Maple Systems cMT3092Xv2 Series Installation Instruction page 2

EasyBuilder Pro Software Settings
6
Launch EasyBuilder Pro software, select your project file, press F7 shortcut key to open the download
dialog box: Select Ethernet > IP tab > Enter your HMI IP > Click Download to download this project
file to HMI.
Using screensaver and backlight saver is recommended in order to avoid image persistence caused
by displaying the same image on HMI for a long time.
( Please refer to EasyBuilder Pro User Manual for software operation details. )
Communication Connections
7
NOTE:
1. Only Tx & Rx (no RTS/CTS) may be used for COM1 RS232 when COM3 RS-232 is also used.
2. COM2 / COM3 RS-485 2W Supports MPI 187.5K, please use one at a time.
Con.B
COM1 COM3 [RS232] 9 Pin, Male, D-sub COM2
/
COM1 COM3
PIN# PIN#
[RS232]4W [RS232]2W
1
2 RxD
3 TxD
4
5 GND
6
7 RTS TxD
8 CTS RxD
9
8 Touchscreen Calibration & Restore Factory Default
Touchscreen Calibration: Press and hold anywhere on the screen during HMI startup.
Restore Factory Default: There are two methods to restore factory default, both of which will erase all
project files and data stored on the device.
1. Follow the instructions in section 5 of this manual to open the Setting page and select the
Appropriate page based on the OS version before pressing "Reset HMI to default":
For OS versions 20231201 or later, select the "System Properties" page, press "Reset HMI to
Default", and select "Reset".
For OS versions before 20231201, select the "Reset Options" page, press "Reset HMI to default",
and enter "yes".
2. Alternatively, perform the operation based on the OS version:
For OS versions 20231201 or later, after pressing "Reset HMI to Default", enter "default111111" or
the default password "111111", and select "Reset".
For OS versions before 20231201, enter "default111111" during login, and then enter "yes".
Battery Replacement
9
Battery replacement shall be performed by qualified personnel only and care must be taken when
handling lithium batteries.
Con.A
COM3 [RS485]/CAN Bus 9 Pin, Female, D-sub
/
COM2 COM2 COM3
[RS485]2W [RS485]4W [RS485]2W
1 Data- Rx-
2 Data+ Rx+
3 Tx-
4 Tx+
5 GND
6 Data-
7
8
9 Data+
NOTE: Make sure that all local and national electrical standards are met when
CAUTION
installing the unit. Contact your local authorities to determine which codes apply.
Use power output that meets SELV (Safety Extra-Low Voltage) requirements. The unit can be
powered by DC power only, voltage range: 24±20%, compatible with most controller DC
Power
systems. The power conditioning circuitry inside the unit is accomplished by a switching power
supply. The peak starting current can be as high as 2A.
If the display does not come on within 5 seconds of power up, remove power. A resettable fuse
Fusing Require-
will protect against overcurrent faults in DC circuit and the resetting will take place after a period
ments
of time. Check wiring for proper connections and try to power up again.
A resettable fuse will prevent damage for overcurrent condition however it isn't guaranteed.
High Voltage
DC voltage sources should provide proper isolation from main AC power and similar hazards.
A Hard-wired EMERGENCY STOP should be fitted in any system using an HMI to comply with
Emergency Stop
ICS Safety Recommendations.
Do not power the unit and inductive DC loads, or input circuitry to the controller, with the same
Supply Voltage
power supply. Note: The 24 VDC output from some controllers may not have enough current to
Condition
power the unit.
CAN
Bus
a. Power wire length should be minimized (Max: 500m shielded, 300m unshielded).
b. Please use twisted pair cables for power wire and signal wire and conform to the
impedance matching.
c. If wiring is to be exposed to lightning or surges, use appropriate surge suppression
Wire Routing
devices.
d. Keep AC, high energy, and rapidly switching DC power wiring separated from signal wires.
e. Add a resistor and capacitor in the parallel connection between the ungrounded DC power
supply and the frame ground. This provides a path for static and high frequency
DANGER
dissipation. Typical values to use are 1M Ohm and 4700pF.
CAN_L
D ANGER
CAN_H
The system designer should be aware that devices in Controller systems could fail and
thereby create an unsafe condition. Furthermore, electrical interference in an operator
interface can lead to equipment start-up, which could result in property damage and/or
physical injury to the operator.
Hardware
If you use any programmable control systems that require an operator, be aware that this
Considerations
potential safety hazard exists and take appropriate precautions. Although the specific design
steps depend on your particular application, the following precautions generally apply to
installation of solid-state programmable control devices, and conform to the guidelines for
installation of Controllers recommended in NEMA ICS 3-304 Control Standards.
To conform to ICS Safety Recommendations, checks should be placed in the controller to
ensure that all writable registers that control critical parts of plant or machinery have limit
Programming
checks built into the program, with an out-of-limit safe shut down procedure to ensure safety of
Considerations
personnel.
Limited Warranty
A copy of the Warranty and Limitation of Liability is contained in the product box. It can
also be found on the Maple Systems website.
1010-1086_rev04_20240927
