DCT-1 and DCT-1E
Digital Alarm Communicator/Transmitter
Operation, Installation and Maintenance Manual
Siemens Building Technologies, Inc.
8 Fernwood Road
Florham Park, New Jersey 07932
P/N 315-099346-1
Fire Safety
Siemens Building Technologies, Ltd.
2 Kenview Boulevard
Brampton, Ontario L6T 5E4 CN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCT-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens DCT-1

Summary of Contents for Siemens DCT-1

  • Page 1 Fire Safety DCT-1 and DCT-1E Digital Alarm Communicator/Transmitter Operation, Installation and Maintenance Manual Siemens Building Technologies, Inc. Siemens Building Technologies, Ltd. 8 Fernwood Road 2 Kenview Boulevard Florham Park, New Jersey 07932 Brampton, Ontario L6T 5E4 CN P/N 315-099346-1...
  • Page 2 Page 2 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 3: Table Of Contents

    Appendix C: Reporting Summary for Fire Communicator ....................61 Appendix D: Programming Defaults List ..........................63 Appendix E: Report Routing ..............................65 Appendix F: Compatibilities ..............................67 Index ......................................69 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 3...
  • Page 4 Contents Figures Tables Page 4 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 5: Notices

    Notices Notices FCC Compliance Notice FCC Phone Connection to Users The manufacturer, not the user, must make the repairs to this equipment. DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 5...

  • Page 6: Industry Canada Notice

    Installation Guidelines for UL Systems Failure to install and program the DCT-1/1E according to the requirements in this section voids the listing mark of Underwriters Laboratories, Inc. Test in accordance with NFPA 72 Chapter 7-1.6.2 (1999) following any modifcations, repair, upgrades or adjustments made to the system.

  • Page 7: Overview

    Table 1: DCT-1/1E Power Specifications Some FACP’s may momentarily drop DC power that the DCT-1/1E is connected to at the start of an AC power failure. If the FACP used with the DCT-1/1E exhibits this behavior, any immediate AC Fail report can be used as impetus for reprogramming the DCT-1/1E’s date/time.

  • Page 8: Input Configuration

    Overview 2.2.3 Inputs c r i t i u t s i Table 2: DCT-1/1E Input Point Specifications 2.2.4 Input Configuration 2.2.5 Trouble Output Note: 2.2.6 User Interface Note: Page 8 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 9: History Buffer

    Communication Failed Indication: 2.2.8 History Buffer The history buffer is cleared when the system loses all power. 2.2.9 General Specifications Storage and Operating Temperature Range: Lightning Protection: 2.2.10 Hardware Note: Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 9...
  • Page 10 NC C NO KEYPAD + + - - A B Power Molex Connector Pins Keypad Molex Connector Pins Input Molex Trouble Relay Connector Pins Connector Pins Figure 1: DCT-1/1E PCB Layout Page 10 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 11: Installation

    This end up 6.25 in Snap mounting clip onto enclosure lance Inside View of DCT-1E Enclosure Figure 3: Mounting the DCT-1E Enclosure to the Wall 7.75 in DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 11 Inside View of DCT-1E Enclosure...

  • Page 12: Fire Alarm Control Panel

    Ground Wire Support Post Assembly Figure 4: Mounting the DCT-1E Board Enclosure Knockouts Conduit No more than 500 ft. (152 m) Fire Alarm Control Panel DCT-1E Note: Figure 5: Conduit Connections Page 12 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 13: Wiring Connections

    Wiring Connections Wiring Connections Input Point Connections Remove all power before making or breaking any connections to the DCT-1/1E. Failure to do so may result in personal injury and/or damage to the equipment. Note: Contact postion shows off-normal condition. Under normal operation, the trouble relay is held activated (C and NO are normally connected).
  • Page 14 (KEYPAD) FACP Power (+) Contact Relay EOL Resistor: 2.21 k Ω, UL Listed P/N: 25899 Detection Systems, Inc. Panel Ground Earth Ground Figure 9: Dry Contact Input Point Wiring (Supervised) Page 14 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 15: Trouble Relay Connections

    3 4 5 KEYPAD - A B (KEYPAD) EOL Resistor (see FACP installation instructions for UL approved EOL resistor specifications) FACP Zone Input Earth Ground Figure 11: Typical Trouble Relay Connections (Supervised) DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 15...

