Et system N31200 Series Programming Manual

Canopen protocol

Hide thumbs

Quick Links

Download this manual

N31200 Series Programming Guide

Offizieller Partner von NGI: Service und Vertrieb direkt durch ET System electronic GmbH.

Official partner of NGI: Service and sales directly through ET System electronic GmbH.

ET System electronic GmbH

www.et-system.de

CANopen Protocol

Hauptstraße 119 – 121

D – 68804 Altlußheim

N31200 CANopen

V20230415

Vertrieb Kontakt: Tel.: +49 (0)6205 / 394 80

info@et-system.de

contact:

Table of Contents

Chapters

Need help?

Do you have a question about the N31200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Et system N31200 Series

Page 1 Vertrieb Kontakt: Tel.: +49 (0)6205 / 394 80 www.et-system.de D – 68804 Altlußheim info@et-system.de contact: © ET System electronic GmbH, Änderungen ohne Vorankündigung, Irrtümer und Änderungen vorbehalten © ET System electronic GmbH, Subject to modiﬁcation without notice, errors and omissions exepted...
Page 2: Table Of Contents
Contents CONTENTS ........................1 1 PREFACE ........................1 2 SAFETY INSTRUCTIONS ....................2 2.1 Safety Notes ..................... 2 2.2 Safety Symbols ....................2 3 CANOPEN OVERVIEW ....................3 4 COMMUNICATION METHOD ..................4 5 CAN FORMAT ......................4 6 COMMANDS ........................ 6 6.1 Status Reading ....................
Page 3 6.5.11 Under Current Protection Ready Time ..........16 6.5.12 Under Current Protection Delay Time ..........17 6.6 Power Supply Protection ................17 6.6.1 ON-OFF Control ................... 17 6.6.2 Priority Mode ..................18 6.6.3 Voltage Rise Slew ................. 18 6.6.4 Current Rise Slew ................18 6.6.5 Operation Mode ..................
Page 4 6.9 SEQ Test ......................33 6.9.1 SEQ File ....................33 6.9.2 Present Cycle Times ................33 6.9.3 Present Step NO .................. 33 6.9.4 Dwell Time for Present Step ..............34 6.9.5 Dwell Time Unit for Present Step ............34 6.10 Discharge Mode .................... 34 6.10.1 Current Setting ..................
Page 5 6.15.6 Mode Selection ................. 49 6.15.7 Trigger Mode ..................49 6.15.8 Cycle Times ..................49 6.15.9 Start ....................50 6.15.10 END ....................50 6.15.11 Increment ..................51 6.15.12 Increment Time ................51 6.16 Wave Edit ...................... 51 6.16.1 File No ....................51 6.16.2 File Length ..................
Page 6 6.19.2 File Length ..................63 6.19.3 Cycle Times ..................64 6.19.4 Link to File ..................64 6.19.5 Mode Selection ................. 64 6.19.6 Step No ....................65 6.19.7 Wave File ................... 65 6.19.8 Output Amplitude ................65 6.19.9 Output Bias ..................66 6.19.10 Output Phase ...................
Page 8: Contents
1 Preface Dear Customers, First of all, we greatly appreciate your choice of N35100 series wide range bidirectional programmable DC power supply (N35100 for short). We are also honored to introduce our company, Hunan Next Generation Instrumental T&C Tech. Co., Ltd. ( NGI for short). About Company NGI is a professional manufacturer of intelligent equipment and test &...
Page 9: Safety Instructions
2 Safety Instructions In the operation and maintenance of the instrument, please strictly comply with the following safety instructions. Any performance regardless of attentions or specific warnings in other chapters of the manual may impair the protective functions provided by the instrument. NGI shall not be liable for the results caused by the neglect of those instructions.
Page 10: Canopen Overview
3 CANopen Overview CANopen is a high-level protocol based on CAN (control area network) serial bus system and CAL (CAN application layer). CANopen assumes that the hardware of the connected device has a CAN transceiver that conforms to ISO11898 standard and a CAN controller.
Page 11: Communication Method
