Rivers Edge CLASSIC XT RE660 Operator's Manual

1-man ladder stand
Hide thumbs

Advertisement

Quick Links

Download this manual
WE ARE HUNTERS
PRODUCT MEETS
INDUSTRY STANDARDS
RECOGNIZED BY
PARTICIPATING MEMBER
Get parts online at
www.HuntRiversEdge.com
Operator's Manual
CLASSIC XT
1-MAN
Ladder Stand
MODEL RE660
Maximum Height
16' 6" to armrests
Maximum Field Rating
300 lbs
Tree Diameter Range
12" to 20"
Wear Your Harness!
© 2018 RETI
P/N: 29349
All Rights Reserved
REV2: 07/27/18

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLASSIC XT RE660 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rivers Edge CLASSIC XT RE660

Summary of Contents for Rivers Edge CLASSIC XT RE660

  • Page 1 Operator's Manual CLASSIC XT WE ARE HUNTERS 1-MAN Ladder Stand MODEL RE660 Maximum Height 16' 6" to armrests Maximum Field Rating 300 lbs Tree Diameter Range 12" to 20" Wear Your Harness! PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY Get parts online at ©...

  • Page 2: Table Of Contents

    Instructions should be kept in a safe place and reviewed at least annually. If for any reason you have a problem with your product, DO NOT return to the retailer, contact the Rivers Edge® customer service department at 800-450-EDGE (3343) for assistance.

  • Page 3: Warnings

    Operator's Manual CLASSIC XT 1-Man Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE660 WARNING MAXIMUM USE HEIGHT - 16' 6" TO ARMRESTS Never jump or bounce on a treestand to seat it to the tree. MAXIMUM OCCUPANCY - ONE (1) PERSON Pull up a bow, backpack, or firearm or other equipment only after being secure in the treestand and a firearm...

  • Page 4: Inspection And Maintenance

    Operator's Manual CLASSIC XT 1-Man Ladder Stand WARNING INSPECTION AND MAINTENANCE Always lean forward as you climb and attach your harness to the tree before securing the platform to the tree and BEFORE EACH USE PERFORM THE FOLLOWING: stepping onto the platform. Never exceed the stated maximum use height.

  • Page 5: Assembly Instructions

    Operator's Manual CLASSIC XT 1-Man Ladder Stand ASSEMBLY INSTRUCTIONS TOOLS NEEDED: two 7/16 IN wrenches. All assembly must be done in this order at ground level before IMPORTANT ASSEMBLY TIP: uprighting. Do not tighten any nut and bolt combinations completely until all Do not remove labels/warnings from product, they are there parts are assembled together! Finger tighten plus one turn of a wrench for your safety.
  • Page 6 Operator's Manual CLASSIC XT 1-Man Ladder Stand 3. Attach the spreader bar (5) and both armrests (8) to the outer edge of the seat side rails (3) using four 1/4-20 X 2-1/4 IN bolts (19), four yellow washers (16), and four 1/4-20 nuts (15). SEE FIGURE 3.
  • Page 7 Operator's Manual CLASSIC XT 1-Man Ladder Stand 5. Take the foot platform (1) and align holes in the outer edges with holes in free end of support bars (6), and flared platform rails (2) as shown in FIGURE 5. Secure the support bars (6) to the rear of the foot platform (1) with two 1/4-20 X 1-1/2 IN bolts (18), two washers (14), and two 1/4-20 nuts (15).
  • Page 8 Operator's Manual CLASSIC XT 1-Man Ladder Stand 8. Attach the stabilizer bar extension tube (7) to the middle ladder section (12) through the mounting bracket with one lockpin (17). SEE FIGURE 6. 9. Slide the stabilizer bar (13) into the extension tube (7) and attach the two pieces together using one lockpin (17).

  • Page 9: Warnings

    Operator's Manual CLASSIC XT 1-Man Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE SETUP AND USE STOP WARNING WARNING Double check assembly steps to be certain you have Always maintain three (3) points of contact when correctly assembled this product. climbing a ladder treestand.

  • Page 10: Setup And Use Instructions

    Operator's Manual CLASSIC XT 1-Man Ladder Stand SETUP AND USE INSTRUCTIONS FIGURE 8 WARNING Never use a treestand on a dead, leaning, diseased or loose barked tree, or a utility pole. Always avoid electrical power lines. During installation and removal of ladder treestands, you must always and properly use the included Full Body Harness (Fall Arrest System).
  • Page 11 Operator's Manual CLASSIC XT 1-Man Ladder Stand 5. a. Loop the D-loop end of the two 16' criss cross straps (23) FIGURE 12A FIGURE 12B through the loop end to form a cinch knot around the ladder rail tube. Secure beneath step rung, at the stabilizer bar height location.

  • Page 12: Finished Ladder

    Operator's Manual CLASSIC XT 1-Man Ladder Stand FINISHED LADDER ratchet strap platform 16' criss cross straps top ladder section stabilizer bar 6' cam strap middle ladder section stabilizer bar spring lock pins stabilizer bar extension tube bottom ladder section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 13 Operator's Manual CLASSIC XT 1-Man Ladder Stand NOTES Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...

  • Page 14: Illustrated Parts Breakdown

    Operator's Manual CLASSIC XT 1-Man Ladder Stand ILLUSTRATED PARTS BREAKDOWN 14 6 Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 15 Operator's Manual CLASSIC XT 1-Man Ladder Stand PARTS LIST ITEM # PART # DESCRIPTION QTY. ITEM # PART # DESCRIPTION QTY. 29191 PLATFORM 23572 YELLOW WASHER M6 29194 FLARED PLATFORM RAIL 19847 LOCKPIN M6 X 50.8 MM 29236 SEAT SIDE RAIL 48240B BOLT 1/4-20 X 1-1/2 IN 29198...
  • Page 16 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-450-EDGE (3343) 1160 Eighth Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 www.HuntRiversEdge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