  • Page 16: Telephone Connections

    Input Earth Ground Figure 12: Typical Trouble Relay Connections (Non-supervised) Telephone Connections 4.3.1 Telephone Cord Installation Note: 4.3.2 Location Full Modular Phone Jack RJ31X Module Figure 13: RJ31X Wiring Note: Page 16 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 17 + + - - A B DCT-P DCT-P Terminal Strip Terminal Strip KEYPAD +12 VDC BLACK Data In GREEN Data Out YELLOW Figure 14: Connecting a Keypad to the DCT-1/1E DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 17...
  • Page 18 Wiring Connections Notes: Page 18 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 19: System Start-Up

    Before Power-up 5.1.2 After Power-up System Quick Start Note: Test in accordance with NFPA 72 Chapter 7-1.6.2 (1999) following any modifcations, repair, upgrades or adjustments made to the system. Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 19...
  • Page 20 Wiring Connections Notes: Page 20 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 21: Overview Of Features And Operation

    System Operation Overview Of Features And Operation Communicator Operation Note: 6.1.1 Phone Line and Phone Number Selection Note: Note: Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 21...

  • Page 22: Call Routing

    PHONE 1 Only: PHONE 2 Only: PHON 1 AND 2: PHN 2 BACKUP: Note: 6.1.5 Call Attempts Table 3: Report Routing with Primary and Alternate Phone Number, Phone 2 Backup Page 22 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 23 System Operation 6.1.6 Communication Fault 6.1.7 Programming Fault 6.1.8 Lost Data 6.1.9 Limited Reports 6.1.10 Communications Tests DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 23...
  • Page 24 6.1.10.1 Auto Test Note: A power cycle will default the system time to “0000.” The system time should be set up again after a power cycle. Note: 6.1.10.2 Manual Test Note: Page 24 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 25 Note: Note: Note: Note: Low Battery*: * Input Voltage Levels for Fire, Waterflow, Supervisory, Monitor, AC Failure and Low Battery: Table 4: Input Point Voltage Levels OPEN: NORMAL: SHORT: Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 25...
  • Page 26 (KEYPAD) FACP Output Relay Earth Ground EOL Resistor: 2.21 k Ω, UL Listed P/N: 25899 Detection Systems, Inc. Figure 15: System Fault/Fault on Open Connections Note: Trouble Relay Operation Note: Page 26 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 27: Keypad Operation

    [#/Command] Key: [*/Clear] Key: [*/Clear] [Drill] Key: [Disable] Key: [Test] Key: [Test] [Test] [History] Key: [History] [1] Key: [*/Clear] [4] Key: [*/Clear] [3] Key: [*/Clear] [6] Key: [*/Clear] [Reset] Key: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 27...

  • Page 28: Scrolling Menus

    Selecting Menu Items Exclusive Keys: [Test] SYSTEM NORMAL Test 3: TEST Press the [TEST] key Press the [3] key on the DCT-P Keypad from the Main Menu Figure 19: Exclusive Keys Page 28 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 29 Event # Event NXT-DRL/PRV-DIS 037/037 KEYPD:IN 02:51 010100 Press [Drill] to Press [Disable] advance to the to display the Time next event. previous event. Month Year Figure 22: Event History Example DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 29...
  • Page 30 System Operation o i t u l i t l u e l l c i t t i n o l f Table 6: Event History Abbreviations Reset [Reset] Page 30 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 31: How To Program

    Figure 23: Programming Key Sequence for System Date Note: When Programming Mode is entered, all monitoring will cease. The DCT-1/1E will not process input point events or supervise the phone lines. Central Station communication is disabled. Programming Key Sequences 7.2.1...
  • Page 32 (Level 3), confirm the setting. PROG TIME submenu. enter the Programming press [1] to select 1: Menu (Level 2). SYSTEM (Level 4). Figure 24: Programming Key Sequence Diagram Note: Page 32 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 33: Program Menu Tree