4 Communication Method The protocol used by N35100 physical CAN is CANopen protocol. Before using N35100, please connect CAN communication and configure physical CAN interface parameters, for example, address is set to 01. Please refer to the user manual for details.
Page 12 2b: CS command specifier, which means to write two bytes. The command specifier description is as follows. 40H=Read 2BH=Write two bytes 4BH=Read response two bytes 2FH=Write one byte 4FH=Read response one byte 27H=Write three bytes 47H=Read response three bytes 23H=Write four bytes 43H=Read response four bytes 60H=Write successful response 80H=Abnormal response...
Page 13: Commands
6 Commands 6.1 Status Reading Reading command: 43 00 20 00 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2000 0x00 Parameter description: Returning data: 43 00 20 00 00 00 00 00 [00] Normal operation [02] Under voltage protection [04] Over voltage protection [08] Over current protection...
Page 14: Output Setting
Enter the command 23 00 20 00 00 00 00 00 to clear the alarm information of the current device. Default value :0 6.2 Output Setting 6.2.1 Voltage Setting Setting command: 23 01 20 00 88 13 00 00 Reading command: 43 01 20 00 00 00 00 00 Format Main Index Sub Index...
Page 15: Load Current Setting
index. 01 indicates sub index. Return of reading command: 43 01 20 01 E8 03 00 00 The red part is setting source current data. Hexadecimal 0x000003E8, converting to decimal, is 1000mA, that is, 1.000A. Default value: 0 6.2.3 Load Current Setting Setting command: 23 01 20 02 E8 03 00 00 Reading command: 43 01 20 02 00 00 00 00 Format...
Page 16: Load Power Setting
Return of setting command: 60 05 20 03 00 00 00 00 The red portion of the data 60 indicates successful writing. 05 20 indicates main index. 03 indicates sub index. Return of reading command: 43 05 20 03 32 00 00 00 The red part is setting source power data.
Page 17: Readback Current
Parameter description: reading readback voltage, unit mV Returning data: 43 02 20 00 88 13 00 00 The red part is voltage data. Hexadecimal 0x00001388, converting to decimal, is 5000mV, that is, 5.000V. 6.3.2 Readback Current Reading command: 43 02 20 01 00 00 00 00 Format Main Index Sub Index...
Page 18: Readback Temperature
Main Index Sub Index Read/Write Data Type Byte Size 0x2002 0x04 Parameter description: On the premise that the device opens the output, view the current device with the milliampere-hour, the unit mAh Returing data: 43 02 20 04 88 13 00 00 The red part is the on-load output mah data.
Page 19: Reading Maximum Current Range
6.4.2 Reading Maximum Current Range Reading command: 43 03 20 01 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2003 0x01 Parameter description: reading the maximum current range , unit mA Returning data: 43 03 20 01 E0 2E 00 00 The red part is current range data.
Page 20: Over Current Protection
Main Index Sub Index Read/Write Data Type Byte Size 0x2004 0x00 Parameter description: Return of setting command: 60 04 20 00 00 00 00 00 Return of reading command: 43 04 20 00 10 27 00 00 The red part is the current over voltage protection data. Hexadecimal 0x00002710, converting to decimal, is 10000mV, that is, 10.0V.
Page 21: Under Voltage Protection
6.5.4 Under Voltage Protection Setting command: 23 04 20 03 10 27 00 00 Reading command: 43 04 20 03 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2004 0x00 Parameter description: Return of setting command: 60 04 20 03 00 00 00 00 Return of reading command: 43 04 20 03 10 27 00 00 The red part is under voltage protection data.
Page 22: Over Current Protection Delay Time
Parameter description: Return of setting command: 60 04 20 05 00 00 00 00 Return of reading command: 43 04 20 05 E8 03 00 00 The red part is the current over voltage protection delay time data. Hexadecimal 0x000003E8, converting to decimal, is 1000ms, that is, 1.0s. Default value: 1 6.5.7 Over Current Protection Delay Time Setting command: 23 04 20 06 E8 03 00 00...
Page 23: Under Voltage Protection Ready Time
