Summary of Contents for Rivers Edge RE761
- Page 1 Operator's Manual LOUNGER WE ARE HUNTERS TREE SEAT MODEL RE761 Maximum Field Rating 300 lbs Tree Diameter Range 8" - 20" WARNING FOR GROUND LEVEL USE ONLY! Get parts online at P/N: OMRE76109 © 2022 Ardisam C/N: 15355 www.HuntRiversEdge.com All Rights Reserved...
-
Page 2: Table Of Contents
Instructions should be kept in a safe place and reviewed at least annually. If for any reason you have a problem with your product, DO NOT return to the retailer, contact the Rivers Edge® cus- tomer service department at 800-345-6007 for assistance. -
Page 3: Warnings
Operator's Manual LOUNGER TREE SEAT WARNING WARNING Always be physically fit, mentally alert, and well-rested This tree seat is designed to be used at a height that allows the user's feet to be on the ground at all times before using this product. when in use. -
Page 4: Inspection And Maintenance Schedule
Operator's Manual LOUNGER TREE SEAT ASSEMBLY INSTRUCTIONS INSPECTION AND MAINTENANCE TOOLS NEEDED – TWO 7/16" WRENCHES Attach the tree hugger (3) to the seat frame (4) using one 1/4-20 x 2-1/4 IN bolt (5), nut (9) and washer (7). SEE BEFORE EACH USE PERFORM THE FOLLOWING: FIGURE 1. -
Page 5: Setup And Use Instructions
Operator's Manual LOUNGER TREE SEAT SETUP AND USE INSTRUCTIONS This tree seat is designed to be used at a height that allows the user's feet to be on the ground at all times when in use. Use as a ground seat only. Attach the long strap to either upper corner of backrest frame. -
Page 6: Illustrated Parts Breakdown
Operator's Manual LOUNGER TREE SEAT ILLUSTRATED PARTS BREAKDOWN Check for parts online at www.HuntRiversEdge.com or call 800-345-6007... - Page 7 Operator's Manual LOUNGER TREE SEAT PARTS LIST FINISHED LOUNGER TREE SEAT ITEM # PART # DESCRIPTION QTY. 41014 WASHER #8 X .375 X .04 IN FLAT GR5 BLK ZN 48075 BACKREST 48078 TREE HUGGER 48081 SEAT FRAME 48271B BOLT 1/4-20 X 2-1/4" HHCS GR5 BLK ZN 48250B BOLT 1/4-20 X 1-3/4 HHCS...
- Page 8 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-345-6007 1730 Industrial Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 www.huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