    Program Menu Tree Program Menu Tree Level 2 (Programming Menu) Level 3 Level 4 Level 5 Note: Note: Note: Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 33...
  • Page 34 Program Menu Tree Level 6 Level 3 Level 4 Level 5 Level 2 (Programming Menu) Page 34 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 35 Program Menu Tree Level 2 (Programming Menu) Level 3 Level 4 Level 5 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 35...
  • Page 36 Program Menu Tree Notes: Page 36 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 37: Programming

    Programming Programming Note: PROG TIME Description: Programming Procedure: 9.1.1 1: SYSTEM Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [*/Clear] [#/Command] [*/Clear] DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 37...
  • Page 38 Programming Key Sequence: [0] , [1] Description: Programming Procedure: [#/Command] [*/Clear] 9.1.2.2 2: TEST FREQUENCY Programming Key Sequence: [0] , [2] Description: Programming Procedure: This item is not currently supported. [#/Command] [*/Clear] Page 38 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 39 PROG TIMERS Description: Programming Procedure: 9.2.1 1: AC FAIL DLY Programming Key Sequence: [0] Description: 9.2.1.1 1: WAIT FOR DC Programming Key Sequence: [0] Description: Note: Programming Procedure: [#/Command] [*/Clear] DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 39...

  • Page 40: Program Inputs

    Note: Note: Programming Procedure: [#/Command] [#/Command] [*/Clear] 9.2.2 2: DISPLAY RATE Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [*/Clear] Program Inputs Description: Programming Procedure: [#/Command] [Drill] [Drill] [Disable] [Disable] Page 40 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 41 1: CONFIGURE Programming Key Sequence: [0] Description: Fire: Waterflow: Supervisory: Monitor: System Fault: AC Failure: Low Battery: Note: Note: Note: Note: Note: Programming Procedure: [#/Command] Note: [#/Command] [*/Clear] [#/Command] [*/Clear] DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 41...
  • Page 42 Programming Procedure: Note: 9.4.1 1: RELEAS ON TRBL Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [*/Clear] 9.4.2 2: ACTIV GND STRT Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [*/Clear] Page 42 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 43 Programming PROG ACC’NTS Description: Programming Procedure: 9.5.1 1: ACCOUNT NUMBERS Programming Key Sequence:[0] Description: Programming Procedure: [Test] [*/Clear] Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 43...
  • Page 44 For compliance with UL and NFPA standards, both phone numbers must be used. Programming Procedure: This item is not currently supported. [Drill] [Disable] [#/Command] [*/Clear] Note: [TEST] * CODE: [TEST] # CODE: [TEST] /3 SEC DELAY: [TEST] Page 44 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 45 Programming 9.5.3 3: PHONE CONTROL Programming Key Sequence:[0] Description: Programming Procedure: 4/2 Format only. See below for Tone settings. [#/Command] [*/Clear] [#/Command] [*/Clear] DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 45...
  • Page 46 Programming 9.5.4 4: RPT STEERING Programming Key Sequence:[0] Description: Note: Programming Procedure: PHONE 1 ONLY: PHONE 2 ONLY: PHONE 1 AND 2: PHONE 2 BACKUP: [#/Command] [*/Clear] Note: Page 46 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 47 Programming 9.5.5 5: LINE CONTROL Programming Key Sequence:[0] [5]- , [5]- Description: Programming Procedure: Dialing Type: Monitor Line: Note: Wait Dialtone: [#/Command] [*/Clear] [#/Command] [*/Clear] [#/Command] [*/Clear] DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 47...