6.5.9 Under Voltage Protection Ready Time Setting command: 23 04 20 08 E8 03 00 00 Reading command: 43 04 20 08 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2004 0x08 Parameter description: Return of setting command: 60 04 20 08 00 00 00 00 Return of reading command: 43 04 20 08 E8 03 00 00...
Page 24: Under Current Protection Delay Time
Parameter description: Return of setting command: 60 04 20 0A 00 00 00 00 Return of reading command: 43 04 20 0A E8 03 00 00 The red part is current under current protection ready time data. Hexadecimal 0x000003E8, converting to decimal, is 1000ms, that is, 1.0s. Default value: 1 6.5.12 Under Current Protection Delay Time Setting command: 23 04 20 0B E8 03 00 00...
Page 25: Priority Mode
01 – ON 6.6.2 Priority Mode Setting command: 23 05 20 01 00 00 00 00 Reading command: 43 05 20 01 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2005 0x01 Parameter description: Return of setting command: 60 05 20 01 00 00 00 00 Return of reading command: 43 05 20 01 00 00 00 00 00 –...
Page 26: Operation Mode
Main Index Sub Index Read/Write Data Type Byte Size 0x2005 0x04 Parameter description: Setting the current rise slew in common mode, unit ms Hexadecimal 0x00001388, converting to decimal, is 5000, that is, the voltage rise slew is set to 5000A/s. Defalut value: 1000 6.6.5 Operation Mode Setting command: 23 05 20 06 00 00 00 00...
Page 27: Delay Time Off
Parameter description: Return of setting command: 60 05 20 07 00 00 00 00 Return of reading command: 43 05 20 07 E8 03 00 00 The red part is the delay time ON data. Hexadecimal 0x000003E8, converting to decimal, is 1000ms, that is, 1.0s. Default value：...
Page 28: Timer Shutdown
01- 0N Default value： 0 6.6.9 Timer Shutdown Setting command: 23 05 20 0A 88 13 00 00 Reading command: 43 05 20 0A 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2005 0x0A Parameter description: Setting the shutdown time, unit: ms Hexadecimal 0x00001388, converting to decimal, is 5000ms, that is, 5.0s.
Page 29: Control Mode
Format Main Index Sub Index Read/Write Data Type Byte Size 0x2006 0x00 Parameter description: Setting the digital input signal 1 to ONOFF, Hexadecimal 0x00000001, converting to decimal, is 1, that is, the digital input signal 1 is set to ON/OFF. 60 01 20 00 00 00 00 00 Return of setting command:...
Page 30: Control Mode
0x00000001, converting to decimal, is 1, that is, the digital input signal 2 is set to ON/OFF. Return of setting command: 60 01 20 02 00 00 00 00 The red portion of the data 60 indicates successful writing. 01 20 indicates main index.
Page 31: Control Mode
Input Signal: 0-OFF; 1-ONOFF; 2-Clear Default: 0 6.7.6 Control Mode Setting command: 23 06 20 05 01 00 00 00 Reading command: 43 06 20 05 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2006 0x03 Parameter description: Setting the digital input signal 3 to ONOFF, Hexadecimal...
Page 32: Digital Output Signal 2
6.7.8 Digital Output Signal 2 Setting command: 23 06 20 07 01 00 00 00 Reading command: 43 06 20 07 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2006 0x07 Parameter description: Setting the digital output signal 2 to ONOFF, Hexadecimal 0x00000001, converting to decimal, is 1, that is, the digital output signal 2 is set to ON/OFF.
Page 33: Analogue Programming Channel 1
Format Main Index Sub Index Read/Write Data Type Byte Size 0x2006 0x09 Parameter description: Setting the Analogue reference voltage to 5V, Hexadecimal 0x00000000, converting to decimal, is 0, that is, the Analogue reference voltage is set to 5V. Return of setting command: 60 01 20 09 00 00 00 00 The red portion of the data 60 indicates successful writing.
Page 34: Analogue Monitor Channel 1
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 0x2006 0x0B Parameter description: 0---OFF --APG-V --APG-SI --APG-LI --APG-SP --APG-LP Default: 0 6.7.13 Analogue Monitor Channel 1 Setting command: 23 06 20 0C 01 00 00 00 Reading command: 43 06 20 0C 00 00 00 00 Format Main Index Sub Index...
Page 35: Seq Edit
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.8 SEQ Edit 6.8.1 SEQ File No. Setting command: 2F 07 20 00 00 00 00 Reading command: 4F 07 20 00 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2007...
