Operator's Manual
LOCKDOWN
1-MAN
Ladder Stand
MODEL RE651
Maximum Height
21' to shooting rail
Maximum Field Rating
300 lbs
Tree Diameter Range
12" to 20"
Wear Your Harness!
© 2018 RETI
P/N: 26875
All Rights Reserved
REV4: 01/25/18
21
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rivers Edge LOCKDOWN 21
Summary of Contents for Rivers Edge LOCKDOWN 21
- Page 1 Operator's Manual LOCKDOWN ™ WE ARE HUNTERS 1-MAN Ladder Stand MODEL RE651 Maximum Height 21' to shooting rail Maximum Field Rating 300 lbs Tree Diameter Range 12" to 20" Wear Your Harness! PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY Get parts online at ©...
-
Page 2: Table Of Contents
Instructions should be kept in a safe place and reviewed at least annually. If for any reason you have a problem with your product, DO NOT return to the retailer, contact the Rivers Edge® customer service department at 800-450-EDGE (3343) for assistance. -
Page 3: Warnings
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE651 WARNING MAXIMUM USE HEIGHT - 21' TO SHOOTING RAIL Never jump or bounce on a treestand to seat it to the tree. -
Page 4: Inspection And Maintenance
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand WARNING INSPECTION AND MAINTENANCE Always lean forward as you climb and attach your harness to the tree before securing the platform to the tree and BEFORE EACH USE PERFORM THE FOLLOWING: stepping onto the platform. -
Page 5: Hardware Identification Chart
Bolts shown are for size reference. HARDWARE IDENTIFICATION CHART Extra hardware may be included in the parts bag. Quick Tip: Cut page out to use as a reference tool while following assembly instructions 1/4-20 X 1-1/4in Bolt - Qty 3 5/16in Washer Qty 4 M6 Yellow Washer... -
Page 7: Assembly Instructions
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand ASSEMBLY INSTRUCTIONS IMPORTANT ASSEMBLY TIP: All assembly must be done in this order at ground Do not tighten any nut and bolt combinations completely level before uprighting. until all parts are assembled together! Finger tighten plus one... - Page 8 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 4. Attach the right rear seat support (7) and the left rear seat support (6) to the underside of the rear platform (3) using four 5/16-18 x 2-1/4 IN bolts (30) and 5/16 IN locknuts (35). SEE FIGURE 3.
- Page 9 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 8. Attach the top of the right armrest (9) and the top of the left armrest (10) to the rear seat supports (6,7) using two 5/16-18 x 3-1/4 IN bolts (31), 5/16 IN washers (37) and 5/16 IN locknuts (35).
- Page 10 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 14. Attach the seat (11) to the seat mounting brackets of the rear seat supports (6,7) using two 1/4-20 X 2 IN bolts (27), four yellow M6 plastic washers (38), two yellow M6 plastic spacers (39) and two 1/4 IN flange locknuts (34).
- Page 11 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 18. Attach one shooting rail part A (17) to each end of shooting rail part B (18) using two 1/4-20 X 1-1/4 IN bolts (25) and 1/4 IN flange locknuts (34). SEE FIGURE 9.
- Page 12 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 24. Attach stabilizer support tube (20) to the lowest middle ladder section (15) using 1/4-20 x 2 1/4 IN wing screw (33) and wing nut (36). SEE FIGURE 11. NOTE: Mounting hole is located just below top ladder rung on the middle ladder section.
- Page 13 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 27. Attach the straps of the stabilizer bar ratchet assembly (47) to the stabilizer bar bark biting plate. a. Feed the sewn loop of the long strap through either side slot in the bark biting plate and then feed the loose end through the sewn loop.
-
Page 14: Warnings
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE SETUP AND USE STOP WARNING WARNING Double check assembly steps to be certain you have Always maintain three (3) points of contact when correctly assembled this product. -
Page 15: Setup And Use Instructions
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand SETUP AND USE INSTRUCTIONS WARNING During installation and removal of ladder treestands, you must always and properly use the included Full Body Harness (Fall Arrest System). Refer to the Full Body Harness instructions Never use a treestand on a dead, leaning, diseased or included with this product for proper use. - Page 16 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand 10. Locate the two ratchet portions with S-hooks for the criss cross straps (46). a. With one ratchet portion of the criss cross strap (46) now in hand, feed one long strap hanging down from platform through the center slot of ratcheting mechanism and back around through tightening lever.
-
Page 17: Finished Ladder
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand FINISHED LADDER REMOVABLE VINYL DIPPED SHOOTING RAIL LARGE RATCHET FOLD-AWAY STRAPS VINYL DIPPED FOOTREST TEARTUFF MESH ™ STORAGE SHELF LONG CRISS CROSS RATCHET STRAPS SILENT KNOB ASSEMBLIES STABILIZER BAR RATCHET STRAP OCTAGONAL LADDER TUBING... -
Page 18: Illustrated Parts Breakdown
Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand ILLUSTRATED PARTS BREAKDOWN MESH HIDDEN FOR CLARITY MESH HIDDEN FOR CLARITY 34 1 Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5... - Page 19 Operator's Manual LOCKDOWN 21 1-MAN Ladder Stand PARTS LIST ITEM # PART # DESCRIPTION QTY. ITEM # PART # DESCRIPTION QTY. 26825 J TUBES 26959 BOLT M6 X 1.0 X 70 MM 26780 PLATFORM FRONT 8909B BOLT 1/4-20 X 1-1/4 IN...
- Page 20 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-450-EDGE (3343) 1160 Eighth Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
