2 IN BOLT 48240B 1/4 X 1-1/2 IN BOLT 48250B 1/4 X 1-3/4 IN 48261B WASHER 1/4 IN BOLT 48271B 1/4 X 2-1/4 IN 48752B NUT 1/4 IN BOLT 1/4 X 2-3/4...

  • Page 8: Assembly Instructions

    Operator's Manual 12’ 2-Man Quad Pod ASSEMBLY INSTRUCTIONS IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combinations completely until instructions indicate to. Finger tighten plus one turn of a wrench only! This will temporarily hold the lock- nut on the bolt while helping alignment of all parts! •...
  • Page 9 Operator’s Manual 12’ 2-Man Quad Pod 3. Secure the three platforms together (11, 12, 13) using eight 1/4 X 2 IN bolts (43) and nuts (50). mesh hidden for clarity 4. Attach the seat post bottom (14) to the top of the assembled platform using four 1/4 X 1-3/4 IN bolts (45), four 1/4 IN washers (46) and four nuts (50) for each seat post.
  • Page 10 Operator's Manual 12’ 2-Man Quad Pod 5. Assemble the three legs by attaching the leg-to- platform (21) to each bottom leg (22) using one 1/4 X 2 IN bolt (43) and nut (50) for each leg. Attach two brace-to-leg brackets (3) to each leg assembly using two 1/4 X 2 IN bolt (43) and nuts (50).
  • Page 11 Operator’s Manual 12’ 2-Man Quad Pod 6B. Locate one of each of the following braces: 26, 28, 29, 30, and 42 to make the RIGHT SIDE ladder cross brace assembly. Insert brace (26) into brace (29). Next, insert brace (28) into brace (30). Brace (29) and brace (30) will be the top of the assembly.
  • Page 12 Operator's Manual 12’ 2-Man Quad Pod 8. Begin assembly of the ladder by first sliding together the top, middle, and bottom ladder sections (20, 23, 24). Attach one brace-to-ladder bracket (4) to each side of the top ladder (20) and secure with one 1/4 X 1-3/4 IN bolt (45) and a nut (50).
  • Page 13 Operator’s Manual 12’ 2-Man Quad Pod 10A. Locate the rear cross brace assembly from step 7. With brace (27) closer to the platform, connect each brace (27) to the inside of the brace-to-leg attachments (3) that are closer to the platform using four 1/4 X 3/4 IN bolt (53) and nuts (50).
  • Page 14 Operator's Manual 12’ 2-Man Quad Pod 10B. Locate the left side ladder cross brace assembly made in Step 6A. Begin by attaching brace (30) to the inside of the brace-to-ladder bracket (4) that is closest to the platform located on the left side of the ladder using one 1/4 X 3/4 IN bolt (53) and nut (50).
  • Page 15 Operator’s Manual 12’ 2-Man Quad Pod 11. Attach the three vertical corner supports (35) to the leg-to-platform assemblies using two 1/4 X 2-3/4 IN bolts (51) and two nuts (50) for each support. Attach the two vertical entry supports (32) to the platform assembly using one 1/4 X 2 IN bolt (43) and one nut (50) for each support.
  • Page 16 Operator's Manual 12’ 2-Man Quad Pod 12. Attach the two long support braces (40) to the vertical corner support (35) that is opposite to the ladder using one 1/4 X 1-1/2 IN bolt (44) and nut (50). Be sure the center holes in each long support brace (40) are closer to the other two vertical corner supports (35).
  • Page 17 Operator’s Manual 12’ 2-Man Quad Pod 13A. Assemble the shooting rail using the two long shooting rails (37), two short shooting rails (38), one entry shooting rail (34), three shooting rail corner hubs (36), and two shooting rail entry hubs (33) using ten 1/4 X 1-1/4 IN bolts (52) and nuts (50).
  • Page 18 Operator's Manual 12’ 2-Man Quad Pod 14. Begin assembly of the seats by attaching the top seat post (5) to the seat frame (19) using four 1/4 X 1-1/2 IN bolts (44) and nuts (50) for each seat. 15. Attach the seat assembly (18) and two armrests/ backrest (17) using four 1/4 X 2-1/4 IN bolts (47), two 1/4 X 1-1/2 IN bolts (44), six 1/4 IN steel washers (46), and six nuts (50) for each seat.
  • Page 19 Operator’s Manual 12’ 2-Man Quad Pod 16. Complete the assembly of the seats by sliding the backrest (16) onto the armrests/backrest supports (17). Then tension the backrest by attaching the backrest spreader (15) to the armrests/backrest supports (17) using two 1/4 X 1-1/2 IN bolts (44) and two nuts (50).
  • Page 20 Operator's Manual 12’ 2-Man Quad Pod 18. Using a hammer, drive the five provided ground stakes (6) into the ground at an angle towards the center of the tower. Driving them in at a similar angle as shown will greatly increase how well the tower is secured to the ground.

  • Page 21: Finished Tower

    Operator’s Manual 12’ 2-Man Quad Pod FINISHED TOWER PADDED SHOOTING RAIL SWIVEL SEAT ASSEMBLED PLATFORM SECTION TOP LADDER SECTION LEG ASSEMBLY LADDER BRACE MIDDLE LADDER SECTION CROSS BRACES GROUND STAKES BOTTOM LADDER SECTION Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...

  • Page 22: Illustrated Parts Breakdown

    Operator's Manual 12’ 2-Man Quad Pod ILLUSTRATED PARTS BREAKDOWN - PLATFORM mesh hidden for clarity Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 23 Operator’s Manual 12’ 2-Man Quad Pod ILLUSTRATED PARTS BREAKDOWN - TOWER LEGS additional braces hidden for clarity Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 24 Operator's Manual 12’ 2-Man Quad Pod ILLUSTRATED PARTS BREAKDOWN - SHOOTING RAIL Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 25 Operator’s Manual 12’ 2-Man Quad Pod ILLUSTRATED PARTS BREAKDOWN - SEAT seat mesh hidden for clarity Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...

  • Page 26: Parts List

    Operator's Manual 12’ 2-Man Quad Pod PARTS LIST ITEM # PART # DESCRIPTION QTY. ITEM # PART # DESCRIPTION QTY. 45780 VERTICAL ENTRY SUPPORT 25707 SLEEVE W/FOAM 34 IN 45781 SHOOTING RAIL ENTRY HUB 29713 SQUARE PLUG 19 MM 45782 SHOOTING RAIL ENTRY 34558 BRACE TO LEG BRACKET...

  • Page 27: Notes

    Operator’s Manual 12’ 2-Man Quad Pod NOTES Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 28 WE ARE HUNTERS Rivers Edge® Treestands Phone: 800-345-6007 A Division of Ardisam, Inc. 1730 Industrial Avenue, PO Box 666 www.HuntRiversEdge.com Cumberland, WI 54829 All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvement, product images may not be exact. Warning labels in some product images...