Page 36: Link To File
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Format Main Index Sub Index Read/Write Data Type Byte Size 0x2007 0x02 Parameter description: File cycle times: 1-50000 Hexadecimal: 0x00000001～0x0000FFFF 6.8.4 Link to File Setting command: 23 07 20 03 00 00 00 00 Reading command: 43 07 20 03 00 00 00 00 Format Main Index...
Page 37: Voltage Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.8.6 Voltage Setting Setting command: 23 07 20 05 88 13 00 00 Reading command: 43 07 20 05 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2007 0x05 Parameter description: setting voltage for present step...
Page 38: Dwell Time
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.8.9 Dwell Time Setting command: 23 07 20 08 E8 03 00 00 Reading command: 43 07 20 08 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2007 0x08 Parameter description: setting dwell time for present step...
Page 39: Load Power Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. The current range is the maximum power range supported by the device. Unit is mW. Hexadecimal 0x000003E8, converting to decimal, is 1000mW, that is, 1.000W. 6.8.12 Load Power Setting Setting command: 23 07 20 0B E8 03 00 00 Reading command: 43 07 20 0B 00 00 00 00 Format...
Page 40: Seq Test
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Hexadecimal 0x000003E8, converting to decimal, is 1000mA/s, that is, the voltage slew is 1.000A/s. Default: 5000 6.9 SEQ Test 6.9.1 SEQ File Setting command: 23 08 20 00 01 00 00 00 Reading command: 43 08 20 00 00 00 00 00 Format Main Index...
Page 41: Dwell Time For Present Step
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Main Index Sub Index Read/Write Data Type Byte Size 0x2008 0x02 Parameter description: Reads the number of currently running steps Return of reading command: 43 08 20 02 01 00 00 00 The red part is the number of currently running steps.
Page 42: Power Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Format Main Index Sub Index Read/Write Data Type Byte Size 0x2009 0x00 Parameter description: setting current. The unit is mA. Hexadecimal 0x000003E8, converting to decimal, is 1000mA. That is, 1.000A. 6.10.2 Power Setting Setting command: 23 09 20 01 E8 03 00 00 Reading command: 43 09 20 01 00 00 00 00 Format...
Page 43: Cutoff Time Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 0x2009 0x03 Parameter description: setting charge capacity. The unit is mAh. Hexadecimal 0x000003E8, converting to decimal, is 1000mAh. 6.10.5 Cutoff Time Setting Setting command: 23 09 20 04 E8 03 00 00 Reading command: 43 09 20 04 00 00 00 00 Format Main Index...
Page 44: Cutoff Voltage Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: setting current. The unit is mA. Hexadecimal 0x000003E8, converting to decimal, is 1000mA. That is, 1.000A. 6.11.3 Cutoff Voltage Setting Setting command: 23 0A 20 03 E8 03 00 00 Reading command: 43 0A 20 03 00 00 00 00 Format Main Index...
Page 45: Cutoff Time Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.11.6 Cutoff Time Setting Setting command: 23 0A 20 06 E8 03 00 00 Reading command: 43 0A 20 06 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x200A 0x06...
Page 46: Max. Power Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.12.3 Max. Power Setting Setting command: 23 0B 20 02 E8 03 00 00 Reading command: 43 0B 20 02 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x200B 0x02...
Page 47: Max. Current Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.13.2 Max. Current Setting Setting command: 23 0D 20 01 E8 03 00 00 Reading command: 43 0D 20 01 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x200D 0x01...
Page 48: Level1 Search Term
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Return of reading command: 43 0C 20 00 00 00 00 0: not triggered. 1: Trigger waveform Note: The value is set to 0, the triggered waveform is not changed. 0 is only used to query whether the waveform is triggered 6.14.2 Level1 Search Term Setting command: 23 0C 20 01...