  • Page 48: Prog Formats

    A Fire Alarm on Point 2 will send a 4/2 Point Report of “1 2” to the Central Station. Figure 25: 4/2 Point Report Example Programming Procedure: This item is not currently supported. Page 48 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 49 Programming This item is not currently supported. This item is not currently supported. [#/Command] [TEST] Note: [#/Command] [*/Clear] These items are not currently supported. DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 49...
  • Page 50 Programming [#/Command] [TEST] [#/Command] [*/Clear] Note: 9.6.2 2: RPT CODES Programming Key Sequence: [0] Description: Programming Procedure: These items are not currently supported. Page 50 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 51 Programming [TEST] [TEST] Note: 9.6.3 3: SIA SILENC RPT This item is not currently supported. Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [TEST] Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 51...
  • Page 52 All programming, including point configurations and option selections, will be lost when this operation is performed. Note: Programming Procedure: [#/Command] [*/Clear] 9.7.3 3: DEFLT 4/2 CODES Programming Key Sequence: [0] Description: Programming Procedure: [#/Command] [*/Clear] Page 52 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 53: 10.0 Modes Of Operation

    Modes of Operation 10.0 Modes of Operation 10.1 0-PROGRAM 10.2 1-STATUS [*/Clear] 10.3 2-HISTORY 10.4 3-TEST Note: 10.4.1 1: TEST COMM Programming Key Sequence: [3] Description: Procedure: Note: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 53...
  • Page 54 Modes of Operation Note: 10.5 4-RESET [RESET] Page 54 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 55: Appendix A: Dct-1/1E Troubleshooting

    Appendix A Appendix A: DCT-1/1E Troubleshooting DCT-1/1E Onboard LEDs LINE 1 LED: The voltage present during ringing for an incoming call can be over 100 VAC. LINE 2 LED: HEARTBEAT LED: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 55...

  • Page 56: Input Points

    " g l l i u l i d l i . y l Table 7: SYS TROUBLE LED Indications Note: Input Points Trouble Relay RELEAS ON TRBL: ACTIV GND STRT: Page 56 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...
  • Page 57 Appendix A Manual Test Report Failure [*/Clear] Reports in Queue [*/Clear] [*/Clear] “ERROR DURING COMM TEST” Message DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 57...
  • Page 58 Page 58 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 59: Appendix B: 4/2 Reporting Codes

    : e l h t i h t i t l u : e l t l u : t r t l u i t c DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 59...
  • Page 60 : t r l i a h t i l u f : t l Page 60 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 61: Appendix C: Reporting Summary For Fire Communicator

    Notes: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 61...
  • Page 62 - f l u l i u l i u l i t l u u l i t l u u l i Notes: Page 62 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 63: Appendix D: Programming Defaults List

    Phone #3: Silence: Phone Control Fire Drill: Phone #1 Format: Fire Drill Rstl: Phone #2 Format: Open Reset: Phone #1 Tone: Low Batt: Phone #2 Tone: Low Batt Rstrl: AC Fail: DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 63...
  • Page 64 Network Restor: Sens Bus Rpt: Sens Bus Rstrl: Program Formats (4/2 Rpt Codes Group 5) Rmt Prg Fail: Rmt Prg Succ: Unknown Flt: SIA Silence Report Left Byte: Right Byte: Page 64 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 65: Appendix E: Report Routing

    DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 65...
  • Page 66 Appendix E * l i l i a ‡ l i a * t l * t l ‡ Page 66 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 67: Appendix F: Compatibilities

    = Available) Osborne/Hoffman Silent Report Radionics Radionics Sur-gard Ademco Quick Alert Model Knight Format D6500 D6600 SG-SLR SK9000 Contact ID SIA 300 SIA 110 Table 8: DCT-1/-1E UL Listed Compatibility DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 67...
  • Page 68 Page 68 DCT-1 and DCT-1E Operation, Installation and Maintenance Manual...

  • Page 69: Index

    Index Index Symbols DCT-1 and DCT-1E Operation, Installation and Maintenance Manual Page 69...
  • Page 72 Siemens Building Technologies, Inc. Siemens Building Technologies, Ltd. 8 Fernwood Road 2 Kenview Boulevard Florham Park, New Jersey 07932 Brampton, Ontario L6T 5E4 CN P/N 315-099346-1...