Page 49: Leve3 Search Term
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Level1 Search Term Optional Parameter Implication 0：ISO16750-2 0：Short-Drop Short-Drop：Car Short Time Voltage Drop Waveform 1：Reset-Test 2 Reset-Test：Car Voltage Reset Test ：Start-Profile Waveform 3：Load-Dump Start-Profile：Car Start Waveform Load-Dump：Load Dump Waveform 1：LV124 0：E-04 E-04：Jump start Experiment Pulse 1：E-07 E-07：Experimental parameters for slow drop and slow rise of supply voltage...
Page 50: Leve4 Search Term
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. drop waveform 2：Start-Profile 0：12V 12V： Selected 12V Car Start Waveform 1：24V 24V： Selected 24V Car Start Waveform 3：Load-Dump 0：Test-A Test-A： Select unconcentrated Load Dump Waveform suppression pulse 1：Test-B Test-B：Select concentrated Load Dump Waveform suppression pulse Note: The data change of lookup item and setting item must be OFF machine output first, and the parameters of the later level must be jointly determined by the parameters of the previous level...
Page 51: Waveform Setting I
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. waveform voltage/duration Level4：Corresponding 12V waveform voltage/duration 1:24V 0:Level 1 Level1：Corresponding 24V waveform voltage/duration 1:Level 2 Level2：Corresponding 24V 2: Level 3 waveform voltage/duration Level3：Corresponding 24V waveform voltage/duration 3： 0：Test-A 0：12V 12V：Select 12V system Load-Dump 1：Test-B 1：24V...
Page 52: Waveform Setting Ii
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 0: ISO16750-2 1: Reset-Test None Usmin: minimum power voltage Unit: mV 3: Load-Dump 0: Test-A 0: 12V Td: pulse width 1: Test-B 1: 24V Unit: ms 1: LV124 1: E-07 None Ubmax：start voltage Unit: mV Parameter description: The value is an integer.
Page 53: Waveform Setting Iii
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. voltage Unit: mV Parameter description: The value is an integer, for example, Un. Hexadecimal is 0x00001388, converted to decimal 80000mV, that is, The minimum supply voltage is 80.000V. Note: The data change of lookup item and setting item must be OFF machine output first, and the parameters of the later level must be jointly determined by the parameters of the previous level 6.14.8 Waveform setting...
Page 54: Step Test
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Hexadecimal is 0x0000C350, converted to decimal 50000mV, that is, The minimum supply voltage is 50.000V. Note: The data change of lookup item and setting item must be OFF machine output first, and the parameters of the later level must be jointly determined by the parameters of the previous level 6.15 Step Test 6.15.1 Voltage Setting...
Page 55: Load Current Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.15.3 Load Current Setting Setting command: 23 10 20 02 88 13 00 00 Reading command: 43 10 20 02 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2010 0x02...
Page 56: Mode Selection
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: setting the load power value The unit is mW. Hexadecimal 0x00001388, converting to decimal, is 5000mW. That is, the setting voltage is 5.000W. Return of setting command: 60 10 20 04 00 00 00 00 Return of reading command: 43 10 20 04 88 13 00 00...
Page 57: Start
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Main Index Sub Index Read/Write Data Type Byte Size 0x2010 0x09 Parameter description: To set cycle times, range 0～65535, Hexadecimal 0x00000000 to 0x0000FFFF, 0 for infinite cycle. Return of setting command: 60 10 20 09 00 00 00 00 Return of reading command: 43 10 20 09 01 00 00 00...
Page 58: Increment
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.15.11 Increment Setting command: 23 10 20 07 E8 03 00 00 Reading command: 43 10 20 07 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2010 0x07 Parameter description: setting the increment value...
Page 59: File Length
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x0C Parameter description: setting the file number, range 1-10 Return of setting command: 60 11 20 0C 00 00 00 00 Return of reading command: 43 11 20 0C 01 00 00 00 Default value: 1...
Page 60: Mode Selection
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Reading command: 43 11 20 0F 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x0F Parameter description: setting the link for present file, range 0-10. 0 for no link. Return of setting command: 60 11 20 0F 00 00 00 00...
Page 61: Amplitude
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.16.7 Amplitude Setting command: 23 11 20 12 88 13 00 00 Reading command: 43 11 20 12 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x12 Parameter description: setting the amplitude for present step.
Page 62: Source Current Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. The unit is mV. Hexadecimal 0x00001388, converting to decimal, is 5000mV. That is, the setting voltage is 5.000V. Return of setting command: 60 11 20 00 00 00 00 00 Return of reading command: 43 11 20 00 88 13 00 00 Default: 0 6.17.2 Source Current Setting...
Page 63: Load Power Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Reading command: 43 11 20 03 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x03 Parameter description: setting the source power value The unit is mW. Hexadecimal 0x00001388, converting to decimal, is 5000mW. That is, the setting voltage is 5.000W.
Page 64: Step No
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.17.7 Step No. Reading command: 43 11 20 06 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x06 Parameter description: setting the step No. for present file. Return of reading command: 43 11 20 06 01 00 00 00 Default value: 0...
Page 65: Anywave Test
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Format Main Index Sub Index Read/Write Data Type Byte Size 0x2011 0x0A Parameter description: setting the output mode for present step. Unit ms. Return of reading command: 43 11 20 0A 00 00 00 00 Default value: 0 6.18 Anywave Test 6.18.1 Voltage Setting...
Page 66: Load Current Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.18.3 Load Current Setting Setting command: 23 12 20 02 88 13 00 00 Reading command: 43 12 20 02 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2012 0x02...
Page 67: Mode Selection
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: setting the load power value The unit is mW. Hexadecimal 0x00001388, converting to decimal, is 5000mW. That is, the setting voltage is 5.000W. Return of setting command: 60 12 20 04 00 00 00 0 Return of reading command: 43 12 20 04 88 13 00 00...
Page 68: Wave Selection
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.18.8 Wave Selection Setting command: 23 12 20 06 00 00 00 00 Reading command: 43 12 20 06 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2012 0x06 Parameter description: Range 1-30.
Page 69: Output Phase
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: Expand the setting by 1000 times, such as hex 0x000003E8, convert to decimal as 5000, set the actual value to 5.0; Return of setting command: 60 12 20 08 00 00 00 00 Return of reading command: 43 12 20 08 88 13 00 00 Default value: 0...
Page 70: Advanced Edit
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Format Main Index Sub Index Read/Write Data Type Byte Size 0x2012 0x0B Parameter description: Expand the setting by 1000 times, such as hex 0x000003E8, convert to decimal as 5000, set the actual value to 5.0; Range 0-100. Sine wave setting is not valid.
Page 71: Cycle Times
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.19.3 Cycle Times Setting command: 23 13 20 0E 03 00 00 00 Reading command: 43 13 20 0E 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013 0x0E Parameter description: setting the cycle times for present file, range 0-65535.
Page 72: Step No
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Default value: 0 6.19.6 Step No. Setting command: 23 13 20 11 01 00 00 00 Reading command: 43 13 20 11 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013...
Page 73: Output Bias
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 0x2013 0x13 Parameter description: Expand the setting by 1000 times, such as hex 0x000003E8, convert to decimal as 1000, set the actual value to 1.0; Return of setting command: 60 13 20 14 00 00 00 00 Return of reading command: 43 13 20 14 88 13 00 00...
Page 74: Percentage
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Reading command: 43 13 20 16 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013 0x16 Parameter description: Expand the setting by 1000 times, such as hex 0x000003E8, convert to decimal as 5000, set the actual value to 5.0;...
Page 75: Dwell Time
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.19.14 Dwell Time Setting command: 23 13 20 19 88 13 00 00 Reading command: 43 13 20 19 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013 0x19 Parameter description: To set dwell time for present step.
Page 76: Load Current Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: setting the source current value The unit is mA. Hexadecimal 0x00001388, converting to decimal, is 5000mA. That is, the setting voltage is 5.000A. Return of setting command: 60 13 20 01 00 00 00 00 Return of reading command: 43 13 20 01 88 13 00 00...
Page 77: Load Power Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.20.5 Load Power Setting Setting command: 23 13 20 04 88 13 00 00 Reading command: 43 13 20 04 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013 0x04...
Page 78: Cycle Times
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.20.8 Cycle Times Reading command: 43 13 20 07 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x2013 0x07 Parameter description: setting the cycle times for present file. Return of reading command: 43 13 20 07 01 00 00 00 Default value: 1...
Page 79: System Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.21 System Setting 6.21.1 CANOPEN ID Setting command: 23 0F 20 00 01 00 00 00 Reading command: 43 0F 20 00 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x200F...
Page 80: Rs232/Rs485 Baud Rate Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Main Index Sub Index Read/Write Data Type Byte Size 0x200F 0x02 Parameter description: Return of setting command: 60 0F 20 02 00 00 00 00 Return of reading command: 43 0F 20 02 01 00 00 00 The value ranges from 1 to 250 Default value: 1 6.21.4 RS232/RS485 Baud Rate Setting...
Page 81: Ip Setting
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Parameter description: Return of setting command: 60 0F 20 07 00 00 00 00 Return of reading command: 43 0F 20 07 01 00 00 00 The value ranges 0~ 1 0- No save 1- save Default value: 1 6.21.6 IP Setting...
Page 82: Language
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6. Reset the protection setting value (under voltage, over voltage, over current, over power, etc.) to 0; Reentry protection closed; The protection delay is 1s. 7. Reset the constant power (voltage, current, power) setting value to 0; 8, clear all sequence run files, sequence file allocation step is 0;...
Page 83: Subnet Mask
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 6.21.10 Subnet Mask Setting command: 23 0F 20 0A FF FF FF 00 Reading command: 43 0F 20 0A 00 00 00 00 Format Main Index Sub Index Read/Write Data Type Byte Size 0x200F 0x0A Parameter description:...
Page 84: Seq Mode
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 23 01 20 00 88 13 00 00 //set the output voltage to 5V 23 01 20 01 10 27 00 00 //Set the output source current to 10A 23 01 20 02 D8 D6 00 00 00 //Set output carrier current to 55A 23 01 20 03 A0 25 26 00 00 //Set output source power to 2500W...
Page 85: Simulated Resistance
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 23 07 20 09 01 00 00 00 00 //Set dwell unit for step 1 to s 23 07 20 04 01 00 00 00 00 //Select step number 2 23 07 20 05 88 13 00 00 00 //Set voltage for step 2 to 5V 23 07 20 06 10 27 00 00 00 //Set source current for step 2 to 10A...
Page 86: Factory Reset
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. 43 02 20 01 00 00 00 00 00 00 //Check device output current 43 02 20 02 00 00 00 00 00 00 00 //Check device output power 7.4 Factory Reset 23 0F 20 07 01 00 00 00 N35100 Series Programming Guide SCPI Protocol...
